JVC CA-DXT77

3-31
Main board (DX-T77)
Block No. [0][4]
C9204 QCBB1HK-103Y C CAPACITOR 0.01uF 50V K
C9206 QETN1HM-105Z E CAPACITOR 1uF 50V M
C9209 QETN1HM-226Z E CAPACITOR 22uF 50V M
C9211 QETN1HM-105Z E CAPACITOR 1uF 50V M
C9213 QETN1HM-105Z E CAPACITOR 1uF 50V M
C9215 QETN1HM-105Z E CAPACITOR 1uF 50V M
C9216 QCBB1HK-104Y C CAPACITOR 0.1uF 50V K
C9218 QETN0JM-477Z E CAPACITOR 470uF 6.3V M
C9221 QETN0JM-477Z E CAPACITOR 470uF 6.3V M
C9224 QETN0JM-477Z E CAPACITOR 470uF 6.3V M
C9227 QETN0JM-477Z E CAPACITOR 470uF 6.3V M
C9230 QETN0JM-477Z E CAPACITOR 470uF 6.3V M
C9232 QCBB1HK-103Y C CAPACITOR 0.01uF 50V K
C9300 QETN1CM-107Z E CAPACITOR 100uF 16V M
C9303 QETN1CM-107Z E CAPACITOR 100uF 16V M
 R1000 QRK126J-470X UNF C RESISTOR 47 Ω 1/2W J
R1001 QRE141J-753Y C RESISTOR 75k Ω 1/4W J
R1002 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R1003 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R1005 QRE141J-753Y C RESISTOR 75k
Ω 1/4W J
R2000 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
R2001 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R2002 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R2003 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R2004 QRE141J-681Y C RESISTOR 680 Ω 1/4W J
R2005 QRE141J-272Y C RESISTOR 2.7k Ω 1/4W J
R2006 QRE141J-681Y C RESISTOR 680 Ω 1/4W J
R2007 QRE141J-472Y C RESISTOR 4.7k Ω 1/4W J
R2008 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R2009 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R2010 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R2011 QRL01DJ-471X OMF RESISTOR 470 Ω 1W J
R2012 QRL01DJ-471X OMF RESISTOR 470 Ω 1W J
R2013 QRE141J-273Y C RESISTOR 27k Ω 1/4W J
R9201 QRE141J-431Y C RESISTOR 430 Ω 1/4W J
R9202 QRE141J-391Y C RESISTOR 390 Ω 1/4W J
R9203 QRE141J-391Y C RESISTOR 390 Ω 1/4W J
R9204 QRE141J-131Y C RESISTOR 130 Ω 1/4W J
R9205 QRE141J-391Y C RESISTOR 390 Ω 1/4W J
R9206 QRE141J-131Y C RESISTOR 130 Ω 1/4W J
R9207 QRE141J-391Y C RESISTOR 390 Ω 1/4W J
R9208 QRE141J-431Y C RESISTOR 430 Ω 1/4W J
R9209 QRE141J-391Y C RESISTOR 390 Ω 1/4W J
R9210 QRE141J-431Y C RESISTOR 430 Ω 1/4W J
R9218 QRE141J-750Y C RESISTOR 75 Ω 1/4W J
R9221 QRE141J-750Y C RESISTOR 75 Ω 1/4W J
R9224 QRE141J-750Y C RESISTOR 75 Ω 1/4W J
R9227 QRE141J-750Y C RESISTOR 75 Ω 1/4W J
R9230 QRE141J-750Y C RESISTOR 75
Ω 1/4W J
R9232 QRE141J-750Y C RESISTOR 75 Ω 1/4W J
R9300 QRT01DJ-2R2X MF RESISTOR 2.2
Ω 1W J
R9301 QRE141J-681Y C RESISTOR 680
Ω 1/4W J
R9302 QRZ9006-4R7X FUSI RESISTOR 4.7 Ω
R9303 QRE141J-271Y C RESISTOR 270 Ω 1/4W J
R9310 QRE141J-470Y C RESISTOR 47
Ω 1/4W J
CN100 QGA7901C1-02 CONNECTOR W-B (1-2)
CN101 QGA7901C1-04 CONNECTOR W-B (1-4)
CN102 QGA7901C1-03 CONNECTOR W-B (1-3)
CN103 QGA3901F1-08 CONNECTOR W-B (1-8)
CN104 QGB2510J1-13 CONNECTOR B-B (1-13)
CN105 QGD2503F1-03 CONNECTOR (1-3)
CN106 QGA3901F2-03 CONNECTOR W-B (1-3)
CN200 QGB2510J1-16 CONNECTOR B-B (1-16)
CN201 QGB2510J1-20 CONNECTOR B-B (1-20)
CN202 QGD2504C1-03Z CONNECTOR (1-3)
CN203 QGB2510K2-15 CONNECTOR B-B (1-15)
CN204 QGB2510K2-13 CONNECTOR B-B (1-13)
CN920 QGF1205C2-08 CONNECTOR FFC/FPC (1-8)
CN930 QGF1036C2-28 CONNECTOR FFC/FPC (1-28)
CN931 QGF1205C2-11 CONNECTOR FFC/FPC (1-11)
H2001 GV40577-001A HEAT SINK
HS202 GV40620-003A HEAT SINK
IH920 GV40397-004A IC HOLDER
J920 QNN0572-001 PIN JACK
J921 QNN0557-002 PIN JACK
PP201 QZW0112-001 WIRE CLAMP
 Symbol No. Part No. Part Name Description Local
PP202 QZW0112-001 WIRE CLAMP
 S1000 QSW0812-001 VOLTAGE SWITCH
Z1001 QNG0003-001Z FUSE CLIP
Z1002 QNG0003-001Z FUSE CLIP
Z1003 QNG0003-001Z FUSE CLIP
Z1004 QNG0003-001Z FUSE CLIP
Z1005 QNG0003-001Z FUSE CLIP
Z1006 QNG0003-001Z FUSE CLIP
Z1007 QNG0003-001Z FUSE CLIP
Z1008 QNG0003-001Z FUSE CLIP
Z1009 QNG0003-001Z FUSE CLIP
Z1010 QNG0003-001Z FUSE CLIP
Z1011 QNG0003-001Z FUSE CLIP
Z1012 QNG0003-001Z FUSE CLIP
Z1013 QNG0003-001Z FUSE CLIP
Z1014 QNG0003-001Z FUSE CLIP
Z1015 QNG0003-001Z FUSE CLIP
Z1016 QNG0003-001Z FUSE CLIP
Z1017 QNG0003-001Z FUSE CLIP
Z1018 QNG0003-001Z FUSE CLIP
Z1019 QNG0003-001Z FUSE CLIP
Z1020 QNG0003-001Z FUSE CLIP
 Symbol No. Part No. Part Name Description Local
IC760 SN74AHCT08NS-X IC
IC770 MN101C49GFA MASK MICON
IC771 BR24L02F-W-X IC(DIGITAL)
IC800 RC4558D-X IC
IC801 RC4558D-X IC
IC810 CD4066BM-X IC
IC820 LC75342M-X IC
IC830 RC4558D-X IC
IC850 M65851FP IC
IC860 JCV8011-X IC
IC870 LC75342M-X IC
IC880 LC75342M-X IC
IC881 RC4558D-X IC
IC888 RC4558D-X IC
IC901 RC4580ID-X IC
Q7000 KTC3199/GL/-T TRANSISTOR
Q7010 KTC3199/GL/-T TRANSISTOR
Q7080 KRC107S-X DIGI TRANSISTOR
Q7081 KRC111S-X TRANSISTOR
Q7788 KRA102S-X DIGI TRANSISTOR
Q7794 KRA102S-X DIGI TRANSISTOR
Q7798 KRA102S-X DIGI TRANSISTOR
Q8000 KTC2875-X CHIP TR.
Q8030 KTC3875/YG/-X TRANSISTOR
Q8031 KTC3875/YG/-X TRANSISTOR
Q8032 KTC3875/YG/-X TRANSISTOR
Q8040 KTC2875-X CHIP TR.
Q8070 KTC2875-X CHIP TR.
Q8071 KTC2875-X CHIP TR.
Q8080 KTC2875-X CHIP TR.
Q8081 KTC2875-X CHIP TR.
Q8100 KTC2875-X CHIP TR.
Q8130 KTC3875/YG/-X TRANSISTOR
Q8131 KTC3875/YG/-X TRANSISTOR
Q8132 KTC3875/YG/-X TRANSISTOR
Q8140 KTC2875-X CHIP TR.
Q8170 KTC2875-X CHIP TR.
Q8171 KTC2875-X CHIP TR.
Q8180 KTC2875-X CHIP TR.
Q8211 KRC104S-X TRANSISTOR
Q8212 KRC104S-X TRANSISTOR
Q8260 KTC3199/GL/-T TRANSISTOR
Q8401 KRC109S-X TRANSISTOR
Q8524 KTC3203/OY/-T TRANSISTOR
Q8900 KRA104S-X DIGI TRANSISTOR
 Symbol No. Part No. Part Name Description Local
