13
1
Surround Mode/Source signal indicators
• Surround Mode indicators: light to indicate the current
activated speaker.
• L/C/R/LFE/LS/S/RS: light to indicate the current source
signal.
2
TITLE indicator
• Lights to indicate the title number when the source is
DVD Video.
• Lights to indicate the group title or track title when MP3/
WMA/JPEG/MPEG-4 title is shown on the main display.
3
GROUP indicator
• Lights to indicate the group number when the source is
DVD Audio or MP3/WMA/JPEG/MPEG-4 disc.
4
CHAP. indicator
• Lights to indicate the chapter number when the source is
DVD Video.
5
TRACK indicator
• Lights to indicate the track number when the source is a
disc (except for DVD Video).
6
MP3 indicator
• Lights while playing back an MP3 track.
7
WMA indicator
• Lights while playing back a WMA track.
8
JPEG indicator
• Lights while playing back a JPEG file.
9
LPCM indicator
• Lights when a source signal is linear PCM.
p
FM reception indicators
• MONO: lights while receiving an FM stereo station in
monaural.
• ST (stereo): lights while an FM stereo station with
sufficient signal strength is tuned in.
q
Animation indicator
w
DVD AUDIO indicator
• DVD: lights when DVD Video is detected.
• DVD AUDIO: lights when DVD Audio is detected.
e
Source signal indicators
• DIGITAL: lights when a source signal is Dolby
Digital.
• DTS: lights when a source signal is DTS Surround.
• MPEG: lights when a source signal is MPEG
multichannel.
r
Main display
t
SURR. indicators
• Lights when Surround mode is activated.
y
Dolby Pro Logic II indicator
• PL II: lights when Dolby Pro Logic II mode is
activated.
• MOVIE: lights when Dolby Pro Logic II Movie is
activated.
• MUSIC: lights when Dolby Pro Logic II Music is
activated.
u
SOUND indicators
• Lights when SEA mode or USER mode is activated.
i
RESUME indicator
• Lights when the Resume function is activated (see
page 16).
o
BONUS indicator
• Lights when DVD Audio with bonus group is detected
(see page 26).
;
PROGRESSIVE indicator
• Lights when the progressive scanning mode is selected.
a
B.S.P. indicator
• Lights when browsable still picture on DVD Audio is
available (see page 25).
s
Karaoke operation indicators
• MIC: lights when the mic mixing mode is activated (see
page 37).
• ECHO: lights when the echo effect is activated (see
page 38).
• KARAOKE: lights when the Karaoke mode is activated
(see page 38).
d
DVD LEVEL 1/2/3 indicators
• Lights when the DVD Video is detected.
f
Disc operation indicators
• PRGM.: lights when Program Play mode is activated.
• RND.: lights when Random Play is activated.
• REPEAT: lights when Repeat Play mode is activated.
• ALL: lights when All Disc Repeat is activated.
• 1: lights when One Track/Chapter/Step Repeat is
activated.
g
Tape operation indicators
• TAPE: lights when a tape is loaded in either A or B.
• (reverse mode):
–: tape play continues endlessly.
–: tape automatically reverses once.
–: tape play stops at the end of one side.
• A: lights when a tape is loaded in the deck A.
• B: lights when a tape is loaded in the deck B.
• REC: lights while recording.
•
2
3
(tape direction):
– Lights to indicate the current tape running direction.
– Flashes slowly during playback and recording.
– Flashes quickly while rewinding a tape.
h
Timer indicators
•: lights when Sleep Timer is working or Daily Timer
or Recording Timer stands by or is working or setting.
• SLEEP: flashes when the Sleep Timer is activated.
• DAILY: lights when the Daily Timer stands by; flashes
while working or setting.
• REC: lights when the Recording Timer stands by; flashes
while working or setting.
MX-JD5&8[UX].book Page 13 Monday, April 26, 2004 2:22 PM
