JVC CS-BB2J - Adjustment Procedures; Troubleshooting Guide; 10-Pin Cord Diagram

(No.MA252)1-5
SECTION 4
ADJUSTMENT
This service manual does not describe ADJUSTMENT.
SECTION 5
TROUBLESHOOTING
5.1 10 PIN CORD DIAGRAM
1.BL/WH
2.YL
3.BK
4.WH/BK
5.GY/BK
6.NC
7.YL
8.BK
9.WH
10.GY
REMOTE OUT OR POWER LEAD
POWER
LEAD
GROUND
TO L CHANNEL
SPEAKER OUTPUT
TO R CHANNEL
SPEAKER OUTPUT
TO ANPLEFIER
OR
RECEIVER
TO ANPLEFIER
OR
RECEIVER
1 BL/WH
2 YL
7 YL
3 BK
8 BK
9 WH
4 WH/BK
10 GY
5 GY/BK
BK
BL
WH
GY
YL
Black
Blue
White
Gray
Yellow
RR
Rear Right
FR
Front Right
FL
Front Left
RL
Rear Left
REMOTE
Remote Out
GND
Ground
MEMORY
Memory Backup Battery+
REMOTE
MEMORY
GND
FL+
FL-
FR+
FR-
