JVC EX-A10 Service Manual

3-15
Electrical parts list
Main board (RX-EXA10)
Block No. [0][1]
 Symbol No. Part No. Part Name Description Local
IC211 SN74LV14ANS-X IC
IC212 SN74HC74ANS-X IC
IC231 UPC393G2-W IC
IC261 MM1614AN-X IC 4.0V REG
IC281 MM1593DF-X IC
IC402 BD3805F-X IC
IC403 NJM4580M-X IC
IC404 NJM4580M-X IC
IC405 BA3121F-X IC
IC406 BA3121F-X IC
IC407 NJM4580M-X IC
IC511 NJM4580M-X IC
IC551 GP1FAV30RK0F OPT RECEIVER
IC552 GP1FAV30RK0F OPT RECEIVER
IC553 AK4112BVF-X IC(MICRO C ROM)
IC554 JCV8009-W IC
IC555 AK4385ET-X IC
IC701 MN101C61GPB IC
IC702 BR24L02F-W-X IC
Q2001 KTC3875/YG/-X SI TRANSISTOR
 Q2002 RSS090N03-X POWER MOS FET
Q2003 UN2113-X TRANSISTOR
Q2004 UN211L-X TRANSISTOR
Q2005 2SB709A/R/-X TRANSISTOR
Q2006 UN2213-X DIGI TRANSISTOR
Q2007 2SB709A/R/-X TRANSISTOR
Q2101 KTC3875/YG/-X SI TRANSISTOR
Q2102 2SB709A/R/-X TRANSISTOR
Q2103 KTC3875/YG/-X SI TRANSISTOR
Q2104 2SB709A/R/-X TRANSISTOR
 Q2201 KTA1267/YG/-T TRANSISTOR
Q2202 UN2115-X D.TRANSISTOR
Q2203 KTC3875/YG/-X SI TRANSISTOR
Q2301 KTC3875/YG/-X SI TRANSISTOR
Q2302 KTC3875/YG/-X SI TRANSISTOR
Q2303 2SB709A/R/-X TRANSISTOR
Q2304 KTC3875/YG/-X SI TRANSISTOR
Q2305 2SB709A/R/-X TRANSISTOR
 Q2306 RSQ035P03-W MOS FET
Q2307 KTC3875/YG/-X SI TRANSISTOR
Q2401 KTC3875/YG/-X SI TRANSISTOR
Q2402 2SB709A/R/-X TRANSISTOR
 Q2403 RSQ035P03-W MOS FET
Q2404 KTC3875/YG/-X SI TRANSISTOR
Q2501 KTA1273/Y/-T TRANSISTOR
Q2502 KTC3875/YG/-X SI TRANSISTOR
Q2503 KTA1273/Y/-T TRANSISTOR
Q2701 2SB709A/R/-X TRANSISTOR
Q2702 KTC3875/YG/-X SI TRANSISTOR
Q2901 2SC3661-X TRANSISTOR
Q4001 2SC3661-X TRANSISTOR
Q4011 2SC3661-X TRANSISTOR
Q4012 UN211E-X DIGI TRANSISTOR
Q4013 KTC3875/YG/-X SI TRANSISTOR
Q4031 KTC3875/YG/-X SI TRANSISTOR
Q4032 KTC3875/YG/-X SI TRANSISTOR
Q4033 KTC3875/YG/-X SI TRANSISTOR
Q4081 UN2211-X TRANSISTOR
Q4151 KTC3875/YG/-X SI TRANSISTOR
Q4152 2SB709A/R/-X TRANSISTOR
Q4181 2SK1103-X JUNCTION FET
Q4251 KTC3875/YG/-X SI TRANSISTOR
Q4252 2SB709A/R/-X TRANSISTOR
Q4281 2SK1103-X JUNCTION FET
Q4361 KTC3875/YG/-X SI TRANSISTOR
Q4362 2SB709A/R/-X TRANSISTOR
Q4461 KTC3875/YG/-X SI TRANSISTOR
Q4462 2SB709A/R/-X TRANSISTOR
Q5301 2SB709A/R/-X TRANSISTOR
Q5302 KTC3875/YG/-X SI TRANSISTOR
Q7001 2SB709A/R/-X TRANSISTOR
Q7002 UN2214-X TRANSISTOR
Q7003 UN2214-X TRANSISTOR
Q7301 KTC3875/YG/-X SI TRANSISTOR
Q7302 KTC3875/YG/-X SI TRANSISTOR
Q7303 UN2211-X TRANSISTOR
Q7401 KTC3195/O/-T TRANSISTOR
Q7402 KTC3195/O/-T TRANSISTOR
Q7501 UN2214-X TRANSISTOR
Q7601 KTA1271/OY/-T TRANSISTOR
Q7602 KTC3875/YG/-X SI TRANSISTOR
Q7701 UN2111-X TRANSISTOR B,E,EE,EN,EV
Q7702 UN2213-X DIGI TRANSISTOR B,E,EE,EN,EV
D2001 1SS355-X SI DIODE
D2002 UDZS15B-X Z DIODE
D2003 1SS355-X SI DIODE
D2004 1SS355-X SI DIODE
D2005 UDZS8.2B-X Z DIODE
D2006 UDZS15B-X Z DIODE
D2101 UDZS4.3B-X Z DIODE
D2102 1SS355-X SI DIODE
D2103 1SS355-X SI DIODE
D2201 UDZS27B-X Z DIODE
D2301 1SS355-X SI DIODE
D2302 1SS355-X SI DIODE
D2303 RB161L-40-X SB DIODE
D2304 UDZS4.3B-X Z DIODE
D2401 1SS355-X SI DIODE
D2402 RB161L-40-X SB DIODE
D2403 UDZS13B-X Z DIODE
D2701 1SS355-X SI DIODE
D4021 UDZS9.1B-X Z DIODE
D4032 1SS355-X SI DIODE
D4130 UDZS6.2B-X Z DIODE
D4230 UDZS6.2B-X Z DIODE
D4370 UDZS6.2B-X Z DIODE
D4470 UDZS6.2B-X Z DIODE
D5110 UDZS6.2B-X Z DIODE
D5210 UDZS6.2B-X Z DIODE
D5301 1SS355-X SI DIODE
D7302 UDZS15B-X Z DIODE
D7303 1SS355-X SI DIODE
D7304 1SS355-X SI DIODE
D7305 1SS355-X SI DIODE
D7311 MA152WA-X DIODE
D7501 RB521S-30-X SB DIODE
D7601 1SS355-X SI DIODE
D7602 UDZS6.2B-X Z DIODE
C2002 QFZ0225-473Z PP CAPACITOR 0.047uF
C2003 QTE1V06-476Z E CAPACITOR 47uF 35V
C2004 QEZ0767-828 8200/35 8200uF
C2005 QTE1V06-476Z E CAPACITOR 47uF 35V
C2006 QETN1VM-227Z E CAPACITOR 220uF 35V M
C2101 NCB31HK-102X C CAPACITOR 1000pF 50V K
C2102 NCB31EK-683X C CAPACITOR 0.068uF 25V K
C2103 NCB31HK-331X C CAPACITOR 330pF 50V K
C2104 NCB31HK-331X C CAPACITOR 330pF 50V K
C2201 QETN1HM-226Z E CAPACITOR 22uF 50V M
C2202 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C2301 NCB31HK-471X C CAPACITOR 470pF 50V K
C2302 NCB31HK-152X C CAPACITOR 1500pF 50V K
C2303 NCB31EK-683X C CAPACITOR 0.068uF 25V K
C2304 QETN1HM-106Z E CAPACITOR 10uF 50V M
C2305 NCB31EK-333X C CAPACITOR 0.033uF 25V K
C2306 NCB21HK-104X C CAPACITOR 0.1uF 50V K
C2307 QETN1CM-477Z E CAPACITOR 470uF 16V M
C2308 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C2401 NCB31HK-222X C CAPACITOR 2200pF 50V K
C2402 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2403 QETN1EM-337Z E CAPACITOR 330uF 25V M
C2404 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C2405 NCB21HK-104X C CAPACITOR 0.1uF 50V K
C2406 QFZ0225-473Z PP CAPACITOR 0.047uF
C2501 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2502 QETN1EM-476Z E CAPACITOR 47uF 25V M
 Symbol No. Part No. Part Name Description Local

JVC EX-A10 Specifications

General

Impedance	6 Ω
RMS rated power	20 W
Equalizer	Yes
Volume control	Digital
Supported radio bands	AM, FM
Type	Home audio micro system
Speakers	2-Way, Bass-Reflex
Dimensions (WxDxH)	245 x 80 x 297 mm
USB 2.0 ports quantity	1

Weight and Dimensions

Weight	2700 g
Center speaker weight	3500 g
Center speaker dimensions (WxDxH)	143 x 243 x 257 mm
