(MB685-R002) 3
PARTS LIST
MODEL No. LIST
Model No.No.MB685<Rev.002>
NX-G3A 0D
NX-G3UB 0F
NX-G3UG 10
NX-G3UH 12
NX-G3UN 11
NX-G3UP 1F
NX-G3US 0E
NX-G3UT 20
NX-G3UX 21
NX-G5A 1A
NX-G5E 19
NX-G5UB 1B
NX-G5UG 0B
NX-G5UH 1E
NX-G5UN 0C
NX-G5US 0A
NX-G5UT 1C
NX-G5UX 1D
NX-G7A 06
NX-G7EE 16
NX-G7UF 17
NX-G7UG 08
NX-G7UN 09
NX-G7US 07
NX-G7UX 18
NX-G9A 01
NX-G9EE 13
NX-G9UG 04
NX-G9UH 15
NX-G9UN 05
NX-G9US 02
NX-G9UX 14
NX-G9UY 03
General assembly [M1]
Part No.
!
Symbol o
<Rev.001> <Rev.002>
Part Name Description Qty Models
M1 1 ------------ GV10428-022A FRONT
PANEL
(Addition) 1 13
M1 1 ------------ GV10428-021A FRONT
PANEL
(Addition) 1 16
M1 1 ------------ GV10428-020A FRONT
PANEL
(Addition) 1 19
M1 7 ------------ GV20519-003A ROLLING
PANEL
(Addition) 1 13,14,15,19,1A,1B,1C,1D,1E,1F,20,21
M1 11 ------------ GV31211-002A KNOB (Addition) 2 13,14,15,16,17,18,19,1A,1B,1C,1D,1E,20,21
M1 17 ------------ QYSDSF2608ZA TAP SCREW (Addition) 8 13,14,15,16,17,18,19,1A,1B,1C,1D,1E,1F,20,
21
M1 26 ------------ QYSDSF2608ZA TAP SCREW (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C,0D,0E,
0F,10,11,12,13,14,15,16,17,18,19,1A,1B,1C,
1D,1E,1F,20,21
M1 26 QYSDSF2608ZA ------------ TAP SCREW (Deletion) 1 01,02,03,04,05,0A,0B,0C,0D,0E,0F,10,11,12
M1 26 QAR0219-001 ------------ LOADING
MOTOR
(Deletion) 1 06,07,08,09
M1 28 ------------ GV30349-067A SPACER (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C,0D,0E,
0F,10,11,12,13,14,15,16,17,18,19,1A,1B,1C,
1D,1E,1F,20,21
M1 28 GV30349-067A ------------ SPACER (Deletion) 1 01,02,03,04,05,0A,0B,0C,0D,0E,0F,10,11,12
M1 28 QYSDSF2608ZA ------------ TAP SCREW (Deletion) 1 06,07,08,09
M1 29 ------------ GV40846-001A SPECIAL
SPACER
(Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C,0D,0E,
0F,10,11,12,13,14,15,16,17,18,19,1A,1B,1C,
1D,1E,1F,20,21
M1 29 GV40846-001A ------------ SPECIAL
SPACER
(Deletion) 1 01,02,03,04,05,0A,0B,0C,0D,0E,0F,10,11,12
M1 29 GV30349-067A ------------ SPACER (Deletion) 1 06,07,08,09
To Next Page
