3-3
General assembly
Block No. [M][1][M][M]

Symbol No.
Part No. Part Name Description Local
1 LV41843-001A LASER CAUTION
2 LV20065-004B FITTING
3 LV40706-003A CAUTION LABEL
4 QYSDST2004Z SCREW 2mm x 4mm
5 LV41266-001A SPACER
6 LV10407-006A TOP COVER
7 QYSSST2005M SCREW 2mm x 5mm(x2)
8 VYSH101-031 SPACER
9 LV10408-006A BOTTOM COVER
10 LV30632-001A INSULATOR
11 LV42152-001A BRACKET (x2)
12 LV30360-004A DIRECTION KNOB (x2)
13 LV30451-002A DAMPER (x4)
14 LV40345-003A DAMPER SP(R)
15 LV40346-003A DAMPER SP(L)
16 QYSDST2604M SCREW 2.6mm x 4mm(x2)
17 QYSSST2605M SCREW 2.6mm x 5mm(x6)
18 QYSDST2604M SCREW 2.6mm x 4mm(x2)
19 QYSDST2005Z SCREW 2mm x 5mm(x2)
20 QYSDST2606Z SCREW 2.6mm x 6mm
21 LV20923-013B F.PANEL ASSY X500
21 LV21396-008A F.PANEL ASSY X550
22 LV30786-003A HOLD BRACKET
23 QYSDSF2005Z SCREW 2mm x 5mm(x2)
24 LV34572-001A NAME PLATE X500
24 LV34569-001A NAME PLATE X550
25 VYSS2R2-028 SPACER
26 LV40762-001A CAUTION LABEL
27 LV40487-003A CAUTION LABEL
28 LV40528-005A LABEL
29 E70891-001 CLASS 1 LABEL
