JVC AV29A10EUS - Page 20

No. 51818
AV29A10EUS
20
(3)
Setting methods
"
Method of Setting 1.IF as [VCO] : It must not adjust without signal.
(
1 Key
!!!!!!!!!!!!!!!!!!!!!!!!!
Select 1.IF.
)
1 Key
!!!!!!!!!!!!!!!!!!!!!!!!
Select 1. VCO (CW)
Check the arrow position from the “ABOVE REF.” to “BELOW REF.”
*
INFORMATION Key
!!!!!!!!!!!!
Return to the SERVICE MENU screen.
"
Method of setting
2.V/C, 3.AUDIO, 4.DEF
and
5.VSM PRESET.
(
2
#
5 Key
!!!!!!!!!!!!!!!!!!!!!!
Select one from
2. V/C, 3. AUDIO, 4. DEF
and
5. VSM PRESET
.
)
FUNCTION UP/DOWN Key
!!!!!
Select setting items.
*
FUNCTION LEFT/RIGHT Key
!!!!
Set (adjust) the setting values of the setting items.
+
MENU (OK) Key
!!!!!!!!!!!!!!!
Memorize the setting value.
(Before storing the setting values in memory, do not press the CH, TV, POWER ON / OFF key -
if you do, the values will not be stored in memory.)
,
INFORMATION Key
!!!!!!!!!!!!
Return to the
SERVICE MENU
screen.
"
Do not adjust
6. STATUS, 7. PIP, 8. --- , 9. SHIPPING(ON)
and
0. BUS FREE
functions
.
(4)
Release of SERVICE MENU
1) After completing the adjustment, return to the SERVICE MENU, then again press the INFORMATION (OK) key to return to the normal
screen.
