3-7
Main board (Old)
Block No. [0][2][0][0]
R106 NRSA63J-392X MG RESISTOR 3.9k
Ω
1/16W J
R107 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R108 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R109 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R110 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R111 NRSA63J-682X MG RESISTOR 6.8k
Ω
1/16W J
R112 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R201 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R202 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R203 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R204 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R205 NRSA63J-392X MG RESISTOR 3.9k
Ω
1/16W J
R206 NRSA63J-392X MG RESISTOR 3.9k
Ω
1/16W J
R207 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R208 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R209 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R210 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R211 NRSA63J-682X MG RESISTOR 6.8k
Ω
1/16W J
R503 NRSA63J-683X MG RESISTOR 68k
Ω
1/16W J
R504 NRSA63J-683X MG RESISTOR 68k
Ω
1/16W J
R505 NRSA63J-334X MG RESISTOR 330k
Ω
1/16W J
R506 NRSA63J-334X MG RESISTOR 330k
Ω
1/16W J
R507 NRSA02J-220X MG RESISTOR 22
Ω
1/10W J
R508 NRSA02J-220X MG RESISTOR 22
Ω
1/10W J
R509 NRSA63J-823X MG RESISTOR 82k
Ω
1/16W J
R510 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R511 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R512 NRSA63J-202X MG RESISTOR 2k
Ω
1/16W J
R513 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R514 NRSA63J-153X MG RESISTOR 15k
Ω
1/16W J
R515 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R516 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R517 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R518 NRSA63J-333X MG RESISTOR 33k
Ω
1/16W J
R519 NRSA63J-151X MG RESISTOR 150
Ω
1/16W J
R521 NRSA63J-562X MG RESISTOR 5.6k
Ω
1/16W J
R522 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R523 NRSA63J-474X MG RESISTOR 470k
Ω
1/16W J
R524 NRSA63J-153X MG RESISTOR 15k
Ω
1/16W J
R525 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R527 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R528 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R531 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R532 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R534 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R535 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R536 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R537 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R538 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R539 NRSA63J-105X MG RESISTOR 1M
Ω
1/16W J
R543 NRSA63J-330X MG RESISTOR 33
Ω
1/16W J
R544 NRSA63J-155X MG RESISTOR 1.5M
Ω
1/16W J
R581 NRSA63J-432X MG RESISTOR 4.3k
Ω
1/16W J
R582 NRSA63J-823X MG RESISTOR 82k
Ω
1/16W J
R583 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R584 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R585 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R601 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R602 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R603 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R604 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R605 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R606 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R607 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R609 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R610 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R611 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R612 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R614 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R617 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R618 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R619 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R620 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R621 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R622 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R623 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R625 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R626 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
Symbol No.
Part No. Part Name Description Local
R628 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R629 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R651 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R652 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R653 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R654 NRSA63J-334X MG RESISTOR 330k
Ω
1/16W J
R655 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R656 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R657 NRSA63J-334X MG RESISTOR 330k
Ω
1/16W J
R658 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R659 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R660 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R661 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R901 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R902 NRSA63J-392X MG RESISTOR 3.9k
Ω
1/16W J
R903 NRSA02J-222X MG RESISTOR 2.2k
Ω
1/10W J
R911 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R912 NRSA02J-2R2X MG RESISTOR 2.2
Ω
1/10W J
R921 NRSA63J-273X MG RESISTOR 27k
Ω
1/16W J
R923 NRSA63J-184X MG RESISTOR 180k
Ω
1/16W J
R924 NRSA63J-682X MG RESISTOR 6.8k
Ω
1/16W J
R925 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R926 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R941 NRSA63J-100X MG RESISTOR 10
Ω
1/16W J
R942 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R943 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R951 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R954 NRSA63J-272X MG RESISTOR 2.7k
Ω
1/16W J
R971 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R972 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R973 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R981 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R982 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
L521 QQL244K-4R7Z COIL 4.7uH K
L522 QQL244K-4R7Z COIL 4.7uH K
L524 QQL244K-4R7Z COIL 4.7uH K
L601 QQL244K-4R7Z COIL 4.7uH K
CN501 QGF1013F1-15X CONNECTOR FFC/FPC (1-15)
CN502 QGF1006F1-26W CONNECTOR FFC/FPC (1-26)
CN503 QGF1009F2-26 CONNECTOR FFC/FPC (1-26)
CN504 QGA2501F1-02 CONNECTOR W-B (1-2)
CN601 QGA2501F1-03 CONNECTOR W-B (1-3)
CN902 QNZ0095-001 CONNECTOR
CN903 QGF1013F1-10X CONNECTOR FFC/FPC (1-10)
CN904 QGF1009F2-10 CONNECTOR FFC/FPC (1-10)
F901 ICP-N70-T IC PROTECTOR 2.5A
S601 VSH1173-001 SWITCH
S602 VSH1173-001 SWITCH
S603 VSH1173-001 SWITCH
S604 VSH1173-001 SWITCH
S606 QSW0643-001Z TACT SWITCH
X521 QAX0413-001Z CRYSTAL 16.9344MHz
X601 QAX0414-001Z CRYSTAL 4.19430MHz
Symbol No.
Part No. Part Name Description Local
IC101 BA15218F-XE IC
IC501 TA2147F-X IC
IC521 TC9490FA IC
IC581 FAN8037 IC
IC601 UPD780058GC-291 IC
IC602 IC-PST9333U-X IC
IC604 BR24L01AF-W-X IC
IC651 HD74HC126FP-X IC
Q101 2SD1048/6-7/-X TRANSISTOR
Q501 2SB1241/QR/-T TRANSISTOR
Q581 2SB1322/RS/-T TRANSISTOR
Q582 KRA102S-X DIGI TRANSISTOR
