Jura ENA 3 Disassembling Manual

Elektroapparate AG
Disassembling manual
Technical Support
Language E
ENA 3 / ENA 5
5/ Pull up fixation of the lateral part 6/ 2x Unscrew TORX 15
7/ Remove lateral part Right towards you 8/ Remove lateral part Left towards you
9/ Release snap-lock of fixation of the lateral part 10/ Remove fixation of the lateral part
Author: Patrik Studer Checked: Approved: Docu.-name: Ena Disassemble Manual.doc
C:\Users\Admin\Documents\Jura Manuals\Ena\ENA 5\Ena
Disassemble Manual.doc
Date: Rev. A: Rev. B: Rev. C: Rev. D: Rev. E: Rev. F:
18.10.2007 26.10.2007
Page 3/15

Jura ENA 3 Specifications

General

Type	Coffee
Dimensions (WxDxH)	238 x 360 x 445 mm
Product type	Espresso machine
Capacity in cups	10 cups
Anti-drip function	Yes
Water tank capacity	1.1 L
Maximum operating pressure	15 bar
Lid type	Hinged lid
Product color	Black
Multi beverage	No

Weight and Dimensions

Weight	9300 g
