JVC DX-J36UN Service Manual

3-29
Cassete control board (For J21 & J11 ver)
Block No. [1][0]
R207 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R208 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R209 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J
R210 NRSA63J-242X MG RESISTOR 2.4k
Ω 1/16W J
R211 NRSA63J-303X MG RESISTOR 30k
Ω 1/16W J
R212 NRSA63J-273X MG RESISTOR 27k
Ω 1/16W J
R213 NRSA63J-182X MG RESISTOR 1.8k
Ω 1/16W J
R214 NRSA63J-512X MG RESISTOR 5.1k
Ω 1/16W J
R215 NRSA63J-512X MG RESISTOR 5.1k
Ω 1/16W J
R216 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R217 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R218 NRSA63J-912X MG RESISTOR 9.1k
Ω 1/16W J
R219 NRSA63J-912X MG RESISTOR 9.1k
Ω 1/16W J
R226 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R227 NRSA63J-243X MG RESISTOR 24k
Ω 1/16W J
R228 NRSA63J-822X MG RESISTOR 8.2k
Ω 1/16W J
R300 NRSA63J-153X MG RESISTOR 15k
Ω 1/16W J
R301 NRSA63J-153X MG RESISTOR 15k
Ω 1/16W J
R302 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R303 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R304 NRSA63J-153X MG RESISTOR 15k
Ω 1/16W J
R305 NRSA63J-2R2X MG RESISTOR 2.2
Ω 1/16W J
R306 QRJ146J-4R7X UNF C RESISTOR 4.7
Ω 1/4W J
R307 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R308 NRSA63J-474X MG RESISTOR 470k
Ω 1/16W J
R309 QRZ9005-100X FUSI RESISTOR 10
Ω
L300 QQR1118-002 OSC COIL(BIAS)
L301 QQL244K-100Z COIL 10uH K
CN100 QGF1205C2-21 CONNECTOR FFC/FPC (1-21)
CN110 QGF1205F2-06 CONNECTOR FFC/FPC (1-6)
CN120 QGF1205C2-07 CONNECTOR FFC/FPC (1-7)
CN200 QGA2001C1-07 CONNECTOR W-B (1-7)
CN220 QGA2001F1-03 CONNECTOR W-B (1-3)
! Symbol No. Part No. Part Name Description Local
IC200 HA12237F-E IC
Q110 KTA1271/OY/-T TRANSISTOR
Q111 RT1N144C-X DIGI TRANSISTOR
Q120 KTA1296/Y/-T TRANSISTOR
Q121 RT1N144C-X DIGI TRANSISTOR
Q140 KTA1271/OY/-T TRANSISTOR
Q141 RT1N144C-X DIGI TRANSISTOR
Q150 KTA1296/Y/-T TRANSISTOR
Q151 RT1N144C-X DIGI TRANSISTOR
Q200 RT1P430C-X TRANSISTOR
Q201 RT6N430C-X TRANSISTOR
Q202 RT6N430C-X TRANSISTOR
Q203 RT6N430C-X TRANSISTOR
Q204 RT6N430C-X TRANSISTOR
Q300 KTC3203/OY/-T TRANSISTOR
Q301 KTC3203/OY/-T TRANSISTOR
D121 1N4003S-T5 SI DIODE
D122 1N4003S-T5 SI DIODE
D151 1N4003S-T5 SI DIODE
D152 1N4003S-T5 SI DIODE
C110 QETN1HM-106Z E CAPACITOR 10uF 50V M
C122 QETN1CM-107Z E CAPACITOR 100uF 16V M
C140 QETN1HM-106Z E CAPACITOR 10uF 50V M
C202 NCB31HK-122X C CAPACITOR 1200pF 50V K
C203 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C204 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C205 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C206 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C207 NCB31HK-391X C CAPACITOR 390pF 50V K
C209 QETN1AM-227Z E CAPACITOR 220uF 10V M
! Symbol No. Part No. Part Name Description Local
C210 QETN1HM-105Z E CAPACITOR 1uF 50V M
C211 QETN1HM-106Z E CAPACITOR 10uF 50V M
C212 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C213 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C214 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C215 NCB31HK-391X C CAPACITOR 390pF 50V K
C216 NCB31HK-221X C CAPACITOR 220pF 50V K
C219 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C220 QETN1HM-226Z E CAPACITOR 22uF 50V M
C221 QETN1HM-105Z E CAPACITOR 1uF 50V M
C222 QETN1HM-226Z E CAPACITOR 22uF 50V M
C223 NCB31HK-682X C CAPACITOR 6800pF 50V K
C224 NCB31HK-682X C CAPACITOR 6800pF 50V K
C225 NCB31HK-122X C CAPACITOR 1200pF 50V K
C226 QETN1EM-475Z E CAPACITOR 4.7uF 25V M
C227 QETN1EM-475Z E CAPACITOR 4.7uF 25V M
C228 QETN1CM-107Z E CAPACITOR 100uF 16V M
C231 NCB31HK-221X C CAPACITOR 220pF 50V K
C234 NCB31HK-821X C CAPACITOR 820pF 50V K
C235 NCB31HK-821X C CAPACITOR 820pF 50V K
C300 NCB31HK-331X C CAPACITOR 330pF 50V K
C301 NCB31HK-331X C CAPACITOR 330pF 50V K
C303 QFG32AJ-273Z PP CAPACITOR 0.027uF 100V J
C304 QETN1CM-107Z E CAPACITOR 100uF 16V M
C306 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C307 NCB31HK-152X C CAPACITOR 1500pF 50V K
R110 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R113 NRSA63J-183X MG RESISTOR 18k
Ω 1/16W J
R114 NRSA63J-822X MG RESISTOR 8.2k
Ω 1/16W J
R115 NRSA63J-363X MG RESISTOR 36k
Ω 1/16W J
R123 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R140 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R153 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R200 NRSA63J-512X MG RESISTOR 5.1k
Ω 1/16W J
R201 NRSA63J-512X MG RESISTOR 5.1k
Ω 1/16W J
R202 NRSA63J-182X MG RESISTOR 1.8k
Ω 1/16W J
R203 NRSA63J-242X MG RESISTOR 2.4k
Ω 1/16W J
R204 NRSA63J-273X MG RESISTOR 27k
Ω 1/16W J
R205 NRSA63J-303X MG RESISTOR 30k
Ω 1/16W J
R206 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R207 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R208 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R209 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J
R210 NRSA63J-242X MG RESISTOR 2.4k
Ω 1/16W J
R211 NRSA63J-303X MG RESISTOR 30k
Ω 1/16W J
R212 NRSA63J-273X MG RESISTOR 27k
Ω 1/16W J
R213 NRSA63J-182X MG RESISTOR 1.8k
Ω 1/16W J
R214 NRSA63J-512X MG RESISTOR 5.1k
Ω 1/16W J
R215 NRSA63J-512X MG RESISTOR 5.1k
Ω 1/16W J
R216 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R217 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R218 NRSA63J-912X MG RESISTOR 9.1k
Ω 1/16W J
R219 NRSA63J-912X MG RESISTOR 9.1k
Ω 1/16W J
R226 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R227 NRSA63J-243X MG RESISTOR 24k
Ω 1/16W J
R228 NRSA63J-822X MG RESISTOR 8.2k
Ω 1/16W J
R300 NRSA63J-153X MG RESISTOR 15k
Ω 1/16W J
R301 NRSA63J-153X MG RESISTOR 15k
Ω 1/16W J
R302 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R303 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R304 NRSA63J-153X MG RESISTOR 15k
Ω 1/16W J
R305 NRSA63J-2R2X MG RESISTOR 2.2
Ω 1/16W J
R306 QRJ146J-4R7X UNF C RESISTOR 4.7
Ω 1/4W J
R307 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R308 NRSA63J-474X MG RESISTOR 470k
Ω 1/16W J
R309 QRZ9005-100X FUSI RESISTOR 10
Ω
L300 QQR1118-002 OSC COIL(BIAS)
L301 QQL244K-100Z COIL 10uH K
CN100 QGF1205C2-21 CONNECTOR FFC/FPC (1-21)
CN110 QGF1205F2-06 CONNECTOR FFC/FPC (1-6)
CN120 QGF1205C2-07 CONNECTOR FFC/FPC (1-7)
CN200 QGA2001C1-07 CONNECTOR W-B (1-7)
CN220 QGA2001F1-03 CONNECTOR W-B (1-3)
! Symbol No. Part No. Part Name Description Local
