Jura ENA 3 Disassembling Manual

Elektroapparate AG
Disassembling manual
Technical Support
Language E
ENA 3 / ENA 5
29/ Unscrew TORX 10 30/ Pull air cover forwards
31/ Lift up air cover 32/ Side view of air cover (fit-in hook)
33/ Unscrew 2x TORX 10 34/ Removing upper part:
 Release 1st snap-lock with a screw driver
35/ Removing upper part:
 Release 4 snap-locks with a screw driver
 36/ Pull up upper part, there are
5 snap-locks
Author: Patrik Studer Checked: Approved: Docu.-name: Ena Disassemble Manual.doc
C:\Users\Admin\Documents\Jura Manuals\Ena\ENA 5\Ena
Disassemble Manual.doc
Date: Rev. A: Rev. B: Rev. C: Rev. D: Rev. E: Rev. F:
18.10.2007 26.10.2007
Page 7/15

Jura ENA 3 Specifications

General

Type	Coffee
Dimensions (WxDxH)	238 x 360 x 445 mm
Product type	Espresso machine
Capacity in cups	10 cups
Anti-drip function	Yes
Water tank capacity	1.1 L
Maximum operating pressure	15 bar
Lid type	Hinged lid
Product color	Black
Multi beverage	No

Weight and Dimensions

Weight	9300 g
