JVC AV-14A16 Service Manual

3-10(No.YA391)
PRINTED WIRING BOARD PARTS LIST [AV-14A16/A]
MAIN P.W. BOARD ASS'Y (SCG-1555A-H2)
 Ref No. Part No. Part Name Description Local
IC301 NN5198K IC
IC421 LA78040N IC
IC651 AN5265 IC
IC701 MN1873287JL1 IC
IC702 ATE08-21YMG6 IC (SERVICE)
IC703 L78LR05E-MA IC
IC704 GP1UM281QK IR DETECT UNIT 38kHz
IC921 STR-W5753A/F5 IC
IC971 L7809CP IC
IC972 L7805CP IC
Q102 2SC5397/CD/-T TRANSISTOR
Q301 2SA1530A/QR/-X TRANSISTOR
Q302 2SC3928A/QR/-X TRANSISTOR
Q351 2SC4015/N/-T TRANSISTOR
Q352 2SC4015/N/-T TRANSISTOR
Q353 2SC4015/N/-T TRANSISTOR
Q401 DTC124ESA-T DIGI TRANSISTOR
Q402 2SC3928A/QR/-X TRANSISTOR
Q521 2SC2655/Y/-T TRANSISTOR
 Q522 TT2140LS-YB11 POW TRANSISTOR
Q571 2SA1208/ST/Z1-T TRANSISTOR
Q572 2SC3928A/QR/-X TRANSISTOR
Q651 2SC3928A/QR/-X TRANSISTOR
Q652 2SC3928A/QR/-X TRANSISTOR
Q653 2SA1530A/QR/-X TRANSISTOR
Q702 2SC3928A/QR/-X TRANSISTOR
Q703 2SC3928A/QR/-X TRANSISTOR
Q708 UN2212-X DIGI TRANSISTOR
Q710 UN2212-X DIGI TRANSISTOR
Q803 KTC3199/YG/-T TRANSISTOR
Q804 2SC3928A/QR/-X TRANSISTOR
Q974 2SA966/OY/-T TRANSISTOR
Q975 UN2212-X DIGI TRANSISTOR
D001 MTZJ33A-T2 Z DIODE
D301 MTZJ9.1B-T2 Z DIODE
D302 MTZJ9.1B-T2 Z DIODE
D303 MA3091/M/-X Z DIODE
D305 1K4-T2 SB DIODE
D306 QRE121J-561Y C RESISTOR 560 Ω 1/2W J
D306 or QRE122J-561 C RESISTOR 560 Ω 1/2W J
D306 or QRG01GJ-561 OMF RESISTOR 560 Ω 1W J
D341 MA111-X SI DIODE
D421 MTZJ75-T2 Z DIODE
D423 1SR124-400A-T2 SI DIODE
D425 MA111-X SI DIODE
D427 MTZJ27B-T2 Z DIODE
D501 MTZJ6.8C-T2 Z DIODE
D551 FR105GT-T3 SI DIODE
D552 FR105GT-T3 SI DIODE
D553 MTZJ9.1B-T2 Z DIODE
D554 MA111-X SI DIODE
D571 MTZJ7.5S-T2 Z DIODE
D581 MTZJ20B-T2 Z DIODE
D582 FR105GT-T3 SI DIODE
D651 MA111-X SI DIODE
D652 MTZJ12C-T2 Z DIODE
D653 MA111-X SI DIODE
D654 MTZJ12C-T2 Z DIODE
D655 MA111-X SI DIODE
D656 MA111-X SI DIODE
D657 MA111-X SI DIODE
D703 SPR-39MVWF LED POWER,ON TIMER(RED-GREEN)
D707 MA111-X SI DIODE
D731 MA111-X SI DIODE
D920 1SS133-T2 SI DIODE
D921 FR105GT-T3 SI DIODE
D925 FR105GT-T3 SI DIODE
D927 MTZJ36A-T2 Z DIODE
D928 MTZJ3.3A-T2 Z DIODE
D930 FR107GT-T3 SI DIODE
D931 MA111-X SI DIODE
D933 MTZJ16C-T2 Z DIODE
D941 RU3AM-LFC4 SI DIODE
D942 ERC30-02L38E SI DIODE
D943 FR105GT-T3 SI DIODE
D982 MA111-X SI DIODE
D983 MA111-X SI DIODE
C001 QETN1HM-106Z E CAPACITOR 10uF 50V M
C002 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C004 QETN1CM-477Z E CAPACITOR 470uF 16V M
C005 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C008 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C103 QETN1EM-476Z E CAPACITOR 47uF 25V M
C104 NCB31HK-472X C CAPACITOR 4700pF 50V K
C105 NCB31HK-472X C CAPACITOR 4700pF 50V K
C106 NCB31HK-472X C CAPACITOR 4700pF 50V K
C107 NCB31HK-472X C CAPACITOR 4700pF 50V K
C110 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
C112 QETN1EM-476Z E CAPACITOR 47uF 25V M
C113 NCB31HK-472X C CAPACITOR 4700pF 50V K
C115 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C116 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C117 QFVF1HJ-224Z MF CAPACITOR 0.22uF 50V J
C119 QETN1HM-474Z E CAPACITOR 0.47uF 50V M
C120 NDC31HJ-121X C CAPACITOR 120pF 50V J
C121 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C122 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C162 NCB31HK-152X C CAPACITOR 1500pF 50V K
C301 NCB31HK-681X C CAPACITOR 680pF 50V K
C302 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C303 NDC31HJ-100X C CAPACITOR 10pF 50V J
C304 QFVF1HJ-474Z MF CAPACITOR 0.47uF 50V J
C305 QETN1HM-474Z E CAPACITOR 0.47uF 50V M
C306 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C307 QETN1CM-477Z E CAPACITOR 470uF 16V M
C308 QETN1CM-107Z E CAPACITOR 100uF 16V M
C309 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C310 NDC31HJ-221X C CAPACITOR 220pF 50V J
C311 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C312 QENC1HM-474Z BP E CAPACITOR 0.47uF 50V M
C313 QETN1HM-335Z E CAPACITOR 3.3uF 50V M
C314 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C315 QETN1CM-107Z E CAPACITOR 100uF 16V M
C316 QETN1HM-106Z E CAPACITOR 10uF 50V M
C317 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C321 NDC31HJ-120X C CAPACITOR 12pF 50V J
C322 NCB31EK-273X C CAPACITOR 0.027uF 25V K
C323 QETN1HM-474Z E CAPACITOR 0.47uF 50V M
C324 QETN1HM-106Z E CAPACITOR 10uF 50V M
C325 QENC1HM-106Z BP E CAPACITOR 10uF 50V M
C326 NCS21HJ-221X C CAPACITOR 220pF 50V J
C341 QETN1HM-106Z E CAPACITOR 10uF 50V M
C352 QFZ0097-103 MM CAPACITOR 0.01uF 1250V K
C354 NDC31HJ-271X C CAPACITOR 270pF 50V J
C355 NDC31HJ-221X C CAPACITOR 220pF 50V J
C356 NDC31HJ-331X C CAPACITOR 330pF 50V J
C357 QETN1AM-477Z E CAPACITOR 470uF 10V M
C365 QENC1HM-105Z BP E CAPACITOR 1uF 50V M
C366 QENC1HM-105Z BP E CAPACITOR 1uF 50V M
C367 QENC1HM-105Z BP E CAPACITOR 1uF 50V M
C401 QFVF1HJ-474Z MF CAPACITOR 0.47uF 50V J
C423 QCS32HJ-180Z C CAPACITOR 18pF 500V J
C424 QFLC2AJ-103Z M CAPACITOR 0.01uF 100V J
C426 QFLC1HJ-102Z M CAPACITOR 1000pF 50V J
C427 QETN1VM-107Z E CAPACITOR 100uF 35V M
C428 QETN1VM-107Z E CAPACITOR 100uF 35V M
C429 QETN1HM-106Z E CAPACITOR 10uF 50V M
C430 QFN32AJ-472Z M CAPACITOR 4700pF 100V J
C433 QEHR1HM-475Z E CAPACITOR 4.7uF 50V M
C435 QETM1EM-228 E CAPACITOR 2200uF 25V M
C436 QFVF1HJ-334Z MF CAPACITOR 0.33uF 50V J
C437 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C501 QETN1EM-476Z E CAPACITOR 47uF 25V M
C502 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C503 QETN1HM-106Z E CAPACITOR 10uF 50V M
C523 QETN1EM-476Z E CAPACITOR 47uF 25V M
C525 QFZ0200-802 MPP CAPACITOR 8000pF 1.5kV H
C526 QFLC1HJ-103Z M CAPACITOR 0.01uF 50V J
C527 QFZ0197-684 MPP CAPACITOR 0.68uF 250V J
C529 QFN32AJ-102Z M CAPACITOR 1000pF 100V J
C531 QEZ0203-107 E CAPACITOR 100uF 160V M
C552 QETM1VM-108 E CAPACITOR 1000uF 35V M
C554 QETN2EM-475Z E CAPACITOR 4.7uF 250V M
C555 QFLC2AJ-104Z M CAPACITOR 0.1uF 100V J
C571 QETN1AM-107Z E CAPACITOR 100uF 10V M
C572 QETN1EM-476Z E CAPACITOR 47uF 25V M
C581 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C652 NCB31HK-473X C CAPACITOR 0.047uF 50V K
C653 QETN1HM-106Z E CAPACITOR 10uF 50V M
C654 QETN1CM-477Z E CAPACITOR 470uF 16V M
C655 QETN1HM-106Z E CAPACITOR 10uF 50V M
C656 QENC1HM-105Z BP E CAPACITOR 1uF 50V M
C657 QETN1EM-107Z E CAPACITOR 100uF 25V M
 Ref No. Part No. Part Name Description Local
