JVC DX-J36UN Service Manual

3-28
DVD loading board (For J21 & J11 ver)
Block No. [0][8]
Casset control board (Only J36 ver)
Block No. [0][9]
CN701 QGF1016F8-28W CONNECTOR FFC/FPC (1-28)
CN702 QGF1016F8-10W CONNECTOR FFC/FPC (1-10)
CN801 QGF1016F8-05W CONNECTOR FFC/FPC (1-5)
CN811 QGA2001F6-05X CONNECTOR W-B (1-5)
K101 NQR0502-001X FERRITE BEADS
K351 NQR0502-001X FERRITE BEADS
K352 NQR0502-001X FERRITE BEADS
K353 NQR0502-001X FERRITE BEADS
K354 NQR0022-002X FERRITE BEADS
K454 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
K455 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
K456 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
K501 NQR0502-001X FERRITE BEADS
K720 NQR0022-002X FERRITE BEADS
K732 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
K733 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
K734 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
K735 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
K736 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
K737 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
K738 NQR0022-005X FERRITE BEADS
K744 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
K748 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
K749 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
K750 NQR0022-002X FERRITE BEADS
K752 NQR0022-002X FERRITE BEADS
K754 NQR0022-002X FERRITE BEADS
K756 NQR0022-002X FERRITE BEADS
K758 NQR0022-002X FERRITE BEADS
K811 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
K812 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
TH301 NAD0025-103X N THERMISTOR 10k
Ω
X301 NAX0741-001X CRYSTAL 27.000MHz
X302 NAX0376-002X CRYSTAL
X451 NAX0248-001X C OSCILLATOR 8.000MHz
! Symbol No. Part No. Part Name Description Local
IC1 LB1641 IC
IC2 LB1641 IC
D1 MTZJ6.2A-T2 Z DIODE
C1 QEKC1AM-107Z E CAPACITOR 100uF 10V M
C2 QCBB1HK-104Y C CAPACITOR 0.1uF 50V K
C3 QFLC1HJ-103Z M CAPACITOR 0.01uF 50V J
C5 QFLC1HJ-103Z M CAPACITOR 0.01uF 50V J
C6 QCBB1HK-104Y C CAPACITOR 0.1uF 50V K
C7 QCBB1HK-104Y C CAPACITOR 0.1uF 50V K
CN1 QGF1036F1-15 CONNECTOR FFC/FPC (1-15)
CN2 QGB2024K1-07S CONNECTOR B-B (1-7)
CN3 QGB2024J1-07S CONNECTOR B-B (1-7)
SW1 QSW0844-001 PUSH SWITCH
SW2 QSW0844-001 PUSH SWITCH
SW3 QSW0844-001 PUSH SWITCH
SW4 QSW0844-001 PUSH SWITCH
SW5 QSW0844-001 PUSH SWITCH
SW6 QSW0854-002 PUSH SW
SW8 QSW0923-001 DETECT SWITCH
! Symbol No. Part No. Part Name Description Local
! Symbol No. Part No. Part Name Description Local
IC200 HA12237F-E IC
Q110 KTA1271/OY/-T TRANSISTOR
Q111 RT1N144C-X DIGI TRANSISTOR
Q120 KTA1296/Y/-T TRANSISTOR
Q121 RT1N144C-X DIGI TRANSISTOR
Q140 KTA1271/OY/-T TRANSISTOR
Q141 RT1N144C-X DIGI TRANSISTOR
Q150 KTA1296/Y/-T TRANSISTOR
Q151 RT1N144C-X DIGI TRANSISTOR
Q200 RT1P430C-X TRANSISTOR
Q201 RT6N430C-X TRANSISTOR
Q202 RT6N430C-X TRANSISTOR
Q203 RT6N430C-X TRANSISTOR
Q204 RT6N430C-X TRANSISTOR
Q300 KTC3203/OY/-T TRANSISTOR
Q301 KTC3203/OY/-T TRANSISTOR
D121 1N4003S-T5 SI DIODE
D122 1N4003S-T5 SI DIODE
D151 1N4003S-T5 SI DIODE
D152 1N4003S-T5 SI DIODE
C110 QETN1HM-106Z E CAPACITOR 10uF 50V M
C122 QETN1CM-107Z E CAPACITOR 100uF 16V M
C140 QETN1HM-106Z E CAPACITOR 10uF 50V M
C202 NCB31HK-122X C CAPACITOR 1200pF 50V K
C203 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C204 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C205 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C206 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C207 NCB31HK-391X C CAPACITOR 390pF 50V K
C209 QETN1AM-227Z E CAPACITOR 220uF 10V M
C210 QETN1HM-105Z E CAPACITOR 1uF 50V M
C211 QETN1HM-106Z E CAPACITOR 10uF 50V M
C212 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C213 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C214 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C215 NCB31HK-391X C CAPACITOR 390pF 50V K
C216 NCB31HK-221X C CAPACITOR 220pF 50V K
C219 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C220 QETN1HM-226Z E CAPACITOR 22uF 50V M
C221 QETN1HM-105Z E CAPACITOR 1uF 50V M
C222 QETN1HM-226Z E CAPACITOR 22uF 50V M
C223 NCB31HK-682X C CAPACITOR 6800pF 50V K
C224 NCB31HK-682X C CAPACITOR 6800pF 50V K
C225 NCB31HK-122X C CAPACITOR 1200pF 50V K
C226 QETN1EM-475Z E CAPACITOR 4.7uF 25V M
C227 QETN1EM-475Z E CAPACITOR 4.7uF 25V M
C228 QETN1CM-107Z E CAPACITOR 100uF 16V M
C231 NCB31HK-221X C CAPACITOR 220pF 50V K
C234 NCB31HK-821X C CAPACITOR 820pF 50V K
C235 NCB31HK-821X C CAPACITOR 820pF 50V K
C300 NCB31HK-331X C CAPACITOR 330pF 50V K
C301 NCB31HK-331X C CAPACITOR 330pF 50V K
C303 QFG32AJ-273Z PP CAPACITOR 0.027uF 100V J
C304 QETN1CM-107Z E CAPACITOR 100uF 16V M
C306 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C307 NCB31HK-152X C CAPACITOR 1500pF 50V K
R110 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R113 NRSA63J-183X MG RESISTOR 18k
Ω 1/16W J
R114 NRSA63J-822X MG RESISTOR 8.2k
Ω 1/16W J
R115 NRSA63J-363X MG RESISTOR 36k
Ω 1/16W J
R123 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R140 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R153 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R200 NRSA63J-512X MG RESISTOR 5.1k
Ω 1/16W J
R201 NRSA63J-512X MG RESISTOR 5.1k
Ω 1/16W J
R202 NRSA63J-182X MG RESISTOR 1.8k
Ω 1/16W J
R203 NRSA63J-242X MG RESISTOR 2.4k
Ω 1/16W J
R204 NRSA63J-273X MG RESISTOR 27k
Ω 1/16W J
R205 NRSA63J-303X MG RESISTOR 30k
Ω 1/16W J
R206 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
