JVC CH-X400 - Page 54

CH-X400/CH-X450
3-5
Item Parts number Parts name Area
Parts list (CD changer mechanism)
Q'ty Description
Block No. M2MM
A LV30928-201A TRA MECHA UNIT 1
1 LV30096-002A CHASSIS
(
L
)
ASSY 1
2 LV30097-001A CHASSIS
(
R
)
ASSY 1
2-1 QYSDST2004Z SCREW 1
3 QYSDST2004Z SCREW 27
4 LV40129-003A MOTOR BKT ASS'Y 1
5 PPN13KA10C-SA5 MOTOR ASS'Y 2
6 WJM0017-001A E-SI C WIRE C-F 1
7 QYSPSPT2025M MINI SCREW 2
9 LV40131-001A WORM WHEEL
(
P
)
1
11 LV40132-003A THIRD GEAR 1
12 LV40133-005A LIFTER GEAR 1
13 LV30100-002A APLOCK ARM 1
14 LV40134-003A M.LOCK SPRING 1
15 QYWDL163525-6 SLIT WASHER 4
16 LV40142-003A LIFTER SPRING 1
17 LV40478-002A EJECT DAMPER 1
18 LV10027-002A TOP COVER 1
19 LV30101-004A MAGAZINE SPRING 3
20 LV30448-001A FRONT SLIDER AS 1
21 LV30449-001A REAR SLIDER ASS 1
22 REE1500X E.RING 1
23 LV40135-003A ROD
(
U
)
1
24 LV40136-002A ROD
(
L
)
1
25 LV30104-002A SENSOR BRACKET 1
26 LV30105-001A SENSOR HOLDER 1
27 QVY0002-B14 S V RESISTOR 1
28 WJM0017-002A E-SI C WIRE C-F 1
29 LV40137-001A SENSOR SPRING 1
30 LV20067-002A LIFTER UNIT 1
30-1 LV30110-001A HOOK 1
30-2 VKR3203-001 CLAMPER 1
30-3 VKL7938-001 CLAMPER GUIDE 1
30-4 VKS5587-002 DETECT ROLLER 2
30-5 VKZ4563-005 O RING 4
31 LV30148-004A SIDE BKT UNIT 1
31-1 LV40148-003A TRAY GEAR 1
31-2 QYWDL163525-6 SLIT WASHER 1
31-3 LV40190-002A RETURN SP.
(
R
)
1
32 LV40149-003A L.BKT
(
L
)
ASSY 1
33 LV30119-002A SWITCH LEVER 1
34 LV40151-002A SWITCH SPRING 1
35 LV40152-001A WORM WHEEL
(
T
)
1
36 REE1500X E.RING 1
37 LV30120-001A T.MOTOR HOLDER 1
39 QUB540-10A2A2 WIRE
(
T.MOTOR
)
1
40 QUB541-11A2A2 WIRE
(
T.MOTOR
)
1
42 QYSPSPL2004Z SCREW 3
