5INTRODUCTIONS
p Displays Quick Menu. ( 7)
q Changes the buttons shown on the touch panel.
( 6)
*
1
Available sources depend on the external components
you have connected, media you have attached, and
the < > (input) settings you have made.
( 19)
*
2
This adjustment does not affect the volume level of
the other sources.
Using the monitor panel/touch panel
Basic operations
SRC
CD
01 02 0:01:20
Track Title
Artist Name
Disc Title
15:45
FLAT
MP3
1 Displays AV Menu. ( 12)
2 Displays Source Menu.*
1
( 7)
3 Bluetooth indicator (KD-AVX77 only)
4 • Turns on the power.
• Attenuates the sound (if the power is on).
• Turns off the power. (Hold)
• Switches the conversation media while talking
with a Bluetooth cellular phone. (KD-AVX77
only, 49)
5 Remote sensor
6 Resets the unit. ( 3)
7 Detaches the monitor panel.
8 • Adjusts the volume.
• Adjusts the volume of the incoming calls. *
2
(KD-AVX77 only)
9 • Displays Open/Tilt screen. ( 6)
• Ejects the disc and displays Open/Tilt screen.
(Hold)
Attaching the monitor panel
Touch panel (see the following pages).
Most of the operations are explained using the touch panel
unless mentioned otherwise.
Monitor panel
USB cable from the rear of the unit, (
47, 51)
