JVC AV-14A3 - Page 16

No. 52029
A
V-14A3
A
V-1415EE
A
V-14AMG
3
23
Item
Measuring
instrument
Test point Ad justment part Description
Ad ju st ment
of
SUB BRIGHT
Remote
control unit
3. BR IG HT 1. Receive an y bro adc ast.
2. En ter th e SERVICE MENU.
3. Select 2. V/C f rom SERVICE ME NU.
4. Select 3. BRIGHT with the MENU ▼/▲key.
5. Set the initial setting value with the MENU - / + key.
6. If the brightness is not the best with the initial set value, make
fine adjustment until you get the best brightness.
Ad ju st ment
of
SUB CONT.
Remote
control unit
4. CONT . 1. Receive an y bro adc ast.
2. En ter th e SERVICE MENU.
3. Select 2. V/C f rom SERVICE ME NU.
4. Select 4. CONT. with the MENU ▼/▲key.
5. Set the initial setting value with the MENU - / + key.
6. If the contrast is not t he best with the initial s et value, mak e fine
adjustment until you get the best contrast.
5. COLOUR [Method of adjustment without measuring instrument]
PAL COLOUR
1. Receive a PAL broa dc ast.
2. En ter th e SERVICE MENU.
3. Select 2. V/C f rom t he SERVI CE MENU.
4. Select 5. COLOUR with the MENU ▼ /▲ key.
5. Set the initial settin
g
value for PAL COLOUR with the MENU
- / + key.
6. If t he co lour is no t th e be st with th e in itia l s et valu e, mak e fin e
adjustment until you get the best colour.
SECAM COLO UR
1. Receive a SECAM b roadc ast.
2. Make fine ad justmen t of SE CA M CO LOUR as previou sly.
NTSC 3.58 COLOUR
1. Receive a NTS C 3.58M Hz br oa dca st.
2. Make sim ila r fin e ad justment of NTSC 3 .58 CO LOUR as
previo usly.
Ad ju st ment
of
SUB
COLOUR Ⅰ
ⅠⅠ
Ⅰ
Remote
control unit
NTSC 4.43 COLOUR
When NTSC 3.58 adjustment completed, NTSC 4.43 will be
automatic ally set at the respective values.
