JVC AV-21DMT3 User Manual

No. 52023
A
V-21DMT
3
41
!
Symbol No. Part No. Part Name Description
DIODE
D1552 RGP10J-5025-T3 SI DIODE
D1553 MTZJ9.1B-T2 ZENER DIODE
D1554 MA111-X CHIP DIODE
D1557 1SR124-400A-T2 SI DIODE
D1571 MTZJ7.5S-T2 ZENER DIODE
D1581 MTZJ20B-T2 ZENER DIODE
D1582 RGP10J-5025-T3 SI DIODE
D1651 MA111-X CHIP DIODE
D1652 MTZJ12C-T2 ZENER DIODE
D1653 MA111-X CHIP DIODE
D1654 MTZJ12C-T2 ZENER DIODE
D1655 MA111-X CHIP DIODE
D1656 MA111-X CHIP DIODE
D1657 MA111-X CHIP DIODE
D1701 MA111-X CHIP DIODE
D1704 SLR-342VR-T16 L E D (RED)
D1705 SLR-342DU-T16 L E D (ORG)
D1707 MA111-X CHIP DIODE
D1731 MA111-X CHIP DIODE
D1801 MA111-X CHIP DIODE
! D1901 G2SBA60 BRIDGE DIODE
D1921 RGP10J-5025-T3 SI DIODE
D1925 RGP10J-5025-T3 SI DIODE
D1927 MTZJ36A-T2 ZENER DIODE
D1928 MTZJ3.3A-T2 ZENER DIODE
D1929 MTZJ3.3A-T2 ZENER DIODE
D1930 RGP10M-5010-T3 SI DIODE
D1931 MA111-X CHIP DIODE
D1933 MTZJ16C-T2 ZENER DIODE
D1941 RU3AM-LFC4 SI DIODE
D1942 RU3YX-LFC4 SI DIODE
D1943 RGP10J-5025-T3 SI DIODE
D1982 MA111-X CHIP DIODE
D1983 MA111-X CHIP DIODE
TRANSISTOR
Q1102 2SC5083/L-P/-T SI TRANSISTOR
Q1103 UN2212-X DIGI TRANSISTOR
Q1161 2SD601A/QR/-X CHIP TRANSISTOR
Q1301 2SB709A/QR/-X CHIP TRANSISTOR
Q1302 2SD601A/QR/-X CHIP TRANSISTOR
Q1351 STC344-T SI TRANSISTOR
Q1352 STC344-T SI TRANSISTOR
Q1353 STC344-T SI TRANSISTOR
Q1371 2SD601A/QR/-X CHIP TRANSISTOR
Q1372 2SD601A/QR/-X CHIP TRANSISTOR
Q1373 2SD601A/QR/-X CHIP TRANSISTOR
Q1401 DTC124ESA-T DIGI TRANSISTOR
Q1402 2SD601A/QR/-X CHIP TRANSISTOR
Q1403 2SD601A/QR/-X CHIP TRANSISTOR
Q1404 2SD601A/QR/-X CHIP TRANSISTOR
Q1521 2SC2655/Y/-T SI TRANSISTOR
!
Q1522 2SD2627-YB11 POWER TRANSISTOR H.OUT
Q1571 2SA1208/ST/Z1-T SI TRANSISTOR
Q1572 2SD601A/QR/-X CHIP TRANSISTOR
Q1651 2SD601A/QR/-X CHIP TRANSISTOR
Q1652 2SD601A/QR/-X CHIP TRANSISTOR
Q1653 2SB709A/QR/-X CHIP TRANSISTOR
Q1702 2SD601A/QR/-X CHIP TRANSISTOR
Q1703 UN2212-X DIGI TRANSISTOR
Q1708 UN2212-X DIGI TRANSISTOR
Q1709 2SB709A/QR/-X CHIP TRANSISTOR
!
Symbol No. Part No. Part Name Description
TRANSISTOR
Q1803 2SC1815/YG/-T SI TRANSISTOR
Q1804 2SD601A/QR/-X CHIP TRANSISTOR
Q1821 2SB709A/QR/-X CHIP TRANSISTOR
Q1822 2SD601A/QR/-X CHIP TRANSISTOR
Q1824 2SD601A/QR/-X CHIP TRANSISTOR
Q1825 UN2212-X DIGI TRANSISTOR
Q1826 2SC5083/L-P/-T SI TRANSISTOR
Q1974 2SA966/OY/-T SI TRANSISTOR
Q1975 UN2212-X DIGI TRANSISTOR
IC
IC1301 NN5198K I C
IC1371 TC4053BP/N/ I C
IC1421 AN5522 I C
IC1651 AN5265 I C
IC1701 MN1873287JJ1 I C
IC1702 AT24C08-21DMG3 I C (SERVICE)
IC1703 L78LR05E-MA I C
IC1704 PIC-47143SY IR DETECT UNIT
IC1821 SDA5553-V006 I C
IC1822 PQ2L3252MS-X REGULATOR
IC1921 STR-W5753A/F5 I C
IC1971 BA17809T I C
IC1972 BA17805T I C
OTHERS
LC30114-001C-H LED HOLDER
CF1161 QAX0642-001Z C FILTER
! CP1981 ICP-N25-Y IC PROTEC
!
CP1982 ICP-N75-Y IC PROTEC
!
F1901 QMF51E2-3R15J4 FUSE 3.15A
FC1901 CEMG002-001Z FUSE CLIP
FR1557 QRJ146J-2R2X C R 2.2
Ω
1/4W J
J1002 QNN0384-001 PIN JACK
J1003 QNN0281-003 PIN JACK or CEMN065-001
J1004 QNN0281-002 PIN JACK or CEMN065-002
J1005 QNS0197-001 3.5 JACK
K1351 QQR0621-002Z BEADS CORE
K1421 QQR1113-001Z FERRITE BEADS
K1941 QQR1113-001Z FERRITE BEADS
K1942 QQR1113-001Z FERRITE BEADS
K1943 QQR1113-001Z FERRITE BEADS
!
LF1901 QQR0527-002 LINE FILTER
PC1701 P1241-04 C D S
S1701 QSW0619-003Z PUSH SWITCH VOL+
S1702 QSW0619-003Z PUSH SWITCH VOL-
S1703 QSW0619-003Z PUSH SWITCH CH+
S1704 QSW0619-003Z PUSH SWITCH CH-
S1705 QSW0619-003Z PUSH SWITCH MENU
! S1901 QSW0750-001 PUSH SWITCH POWER SW
SF1102 QAX0731-001 SAW FILTER
SF1122 QAX0325-001 SAW FILTER
!
SK1351 QNZ0537-001 CRT SOCKET or QNZ0536-001
!
TH1901 QAD0121-9R0 P THERISTOR or QAD0119-9R0
TU1001 QAU0282-001 TUNER
! VA1901 ERZV10V621CS Z N R or QAF0052-621
X1301 QAX0705-001Z CRYSTAL
X1302 CE41651-001Z CRYSTAL
X1701 QAX0307-001 CER R ESONATOR
X1821 QAX0669-001Z CRYSTAL
[ AV-21DMT3 ]
