Control elements
1. Rotary Switch
2. Illuminated ring
3. Programming key
4. Draw-off key 2 cups
5. Powder coffee selection key
6. Draw-off key 1cup
7. Steam pre-selection key
8. ON/OFF key
9. Maintenance key
10. Display dialog system
11. Water tank with carrying handle
12. Filler funnel for pre-ground coffee
13. Bean tank cover
14. Aroma preservation cover
15. Steam/hot water water draw-off valve
16. Replaceable 2-stage frothing jet see fig.6
17. Replaceable hot water jet mounted in illustration also
see Fig. 5
18. Height-adjustable coffee spout
19. Coffee grounds container
20. Drip grate
21. Drip drawer
22. Power Switch
7
6
14
15
18
19
12
13
21
16 / 17
20
3
4
5
8
9
11
12
10
22
