JVC AV-14A3 - Replacement of IC301 (IF V;C Decoder); Procedures; Locations of Front Panel Buttons and Lamps

No. 52029
A
V-14A3
A
V-1415EE
A
V-14AMG3
14
REPLACEMENT OF IC301 (IF V/C DECODER)
" For the I C301(I F V /C DECODER) of this model, all data are written in the micr o-computer. So, wri te the data in the micro-
computer in accordance with the following procedures before starting adjustment.
PROCEDURES
(1) Tur n t he POWE R O FF.
(2) Replace t he IC30 1 with a n ew o ne .
(3) While pressing MENU bu tto n a nd VO L+ bu tto n ON the FRO NT CABINE T s imult ane ous ly, t urn th e POW ER O N. Wh en the POW ER is
turned ON, th e dat a is writ ten in the micro-co mputer immediately.
LOCATIONS OF FRONT PANEL BUTTONS AND LAM PS
MENU buttons
CHANNEL ･ / ･ buttons
(ME NU ･ / ･ bu tt ons)
VOLUME
－
/
＋
buttons
(MENU
－
/
＋
bu tto ns)
AI ECO sensor
REMOTE CONTROL sens or
ON TIMER lamp
POWER lamp
MAIN POW ER but ton
MENU buttons
CHANNEL －/＋buttons
(ME NU
－
/
＋
buttons)
VOLUME － /＋ buttons
(MENU －/＋ bu tto ns)
REMOTE CONTROL sens or
POWER / ON TIMER lamp
MAIN POWER butt on
1
2
3
4
5
6
12
3
45 6
