6
The use of three main feet on the bottom of the
main unit enables higher sound quality while
maintaining the stability of the main unit.
In addition, the two studs on the bottom help
stabilize the main unit and prevent it from wobbling
or tipping when nudged from above. Because the
studs are slightly shorter than the main feet, the
studs do not come in contact with the mounted
surface, leaving the main feet to support the main
unit.
Features of the main feet and studs
Main feet (3)
Stud (1)
Stud
Main feet
Stud (1)
The height of the studs are slightly
shorter than the main feet.
Main unit (rear view)
Main unit
(bottom view)
Getting started
EX-AK1[B]-01.fm Page 6 Monday, July 23, 2007 5:02 PM
