JVC AV29A10EUS User Manual

No. 51818
AV29A10EUS
19
COOL
NORMAL
WARM
1. RGB BLK
2. WDR R
3. WDR G
4. WDR B
5. BRIGHT
6. CONTRAST
7. COLOUR
8. HUE
9. SHARP
10.VCO ADJUSTMENT
11. VIDEO AGC
12. SYNC SLICE
1.ERR LIMIT
2. A2 ID THR
SERVICE MENU
SERVICE MENU
1. IF 2. V/C
3. AUDIO 4. DEF
5. VSM PRESET 6. STATUS
7. PIP 8.
---
9. SHIPPING(ON) 0. BUS FREE
1-9 : SELECT i : EXIT
SUB MENU 5. VSM PRESET
VSM PRESET NORMAL
- / +
: STORE i : EXIT
OK
SUB MENU 3. AUDIO (Do not adjust)
DEF FULL
**
****
**
Hz
1. V-SHIFT
SUB MENU 4. DEF
***
(
**
)
- / +
: STORE i : EXIT
OK
1. V-SHIFT
2. V-SIZE
3. H-CENT
4. H-SIZE
5. TRAPEZ
6. EW-PIN
7. COR-PIN
8. COR-UP
9. COR-LO
10. ANGLE
11. BOW
12. V-S.CR
13. V.LIN
1. CONT.
2. BRIGHT
3. SHARP
4. COLOUR
5. HUE
6. WDR R
7. WDR G
8. WDR B
IF SERVICE MENU
1. VCO
2. ATT ON/OFF
1-2 : SELECT i : EXIT
VCO (CW)
**
****
**.
..
.**
****
**
MHz
MAIN
TOO HIGH
ABOVE REF
JUST REF
BELOW REF
TOO LOW
i : EXIT
SUB MENU 1.IF (VCO)
V/C
1. RGB. BLK
****
SUB MENU 2. V/C
PAL
- / +
: STORE i : EXIT
OK
AUDIO
1. ERR LIMIT 0AH
C AD BITS =
********
- / +
: STORE i : EXIT
OK
1.CONT.
***
SUB MENU 1.IF
Do not select it.
Fig.3 SUB MENU SCREEN
1-0
