33
English
Center unit section – CA-MXJ777V/MXJ787V
Amplifier
Output Power
Front:
75 watts per channel, min. RMS, both channels driven into 6
ohms at 1 kHz with no more than 0.9% total harmonic
distortion.
Center:
25 watts, min. RMS, driven into 8 ohms at 1 kHz with no more
than 0.9% total harmonic distortion.
Rear:
12.5 watts per channel, min. RMS, both channels driven into
16 ohms at 1 kHz with no more than 0.9% total harmonic
distortion.
Audio input sensitivity/Impedance (at 1 kHz)
AUX: 380 mV/50 kohms
MIC 1/2: 2.5 mV/5 kohms
Audio output level:
AUX: 300 mV
Digital output: CD OPTICAL DIGITAL OUTPUT
Signal wave length: 660 nm
Output level: –21 to –15 dBm
Speakers/Impedance:
Front: 6 – 16 ohms
Center: 8 – 16 ohms
Rear: 16 – 32 ohms
Tuner
FM tuning range: 87.50 – 108.00 MHz
AM tuning range:
For Saudi Arabia:
At 9 kHz intervals : 531 – 1,602 kHz
At 10 kHz intervals : 530 – 1,600 kHz
For other countries:
At 9 kHz intervals : 531 – 1,710 kHz
At 10 kHz intervals : 530 – 1,710 kHz
CD player
CD Capacity: 3 CDs
Dynamic range: 85 dB
Signal-to-noise ratio: 90 dB
Wow and flutter: Immeasurable
Cassette deck
Frequency response
Normal (type I): 50 – 14,000 Hz
CrO2 (type II): 50 – 14,000 Hz
Metal (type IV): 50 – 14,000 Hz (only for playback)
Wow and flutter: 0.15% (WRMS)
General
Power requirement: AC 110/127/220/230-240 V
(adjustable with the voltage selector),
50 / 60 Hz
Power consumption: 140 watts (at operation)
14 watts (at standby mode)
Maximum power consumption (for Taiwan only): 450 watts
Dimensions (approx.): 265 x 315 x 341 mm (W/H/D)
(10
7
/16 x 12
7
/16 x 13
7
/16 in.)
Mass (approx.): 9.8 kg (21.6 lbs)
Colour
CA-MXJ777V Silver colour model
CA-MXJ787V Gold colour model
Supplied accessories
See page 3.
Design and specifications are subject to change without notice.
SpecificationsSpecifications
EN26-33;MX-J777V/PM6 7/8/99, 9:15 AM33
