3-5
CD changer mechanism
Block No. [M][A][M][M]
Symbol No.
Part No. Part Name Description Local
1 LV30096-005A CHASSIS(L)ASSY
2 LV40123-006A LIFT ARM ASSY
3 LV30098-003A EJECT SLIDER
4 LV40126-005A EJECT SPRING (x2)
5 VYSH102-102 SPACER
6 VYSA1R4-056 SPACER
7 LV30097-002A CHASSIS(R) ASSY
8 QYSDST2004Z SCREW 2mm x 4mm(x2)
9 LV42097-001A MOTOR BKT ASSY
10 PPN-13KA10C MOTOR(FEED)
11 WJM0017-001A E-SI C WIRE C-F
12 QYSPSPT2025M MINI SCREW 2mm x 2.5mm(x2)
13 LV32442-001A WORM DRIVE
14 LV32440-001A WORM GEAR
15 LV32441-001A WORM WHEEL(P)
16 QYWFM164025 WASHER 6.4mm x 2mm
17 QYSDST2004Z SCREW 2mm x 4mm(x2)
18 LV40132-003A THIRD GEAR
19 LV40133-005A LIFTER GEAR
20 LV30100-002A APLOCK ARM
21 LV40134-003A M.LOCK SPRING
22 QYWDL163525-6 SLIT WASHER 5.2mm x (x4)
23 LV40142-003A LIFTER SPRING
24 LV40478-002A EJECT DAMPER
25 QYSDSR2006Z SCREW 2mm x 6mm
26 LV10027-003A TOP COVER
27 LV30101-004A MAGAZINE SPRING (x3)
28 QYSDST2004Z SCREW 2mm x 4mm(x9)
29 LV30448-001A FRONT SLIDER AS
30 LV30449-001A REAR SLIDER ASSY
31 LV42132-001A E RING
32 LV40135-004A ROD(U)
33 LV40136-003A ROD(L)
34 LV30104-002A SENSOR BRACKET
35 LV30105-001A SENSOR HOLDER
36 QVY0002-B14 S V RESISTOR
37 WJM0017-002A E-SI C WIRE C-F
38 LV40137-002A SENSOR SPRING
39 QYSDST2004Z SCREW 2mm x 4mm(x2)
40 QYSDST2004Z SCREW 2mm x 4mm(x2)
41 LV20067-002A-N LIFTER UNIT
41-1 LV30110-001A HOOK
41-2 VKR3203-001 CLAMPER
41-3 VKL7938-001 CLAMPER GUIDE
41-4 VKS5587-002 DETECT ROLLER (x2)
41-5 VKZ4563-005 O RING (x4)
42 LV30148-004A-N SIDE BKT UNIT
42-1 LV40190-002A RETURN SP.(R)
42-2 LV40148-003A TRAY GEAR
42-3 QYWDL163525-6 SLIT WASHER 5.2mm x
43 QYSDST2004Z SCREW 2mm x 4mm(x2)
44 LV40149-003A L.BKT(L) ASSY
45 VYSA1R4-088 SPACER
46 LV30119-003A SWITCH LEVER
47 LV40151-002A SWITCH SPRING
48 LV40152-001A WORM WHEEL(T)
49 REE1500X E RING
50 LV30120-001A T.MOTOR HOLDER
51 PPN-13KA10C MOTOR(FEED)
52 LV40130-001A WORM GEAR
53 QYSPSPL2004Z SCREW 2mm x 4mm(x2)
54 QYSDST2004Z SCREW 2mm x 4mm(x2)
55 QYSDST2004Z SCREW 2mm x 4mm(x2)
56 LV40474-003A ELEVATOR SPRING
57 LV32806-001A-SL TRA MECHA UNIT
58 OPTIMA-725B2M CD PICK UP
59 FF-050SK-11170 DC MOTOR
60 QYSPSPL2004Z SCREW 2mm x 4mm
61 VKS5557-001 F.M. GEAR
62 LV40155-001A MIDDLE GEAR
63 LV40156-001A S.S. GEAR
64 LV40157-001A SCREW SHAFT
65 LV30122-002A SHAFT HOLDER
66 VKZ4248-204 MINI TAP SCREW
67 LV30123-002A RACK ARM
68 QYSPSPT1722M MINI SCREW
1.7mm x
2.2mm(x2)
69 LV32438-001A P.S.SPRING
70 QYSPSGT1425M TAP SCREW 1.4mm x 2.5mm
71 LV30450-004A PICK FPC
72 QYSDST2006Z SCREW 2mm x 6mm(x3)
73 QYSDST2005Z SCREW 2mm x 5mm(x4)
74 QUQ710-2614BJ FFC WIRE
75 QUQ110-1013BJ FFC WIRE
76 QYSDSP2606Z SCREW 2.6mm x 6mm
77 QUB540-10A2A2 WIRE(T.MOTOR)
78 QUB541-11A2A2 WIRE(T.MOTOR)
79 QUB456-04A2A2 WIRE(F.MOTOR)
80 QUB459-05A2A2 WIRE(F.MOTOR)
81 VKL7059-002 TR.BRACKET
