1-2 (No.YA073)
SPECIFICATION
Design & specifications are subject to change without notice.
Items Contents
Dimensions (W × H × D) 75.2cm × 59.0cm × 53.1cm (29-5/8" × 23-1/4" × 23")
Mass 32.2kg (70.8lbs)
TV RF System CCIR (M)
Color System NTSC
Sound System BTSC (Multi Channel Sound)
TV Receiving Channels
and Frequency
VHF Low
VHF High
UHF
CATV
02ch~06ch : 54MHz~88MHz
07ch~13ch : 174MHz~216MHz
14ch~69ch : 470MHz~806MHz
54MHz~804MHz
Low Band : 02~06, A-8 by 02~06&01
High Band : 07~13 by 07~13
Mid Band : A~I by 14~22
Super Band : J~W by 23~36
Hyper Band : W+1~W+28 by 37~64
Ultra Band : W+29~W+84 by 65~125
Sub Mid Band : A8, A4~A1 by 01, 96~99
TV / CATV Total Channel 180 Channels
Intermediate Frequency Video IF
Sound IF
45.75 MHz
41.25 MHz (4.5MHz)
Color Sub Carrier 3.58 MHz
Power Input AC 120V, 60Hz
Power Consumption 105W
Picture Tube 68cm (27") Measured diagonally (H: 55.4cm × V: 41.8cm)
High Voltage 28kV±1.3kV (at zero beam current)
Speaker 5 × 9cm (2" × 3-1/2") Oval type × 2
Audio Power Output 1.2W + 1.2W
Antenna terminal (VHF / UHF) F-type connector, 75Ω unbalanced, coaxial
Video / Audio input
Input-1/2/3
Component Video
[Input-2]
S-video
[Input-1]
Video
Audio
RCA pin jack × 3
Y : 1V(p-p), negative sync, 75 Ω
Pb/Pr : 0.7V(p-p), 75 Ω
Mini DIN 4-pin × 1
Y : 1V(p-p), negative sync, 75 Ω
C : 0.286V(p-p)(burst signal), 75 Ω
1V(p-p), negative sync, 75 Ω, RCA pin jack × 3
500mV(rms)(-4dBs), high impedance, RCA pin jack × 6
Audio Output (Fix) 500mV(rms)(-4dBs), low Impedance, (400kHz when modulated 100%),
RCA pin jack × 2
Remote Control Unit RM-C1259G (AA/R6/UM-3 battery × 2)
