PARTS LIST
CAUTION
! The parts identified by the ! symbol ar e import ant for t he s afe ty. W h ene ver rep lacing the se par ts, be s ure t o use s pec if ied o nes to se cure
the safety .
!
The pa rts n ot indic ate d in th is P arts List a nd tho se which are filled with lines in the Parts No. columns will not be supplied.
! P. W. Board Ass'y will not be supplied, but those which are filled with the Parts No. in the Parts No. columns will be supplied.
ABBREVIATIONS OF RESISTORS, CAPACITORS AND TOLERANCES
RESISTORS CAPACITORS
C R Carbon Resistor C CAP. Ceramic Capacitor
F R Fusible Resistor E CAP. Electrolytic Capacitor
P R Plate Resistor M CAP. Mylar Capacitor
V R Variable Resisto
r
HV CAP. High Voltage Capacitor
HV R High Voltage Resistor MF CAP. Metalized Film Capacitor
MF R Metal Film Resistor MM CAP. Metalized Mylar Capacitor
MG R Metal Glazed Resistor MP CAP. Metalized Polystyrol Capacitor
MP R Metal Plate Resisto r PP CA P. Po lypropylen e Ca pa cit or
OM R M etal Oxide Film Resistor PS CA P. Polystyrol Capacitor
CMF R Coating Metal Film Resistor TF CAP. Thin Film Capacitor
UNF R Non-Flam m able Resisto r MPP CAP . Metalize d P olyprop ylene Capacitor
CH V R Chip Variable Resistor TAN. CAP. Tantalum Capacitor
CH MG R Chip Metal Glazed Resistor CH C CAP. Chip Ceramic Capacitor
COMP . R Composit ion Resist or BP E CAP . Bi-Pola r Electrolytic Ca pacit or
LP TC R
Linear P ositive T emp er at ure Co eff icie nt
Resistor
CH AL E CAP. Chip Aluminum Electrolytic Capacitor
CH AL BP CA P.
Chip A luminum B i-Polar Cap acitor
CH TAN. E CAP.
Chip T ant alum Elec trolytic Cap acitor
CH AL BP E CAP.
Chip T ant alum Bi-Polar Electro lyt ic Ca pac it or
TOLERANCES
FGJKMNRHZ P
±1% ±2% ±5% ±10% ±20 % ±30 %
+30%
-10%
+50%
-10%
+80%
-20%
+100 %
-0%
