JVC D Series Service Manual

(No.YA073)1-17
No. Setting item
Variable
range
Initial setting value
AV-27D305/R
RF / EXTERNAL (S / COMPOSITE) EXTERNAL (COMPONENT)
STANDARD THEATER STANDARD THEATER
LOW HIGH LOW HIGH LOW HIGH LOW HIGH
S11 R CUT OFF 0 ~ 255 30 --- --- --- --- --- --- ---
S12 G CUT OFF 0 ~ 255 30 --- --- --- --- --- --- ---
S13 B CUT OFF 0 ~ 255 30 --- --- --- --- --- --- ---
S14 R DRIVE 0 ~ 127 64 --- --- --- --- --- --- ---
S15 B DRIVE 0 ~ 127 64 --- --- --- --- --- --- ---
S16 R CUT +- -128 ~ +127 --- ±0 ±0 ±0 ±0 --- --- ---
S17 G CUT +- -128 ~ +127 --- ±0 ±0 ±0 ±0 --- --- ---
S18 B CUT +- -128 ~ +127 --- ±0 ±0 ±0 ±0 --- --- ---
S19 R DRV +- -128 ~ +127 --- ±0 7 7 ±0 --- --- ---
S20 B DRV +- -128 ~ +127 --- ±0 -9 -9 ±0 --- --- ---
S21NTSC MAT 0 ~ 333112211
S22 BLACK ST 0 ~ 3 2 --- 1 --- --- --- --- ---
S23 DC REST 0 ~ 1 1 --- 1 --- --- --- --- ---
S24 DCRSW 0 ~ 1 1 --- 1 --- --- --- --- ---
No. Setting item
Variable
range
Initial setting value
RF
EXTERNAL (S / COMPOSITE) EXTERNAL (COMPONENT)
S25 ASY SHRP 0 ~ 7 4 4 4
S26 BPF FO 0 ~ 1 0 0 ---
S27 KILR OFF 0 ~ 1 0 0 ---
S28 KILR SEN 0 ~ 1 1 1 ---
No. Setting item
Variable
range
Initial setting value
S29 RGB MUTE 0 ~ 1 0
S30 BLUE B 0 ~ 1 1
S31 VIDEO SW 0 ~ 3 3
S32 CMP ABCL 0 ~ 1 0
S33 OSD ABL 0 ~ 1 0
S34 OSD CONT 0 ~ 63 9
S35 SUB CONT 0 ~ 15 8
S36 ABL GAIN 0 ~ 3 0
S37 ABL PNT 0 ~ 3 3
S38 Y GAMMA 0 ~ 3 1
S39 Y MUTE 0 ~ 1 0
S40 SVM GAIN 0 ~ 3 3
S41 SVM PH 0 ~ 3 0
S42 WPL 0 ~ 1 0
S43 COL GMM 0 ~ 1 0
S44 V1 GAIN 0 ~ 7 4
S46 VMOFF DE -128 ~ +127 0
S47 APC CLK 0 ~ 1 1
S48 PIP ADJ 0 ~ 15 0
