JVC CA-MXJD8

57
English
Specifications
CA-MXJD5
Amplifier section
Output Power:
FRONT MAIN SPEAKERS: 40 W per channel, min. RMS,
driven into 6 Ω at 1 kHz with
no more than
10% total
harmonic distortion.
FRONT SUBWOOFERS: 80 W per channel, min. RMS,
driven into 6 Ω at 63 Hz with
no more than
10% total
harmonic distortion.
CENTER SPEAKER: 40 W, min. RMS, driven into
8 Ω at 1 kHz with no more
than
10% total harmonic
distortion.
SURROUND SPEAKERS: 25 W per channel, min. RMS,
driven into 16 Ω at 1 kHz with
no more than
10% total
harmonic distortion.
Digital output:
OPTICAL DIGITAL OUTPUT:
–21 dBm to –15 dBm (660 nm ±30 nm)
Audio input sensitivity/Impedance
(Measured at 1 kHz, with tape recording signal 300 mV)
AUX IN: 300 mV/47 k Ω
MIC 1/2: 3.0 mV/50 k Ω
VIDEO OUT:
Color system:NTSC/PAL selectable
VIDEO (composite): 1 V(p-p)/75 Ω
S-VIDEO: Y (luminance) 1 V(p-p)/75 Ω
C (chrominance, burst)
0.286 V(p-p)/75 Ω
COMPONENT (Interlace/Progressive):
(Y) 1 V(p-p)/75 Ω
(P
B /P R ) 0.7 V(p-p)/75 Ω
Speaker Terminals: 6 Ω − 16 Ω (Front main speakers)
8 Ω − 16 Ω (Center speakers)
16 Ω − 32 Ω (Surround speakers)
6 Ω − 16 Ω (Front subwoofers)
Others:
AV COMPU LINKx2 ( φ 3.5)
Tuner section
FM tuning range: 87.50 MHz – 108.00 MHz
AM (MW) tuning range:
531 kHz – 1 710 kHz (at 9 kHz)
530 kHz – 1 710 kHz
(at 10 kHz)
Disc player section
Playable disc: DVD Video/DVD Audio/CD/VCD/SVCD
CD-R/CD-RW (recorded in Audio CD/
Video CD/ Super Video CD/ MP3/ WMA/
JPEG/MPEG-4 format)
DVD-R/DVD-RW (recorded in video
format)
Dynamic range: 90 dB
Horizontal resolution: 500 lines
Wow and flutter: Immeasurable
Cassette deck section
Frequency response
Normal (type I): 50 Hz – 14 000 Hz
Wow and flutter: 0.15% (WRMS)
General
Power requirement: AC 110 V / AC 127 V / AC 220 V /
AC 230 V – AC 240 V ,
(adjustable with the voltage selector),
50 Hz / 60 Hz
Power consumption: 220 W (at operation)
20 W (on standby)
Dimensions (approx.):265 mm x 335 mm x 352 mm
(W/H/D)
Mass (approx.): 8.7 kg
Supplied Accessories
See page 3.
Design and specifications are subject to change without
notice.
