JVC AV-21DMT3 User Manual

No. 52023
A
V-21DMT3
40
!
Symbol No. Part No. Part Name Description
CAPACITOR
C1437 NCB31HK-104X C CAP. 0.1
µ
F 50V K
C1501 QETN1AM-477Z E CAP. 470µF 10V M
C1502 NCB31HK-103X C CAP. 0.01µF 50V K
C1503 QETN1HM-106Z E CAP. 10µF 50V M
C1523 QETN1EM-476Z E CAP. 47µF 25V M
! C1525 QFZ0200-972 MPP CAP. 9700pF1.5kVH ± 3%
C1526 QFLC1HJ-103Z M CAP. 0.01µF 50V J
C1527 QFZ0199-434 MPP CAP. 0.43µF 250V J
C1529 QFN32AJ-102Z M CAP. 1000pF 100V J
C1531 QEZ0203-107 E CAP. 100µF 160V M
C1552 QETM1VM-108 E CAP 1000µF 35V M
C1554 QETN2EM-475Z E.CAP 4.7
µ
F 250V M
C1555 QFLC2AJ-104Z M CAP. 0.1
µ
F 100V J
C1557 QETN1HM-107Z E CAP. 100µF 50V M
C1571 QETN1AM-107Z E CAP. 100µF 10V M
C1572 QETN1EM-476Z E CAP. 47µF 25V M
C1581 QFV71HJ-104Z MF CAP. 0.1µF 50V J
C1652 NCB31HK-473X C CAP. 0.047
µ
F 50V K
C1653 QETN1HM-106Z E CAP. 10
µ
F 50V M
C1654 QETN1CM-477Z E CAP. 470µF 16V M
C1655 QETN1HM-106Z E CAP. 10µF 50V M
C1656 QENC1HM-105Z E CAP. 1µF 50V M
C1657 QETN1EM-107Z E CAP. 100µF 25V M
C1658 QETM1EM-228 E CAP. 2200
µ
F 25V M
C1659 QETN1HM-475Z E CAP. 4.7
µ
F 50V M
C1663 NCB31HK-102X C CAP. 1000pF 50V K
C1664 QETN1CM-107Z E CAP. 100
µ
F 16V M
C1665 NCB31HK-103X C CAP. 0.01µF 50V K
C1701 QETN1HM-106Z E CAP. 10µF 50V M
C1705 QETN1CM-477Z E CAP. 470µF 16V M
C1706 NCB31HK-104X C CAP. 0.1
µ
F 50V K
C1707 NCB31HK-103X C CAP. 0.01
µ
F 50V K
C1708 QETN1AM-108Z E CAP. 1000
µ
F 10V M
C1709 NCB31HK-103X C CAP. 0.01µF 50V K
C1710 QETN1CM-107Z E CAP. 100µF 16V M
C1711 NCB31HK-103X C CAP. 0.01µF 50V K
C1712 NCB31HK-103X C CAP. 0.01
µ
F 50V K
C1713 NCB31HK-103X C CAP. 0.01
µ
F 50V K
C1716 NDC31HJ-181X C CAP. 180pF 50V J
C1717 NDC31HJ-181X C CAP. 180pF 50V J
C1718 NCB31HK-103X C CAP. 0.01µF 50V K
C1719 QETN1HM-105Z E CAP. 1
µ
F 50V M
C1720 NCB31HK-103X C CAP. 0.01
µ
F 50V K
C1721 NCB31EK-333X C CAP. 0.033 µF 25V K
C1722 NDC31HJ-101X C CAP. 100pF 50V J
C1724 NDC31HJ-560X C CAP. 56pF 50V J
C1728 NDC31HJ-181X C CAP. 180pF 50V J
C1729 NDC31HJ-181X C CAP. 180pF 50V J
C1730 NCB31HK-103X C CAP. 0.01µF 50V K
C1741 QETN1HM-106Z E CAP. 10µF 50V M
C1742 QETN1HM-106Z E CAP. 10
µ
F 50V M
C1743 QETN1HM-106Z E CAP. 10µF 50V M
C1744 NCB31HK-103X C CAP. 0.01µF 50V K
C1805 QETN1CM-227Z E CAP. 220µF 16V M
C1806 QETN1CM-477Z E CAP. 470µF 16V M
C1811 QETN1HM-106Z E CAP. 10µF 50V M
C1821 QETN1CM-107Z E CAP. 100
µ
F 16V M
C1822 NCB31HK-103X C CAP. 0.01µF 50V K
C1823 NDC31HJ-330X C CAP. 33pF 50V J
C1824 NDC31HJ-390X C CAP. 39pF 50V J
C1825 QETN1HM-105Z E CAP. 1
µ
F 50V M
C1826 NCB31HK-103X C CAP. 0.01
µ
F 50V K
C1827 NCB31HK-103X C CAP. 0.01µF 50V K
C1830 NDC31HJ-151X C CAP. 150pF 50V J
C1831 QFV71HJ-104Z MF CAP. 0.1µF 50V J
C1832 NCB31HK-103X C CAP. 0.01µF 50V K
C1833 NDC31HJ-680X C CAP. 68pF 50V J
C1834 NDC31HJ-330X C CAP. 33pF 50V J
C1835 NDC31HJ-221X C CAP. 220pF 50V J
C1836 QETN1HM-335Z E CAP 3.3
µ
F 50V M
C1837 QETN1HM-335Z E CAP 3.3µF 50V M
C1838 QETN1HM-335Z E CAP 3.3µF 50V M
C1841 NCB31HK-152X C CAP. 1500pF 50V K
C1843 NCB31HK-103X C CAP. 0.01µF 50V K
C1844 NCB31HK-103X C CAP. 0.01µF 50V K
C1845 NCB31HK-103X C CAP. 0.01µF 50V K
C1846 NCB31HK-103X C CAP. 0.01
µ
F 50V K
C1847 QETN1HM-475Z E CAP. 4.7
µ
F 50V M
!
Symbol No. Part No. Part Name Description
CAPACITOR
C1848 NCB31HK-103X C CAP. 0.01
µ
F 50V K
C1849 NCB31HK-103X C CAP. 0.01µF 50V K
C1852 NCB31HK-103X C CAP. 0.01µF 50V K
C1853 NCB31HK-103X C CAP. 0.01µF 50V K
C1854 QETN1CM-107Z E CAP. 100µF 16V M
C1855 QETN1HM-106Z E CAP. 10µF 50V M
C1856 NCB31HK-104X C CAP. 0.1µF 50V K
!
C1901 QFZ9078-224 MP F CAP 0.22µF AC275V M
!
C1904 QCZ9015-102 C CAP. 1000pFAC250V Z
! C1905 QCZ9015-102 C CAP. 1000pFAC250V Z
! C1907 QCZ9015-102 C CAP. 1000pFAC250V Z
C1909 QEZ0552-127 E CAP. or QEZ0199-127 120µF 400V M
! C1910 QFZ9078-473 MP F CAP 0.047µF AC275V M
C1922 QFLC1HJ-104Z M CAP. 0.1
µ
F 50V J
C1924 QETN1HM-475Z E CAP. 4.7µF 50V M
C1925 QETN1VM-476Z E CAP 47µF 35V M
C1926 QFLC1HJ-332Z M CAP. 3300pF 50V J
C1929 QFKA2JK-103 MM CAP 0.01µF 630V K
C1931 QCZ0364-681 C CAP 680pF 2KV K
C1932 NDC31HJ-681X C CAP. 680pF 50V J
C1941 QCZ0364-561 C CAP 560pF 2KV K
C1942 QEZ0203-107 E CAP. 100
µ
F 160V M
C1944 QCB32HK-222Z C CAP. 2200pF 500V K
C1945 QEHR1EM-108Z E CAP. 1000µF 25V M
C1946 QETN1EM-108Z E CAP. 1000µF 25V M
C1947 QCB32HK-222Z C CAP. 2200pF 500V K
C1948 QETN1EM-108Z E CAP. 1000
µ
F 25V M
C1949 NDC31HJ-471X C CAP. 470pF 50V J
C1976 QETN1EM-227Z E CAP. 220
µ
F 25V M
C1977 QETN1CM-227Z E CAP. 220µF 16V M
C1978 QETN1EM-227Z E CAP. 220µF 25V M
C1979 QETN1AM-227Z E CAP. 220µF 10V M
!
C1991 QCZ9079-102 C CAP. 1000pFAC250V M
!
C1992 QCZ9079-102 C CAP. 1000pFAC250V M
!
C1993 QCZ9079-222 C CAP. 2200pFAC250V M
TRANSFORMER
T1501 QQR1244-001 DRIVE TRANSF
! T1522 QQH0131-001 F B T
! T1921 QQS0161-001 SW TRANSF
COIL
L1001 QQL244K-8R2Z COIL 8.2
µ
H K
L1101 QQL244J-2R2Z COIL 2.2µH J
L1103 QQL244K-8R2Z COIL 8.2µH K
L1551 QQLZ034-670 HEATER CHOKE
L1701 QQL244J-5R6Z COIL 5.6µH J
L1821 NQL092K-4R7X CHIP INDUCTOR
L1822 NQL092K-4R7X CHIP INDUCTOR
L1823 NQL092K-4R7X CHIP INDUCTOR
L1824 NQL092K-4R7X CHIP INDUCTOR
L1825 NQL092K-4R7X CHIP INDUCTOR
L1826 NQL092K-4R7X CHIP INDUCTOR
L1827 NQL092K-4R7X CHIP INDUCTOR
L1828 QQL244K-8R2Z COIL 8.2µH K
L1941 QQL26AK-820Z COIL 82µH K
L1942 QQL244J-4R7Z COIL
L1943 QQL244J-4R7Z COIL
DIODE
D1001 MTZJ33A-T2 ZENER DIODE
D1102 MA859-T2 SI DIODE
D1301 MTZJ9.1B-T2 ZENER DIODE
D1302 MTZJ9.1B-T2 ZENER DIODE
D1305 AK04-T2 DIODE
D1306 QRE121J-121Y C R 120Ω 1/2W J
D1341 MA111-X CHIP DIODE
D1372 MA111-X CHIP DIODE
D1373 MA111-X CHIP DIODE
D1421 MTZJ75-T2 ZENER DIODE
D1423 1SR124-400A-T2 SI DIODE
D1425 MA111-X CHIP DIODE
D1427 MTZJ27B-T2 ZENER DIODE
D1501 MTZJ6.8C-T2 ZENER DIODE
D1551 RGP10J-5025-T3 SI DIODE
