Assembly Process
5Juvent 1000 Instruction Manual
10. Removed base tube screws.
Slide the hand rail assembly
into the base tubes.
Reassemble the rail mast
fitting and reassemble base
tube screws. Then tighten.
9. Slide the hand rail adjust tubes
onto the side rails. Snap into first
hole.
