JVC CA-DXT77 User Manual

3-30
Primary board (DX-T99)
Block No. [0][3]
R5021 QRE141J-272Y C RESISTOR 2.7k Ω 1/4W J
R5022 QRE141J-392Y C RESISTOR 3.9k Ω 1/4W J
R5023 QRE141J-562Y C RESISTOR 5.6k Ω 1/4W J
R5024 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R5025 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R5026 QRE141J-122Y C RESISTOR 1.2k
Ω 1/4W J
R5027 QRE141J-182Y C RESISTOR 1.8k
Ω 1/4W J
R5028 QRE141J-222Y C RESISTOR 2.2k Ω 1/4W J
R5029 QRE141J-272Y C RESISTOR 2.7k Ω 1/4W J
R5030 QRE141J-392Y C RESISTOR 3.9k Ω 1/4W J
R5035 QRE141J-161Y C RESISTOR 160 Ω 1/4W J
R5036 QRE141J-161Y C RESISTOR 160 Ω 1/4W J
R5037 QRE141J-560Y C RESISTOR 56 Ω 1/4W J
R5038 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R5039 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R5040 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R5041 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R5042 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R5043 QRE141J-271Y C RESISTOR 270 Ω 1/4W J
R5044 QRE141J-821Y C RESISTOR 820 Ω 1/4W J
R5045 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
R5046 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
R5050 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
L3401 QQLZ035-R39 COIL 0.39uH
L3501 QQLZ035-R39 COIL 0.39uH
L3601 QQLZ035-R39 COIL 0.39uH
L4101 QQLZ035-R39 COIL 0.39uH
L4201 QQLZ035-R39 COIL 0.39uH
L4601 QQLZ035-R39 COIL 0.39uH
L4701 QQLZ035-R39 COIL 0.39uH
CN301 QGB2510K2-20 CONNECTOR B-B (1-20)
CN302 QGF1205C2-19 CONNECTOR FFC/FPC (1-19)
CN303 QGF1205F2-11 CONNECTOR FFC/FPC (1-11)
CN304 QGA2501F1-03 CONNECTOR W-B (1-3)
CN401 QGB2510K2-16 CONNECTOR B-B (1-16)
CN402 QGF1205C2-08 CONNECTOR FFC/FPC (1-8)
CN500 QGF1036F2-19 CONNECTOR FFC/FPC (1-19)
CN990 QGB2510J1-06 CONNECTOR B-B (1-6)
FL500 QLF0150-001 FL TUBE
FW301 QUM155-16Z4Z4-E FLAT WIRE
FW401 QUM154-10Z4Z4-E FLAT WIRE
FW500 QUM153-18DGZ4-E FLAT WIRE
J990 QNB0263-001 SPK TERMINAL
S5000 QSW0683-001Z PUSH SW I.M
S5001 QSW0683-001Z PUSH SW I.M
S5002 QSW0683-001Z PUSH SW I.M
S5003 QSW0683-001Z PUSH SW I.M
S5004 QSW0683-001Z PUSH SW I.M
S5005 QSW0683-001Z PUSH SW I.M
S5006 QSW0683-001Z PUSH SW I.M
S5007 QSW0683-001Z PUSH SW I.M
S5008 QSW0683-001Z PUSH SW I.M
S5009 QSW0683-001Z PUSH SW I.M
S5010 QSW0683-001Z PUSH SW I.M
S5011 QSW0683-001Z PUSH SW I.M
S5012 QSW0683-001Z PUSH SW I.M
S5013 QSW0683-001Z PUSH SW I.M
S5014 QSW0683-001Z PUSH SW I.M
S5015 QSW0683-001Z PUSH SW I.M
S5016 QSW0683-001Z PUSH SW I.M
S5017 QSW0683-001Z PUSH SW I.M
S5018 QSW0683-001Z PUSH SW I.M
S5019 QSW0683-001Z PUSH SW I.M
S5020 QSW0683-001Z PUSH SW I.M
S5021 QSW0683-001Z PUSH SW I.M
S5022 QSW0683-001Z PUSH SW I.M
S5023 QSW0683-001Z PUSH SW I.M
S5024 QSW0683-001Z PUSH SW I.M
S5025 QSW0683-001Z PUSH SW I.M
S5026 QSW0683-001Z PUSH SW I.M
S5027 QSW0683-001Z PUSH SW I.M
S5028 QSW0683-001Z PUSH SW I.M
S5029 QSW0683-001Z PUSH SW I.M
S5030 QSW0683-001Z PUSH SW I.M
S5031 QSW0683-001Z PUSH SW I.M
S5032 QSW0683-001Z PUSH SW I.M
 Symbol No. Part No. Part Name Description Local
S5033 QSW0683-001Z PUSH SW I.M
S5034 QSW0683-001Z PUSH SW I.M
SP500 GV40205-004A IC HOLDER
 Symbol No. Part No. Part Name Description Local
IC920 BH7868FS-X IC
IC930 GP1FAV30TK0F OPT TRANSMITTER
Q1000 KTC2026/Y/ TRANSISTOR
Q1001 KTC3203/OY/-T TRANSISTOR
Q2007 KTA1046/Y/ TRANSISTOR
Q2008 KTC3199/GL/-T TRANSISTOR
Q2009 KTC3199/GL/-T TRANSISTOR
Q9300 KRA110M-T TRANSISTOR
Q9301 KRC110M-T TRANSISTOR
Q9303 KTC3199/GL/-T TRANSISTOR
 D1000 1N5402M-20 SI DIODE
 D1001 1N5402M-20 SI DIODE
 D1002 1N5402M-20 SI DIODE
 D1003 1N5402M-20 SI DIODE
 D1004 6A10E2 SI DIODE
 D1005 6A10E2 SI DIODE
 D1006 6A10E2 SI DIODE
 D1007 6A10E2 SI DIODE
 D1008 6A10E2 SI DIODE
 D1009 6A10E2 SI DIODE
 D1010 6A10E2 SI DIODE
 D1011 6A10E2 SI DIODE
D1012 MTZJ6.2B-T2 Z DIODE
D1013 MTZJ18B-T2 Z DIODE
D1014 MTZJ18B-T2 Z DIODE
D1015 1N4003S-T5 SI DIODE
D1016 1N4003S-T5 SI DIODE
D1017 1N4003S-T5 SI DIODE
 D2001 GBU803 BRIDGE DIODE
D2008 2A02-M DIODE
D2009 MTZJ5.1C-T2 Z DIODE
D2013 1SS133-T2 SI DIODE
D9300 2A02-M DIODE
D9301 MTZJ3.3B-T2 Z DIODE
D9302 MTZJ2.0A-T2 Z DIODE
D9303 MTZJ3.9B-T2 Z DIODE
D9310 MTZJ3.0B-T2 Z DIODE
D9311 1SS133-T2 SI DIODE
D9312 1SS133-T2 SI DIODE
D9313 1SS133-T2 SI DIODE
C1002 QETN1HM-226Z E CAPACITOR 22uF 50V M
C1003 QETN1HM-226Z E CAPACITOR 22uF 50V M
C1004 QCBB1HK-103Y C CAPACITOR 0.01uF 50V K
C1005 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1010 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C1011 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C1012 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C1013 QFZ0228-104Z M CAPACITOR 0.1uF
C1014 QFZ0228-104Z M CAPACITOR 0.1uF
C1015 QFZ0228-104Z M CAPACITOR 0.1uF
C1016 QETN2AM-476Z E CAPACITOR 47uF 100V M
C1017 QETN1HM-107Z E CAPACITOR 100uF 50V M
C2000 QEZ0581-688 E CAPACITOR 6800uF
C2004 QEZ0581-688 E CAPACITOR 6800uF
C2006 QEZ0786-688 E CAPACITOR 6800uF
C2008 QEZ0786-688 E CAPACITOR 6800uF
C2009 QFZ0228-104Z M CAPACITOR 0.1uF
C2010 QCBB1HK-103Y C CAPACITOR 0.01uF 50V K
C2011 QCBB1HK-221Y C CAPACITOR 220pF 50V K
C2012 QETM1CM-478 E CAPACITOR 4700uF 16V M
C2013 QETM1EM-688 E CAPACITOR 6800uF 25V M
C9200 QETN1AM-477Z E CAPACITOR 470uF 10V M
 Symbol No. Part No. Part Name Description Local
