JVC CS-BB2J - Safety Precautions; Specific Service Instructions; Disassembly Procedures; Removing the Almi Plate

(No.MA252)1-3
SECTION 1
PRECAUTION
1.1 Safety Precautions
SECTION 2
SPECIFIC SERVICE INSTRUCTIONS
This service manual does not describe SPECIFIC SERVICE INSTRUCTIONS.
SECTION 3
DISASSEMBLY
3.1 Removing the almi plate
(See fig.1)
(1) Remove the six screws A, two screws B and one screw C
attaching the almi plate.
(2) Remove the almi plate from main body.
Fig.1
!
Burrs formed during molding may be left over on some parts of the chassis. Therefore,
pay attention to such burrs in the case of preforming repair of this system.
A
A
B
C
almi plate
