Warnings, Cautions and Others
Caution –– switch!
Disconnect the mains plug to shut the power off completely (the
STANDBY/ON lamp goes off).
The switch in any position does not disconnect the mains line.
• When the unit is on standby, the STANDBY/ON lamp lights red.
• When the unit is turned on, the STANDBY/ON lamp lights
green.
The power can be remote controlled.
CAUTION
To reduce the risk of electrical shocks, fire, etc.:
1. Do not remove screws, covers or cabinet.
2. Do not expose this appliance to rain or moisture.
Caution: Proper Ventilation
To avoid risk of electric shock and fire, and to prevent damage,
locate the apparatus as follows:
1 Front:
No obstructions and open spacing.
2 Sides/ Top/ Back:
No obstructions should be placed in the areas shown by the
dimensions below.
3 Bottom:
Place on the level surface. Maintain an adequate air path for
ventilation by placing on a stand with a height of 10 cm or
more.
The STANDBY/ON lamp
1BIT P•E•M D•D•CONVERTER
MICRO COMPONENT SYSTEM UX-G6R
MOS - FET
OPEN/CLOSE
AUX
VOLUMEMULTI
FM/AM
STANDBY/ON
JOG
– G-1 –
Front view Side view
1 cm
15 cm
15 cm 15 cm
10 cm
1 cm
15 cm 15 cm
AX-UXG6
TD-UXG6
XT-UXG6R
XM-G6
AX-UXG6
TD-UXG6
XT-UXG6R
XM-G6
