JVC D Series Service Manual

3-12(No.YA073)
R1692 NRSA63J-823X MG RESISTOR 82k Ω 1/16W J
R1701 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R1702 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R1703 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1704 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R1705 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R1706 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R1707 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1708 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R1709 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R1714 NRSA63J-823X MG RESISTOR 82k Ω 1/16W J
R1715 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R1718 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R1720 QRJ149J-1R0 UNF C RESISTOR 1 Ω 1/4W J
R1721 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R1729 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R1731 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R1732 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R1733 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R1734 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R1739 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R1740 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R1751 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R1752 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R1753 NRSA63J-152X MG RESISTOR 1.5k Ω 1/16W J
R1754 NRSA63J-272X MG RESISTOR 2.7k
Ω 1/16W J
R1755 NRSA63J-562X MG RESISTOR 5.6k
Ω 1/16W J
R1756 NRSA63J-122X MG RESISTOR 1.2k Ω 1/16W J
R1757 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R1758 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R1764 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R1765 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R1766 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R1767 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R1768 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R1769 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R1770 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1771 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R1772 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1773 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1774 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1775 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1776 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R1777 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R1778 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1801 NRSA63J-680X MG RESISTOR 68 Ω 1/16W J
R1802 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R1803 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R1804 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R1805 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R1821 NRSA63J-124X MG RESISTOR 120k Ω 1/16W J
R1831 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R1832 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R1833 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R1834 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R1835 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R1836 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R1839 NRSA63J-225X MG RESISTOR 2.2M
Ω 1/16W J
R1851 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R1852 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R1853 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R1854 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R1855 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R1856 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R1857 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R1858 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R1859 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R1860 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R1861 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R1862 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R1863 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
 R1901 QRF074K-R47 UNF WW RESISTOR 0.47 Ω 7W K
R1902 QRE121J-473Y C RESISTOR 47k
Ω 1/2W J
R1903 QRE121J-473Y C RESISTOR 47k
Ω 1/2W J
R1904 QRT029J-R22 MF RESISTOR 0.22 Ω 2W J
R1905 QRT029J-R22 MF RESISTOR 0.22
Ω 2W J
R1906 QRE121J-2R2Y C RESISTOR 2.2 Ω 1/2W J
R1907 QRE121J-472Y C RESISTOR 4.7k
Ω 1/2W J
R1908 QRK126J-681X UNF C RESISTOR 680 Ω 1/2W J
R1910 QRE121J-684Y C RESISTOR 680k
Ω 1/2W J
R1911 QRG01GJ-470 OMF RESISTOR 47 Ω 1W J
R1922 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R1923 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R1924 QRX01GJ-1R0 MF RESISTOR 1 Ω 1W J
R1925 QRX01GJ-1R0 MF RESISTOR 1 Ω 1W J
R1926 QRT029J-1R2 MF RESISTOR 1.2
Ω 2W J
R1927 QRT029J-1R2 MF RESISTOR 1.2
Ω 2W J
 Ref No. Part No. Part Name Description Local
R1928 QRE121J-272Y C RESISTOR 2.7k Ω 1/2W J
R1929 QRE121J-223Y C RESISTOR 22k Ω 1/2W J
R1930 QRE121J-473Y C RESISTOR 47k Ω 1/2W J
R1932 NRSA63J-123X MG RESISTOR 12k Ω 1/16W J
R1933 NRSA63J-123X MG RESISTOR 12k Ω 1/16W J
R1934 NRSA63J-273X MG RESISTOR 27k Ω 1/16W J
R1935 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R1936 QRE121J-103Y C RESISTOR 10k Ω 1/2W J
R1938 QRE121J-103Y C RESISTOR 10k Ω 1/2W J
R1939 QRE121J-103Y C RESISTOR 10k Ω 1/2W J
R1941 QRG029J-180 OMF RESISTOR 18 Ω 2W J
R1942 QRE121J-5R6Y C RESISTOR 5.6 Ω 1/2W J
R1943 QRE121J-820Y C RESISTOR 82 Ω 1/2W J
 R1991 QRZ9041-275 C RESISTOR 2.7M Ω 1/2W K
L1101 QQLZ014-R39 COIL 0.39uH 100mA L
L1131 QQL29BJ-220Z P COIL 0.65 Ω 22uH J
L1161 QQL29BJ-220Z P COIL 0.65 Ω 22uH J
L1232 QQL29BJ-560Z PEAKING COIL 56uH J
L1251 QQL29BJ-4R7Z PEAKING COIL 4.7uH J
L1281 QQL29BJ-150Z PEAKING COIL 15uH J
L1291 QQL29BJ-150Z PEAKING COIL 15uH J
L1341 QQL29BJ-390Z PEAKING COIL 39uH J
L1521 QQR1027-004 LINIARITY COIL
L1921 QQL26AK-470Z CHOKE COIL 47uH K
L1922 QQL26AK-470Z CHOKE COIL 47uH K
T1111 QQR0907-001 I F T
T1501 QQR1414-001 DRIVE TRANSF
 T1901 QQT0355-001 POWER TRANSF
 T1921 QQS0204-001 SW TRANSF
CF1001 QAX0349-001 C TRAP 47.25MHz
CF1131 QAX0639-001Z C TRAP 4.500MHz
CF1161 QAX0642-001Z C FILTER 4.500MHz
CN100C QGA2501F1-06 CONNECTOR W-B (1-6)
CN100S QGA2501C5-04Z CONNECTOR W-B (1-4)
CN100T CHGC05-480 CONNECTOR ASSY
CN100U CHGC04-400 CONNECTOR ASSY
CN10E1 CHGT0015-0B CONNECTOR ASSY
CN10HV QGZ5004C1-06 CONNECTOR (1-6)
 CN1DEG QGA7901C1-02 CONNECTOR W-B (1-2)
CN1X CH41169-R03Y EH POST HEADER
 F1901 QMF51N1-5R0-J5 FUSE 5A AC125V
H1002 LC30381-001A HEAT SINK
H1602 LC32599-001A HEAT SINK
HS1004 LC31696-001A HEAT SINK
HS1009 LC31678-001A HEAT SINK/AL-F/
J1001 QNZ0454-001 AV JACK S/V/L/R IN
J1002 QNN0348-001 PIN JACK L/R OUT
J1003 QNN0349-002 PIN JACK V/L/R IN
J1004 QNN0348-001 PIN JACK L/R IN
J1005 CEMN065-001 PIN JACK V IN
J1006 CEMN065-002 PIN JACK L IN
J1007 CEMN072-003 PIN JACK R IN
K1001 QQR0582-001Z FERRITE BEADS
K1101 QQR0582-001Z FERRITE BEADS
K1251 QQR0582-001Z FERRITE BEADS
K1252 QQR0582-001Z FERRITE BEADS
K1253 QQR0582-001Z FERRITE BEADS
K1254 QQR0582-001Z FERRITE BEADS
K1255 QQR0621-002Z FERRITE BEADS
K1401 QQR0582-001Z FERRITE BEADS
K1701 QQR0582-001Z FERRITE BEADS
K1702 QQR0582-001Z FERRITE BEADS
K1901 QQR0582-001Z FERRITE BEADS
K1902 QQR0582-001Z FERRITE BEADS
K1903 QQR0582-001Z FERRITE BEADS
K1904 QQR0582-001Z FERRITE BEADS
K1921 QQR0582-001Z FERRITE BEADS
K1922 QQR0582-001Z FERRITE BEADS
K1923 QQR0582-001Z FERRITE BEADS
LC1687 QQR1459-001 EMI F. COIL
LC1688 QQR1459-001 EMI F. COIL
LC1801 QQR1459-001 EMI F. COIL
 LF1901 QQR0527-003 LINE FILTER
 RY1901 QSK0085-001 RELAY
S1401 QSL4A13-C02 LEVER SWITCH V.CENTER
S1751 QSW0619-003Z TACT SWITCH POWER
S1752 QSW0619-003Z TACT SWITCH VOL+
S1753 QSW0619-003Z TACT SWITCH VOL-
S1754 QSW0619-003Z TACT SWITCH CH+
S1755 QSW0619-003Z TACT SWITCH CH-
S1756 QSW0619-003Z TACT SWITCH MENU
SF1101 QAX0723-001 SAW FILTER
 SK1351 QNZ0536-001 CRT SOCKET
 TH1901 QAD0129-3R0 POSISTOR 3 Ω
 TU1001 QAU0353-001 TUNER
 VA1901 ERZV10V621CS ZNR
X1701 QAX0717-001Z CRYSTAL 8.000MHz
 Ref No. Part No. Part Name Description Local
