72
USB
USB Standards USB 2.0 Full Speed
Data Transfer Rate Full Speed Maximum 12 Mbps
Low Speed Maximum 1.5 Mbps
Compatible Device Mass storage class
Compatible File System FAT 32/16/12
Max. Current DC 5 V
500 mA
BLUETOOTH (KD-AVX77 only)
Version Bluetooth 1.2 certified
Output Power +4 dBm Max. (Power class 2)
Service Area Within 10 m
Profile HFP (Hands-Free Profile) 1.5
OPP (Object Push Profile) 1.1
A2DP (Advanced Audio Distribution Profile) 1.2
AVRCP (Audio/Video Remote Control Profile) 1.3
MONITOR
Screen Size 5.4 inch wide liquid crystal display
Number of Pixel 576 000 pixels: 800 (horizontal) × 3 (RGB) × 240 (vertical)
Drive Method TFT (Thin Film Transistor) active matrix format
Color System PAL/NTSC
Aspect Ratio 3.32:1 (Super wide)
GENERAL
Power Requirement Operating Voltage DC 14.4 V (11 V to 16 V allowance)
Grounding System Negative ground
Allowable Storage Temperature –10°C to +60°C
Allowable Operating Temperature 0°C to +40°C
Dimensions (W × H × D) Installation Size (approx.) 182 mm × 52 mm × 160 mm
Panel Size (approx.) 188 mm × 58 mm × 12 mm
Mass (approx.) 2.2 kg (excluding the accessories)
Design and specifications are subject to change without notice.
EN_KDAVX7755[A]f.indb 72EN_KDAVX7755[A]f.indb 72 09.4.3 4:47:56 PM09.4.3 4:47:56 PM
