JVC FS-G6 Service Manual

3-8
UX-G6/FS-G6
Electrical parts list (System control & Main amplifier board) Block No. 01
Item Parts number Parts name AreaRemarks
R9506
Q
RE141J-103Y C RESISTOR 10K 5% 1/4W
R9507
Q
RE141J-102Y C RESISTOR 1.0K 5% 1/4W
R9508
Q
RE141J-104Y C RESISTOR 100K 5% 1/4W
R9509
Q
RE141J-103Y C RESISTOR 10K 5% 1/4W
R9901
Q
RZ9006-4R7X F RESISTOR 4.7 1/0W
R9902
Q
RZ9005-100X F RESISTOR 10 1/0W
SP701 VYH7237-001SC IC HOLDER
SW902
Q
SW0513-002 SLIDE SWITCH U,UB
SW911
Q
SW0620-001 SWITCH
S7001
Q
SW0674-001Z TACT SWITCH POWER
S7002
Q
SW0674-001Z TACT SWITCH FM/AM
S7003
Q
SW0674-001Z TACT SWITCH AUX
S7004
Q
SW0674-001Z TACT SWITCH OPEN/CLOSE
S7005
Q
SW0674-001Z TACT SWITCH <<
S7006
Q
SW0674-001Z TACT SWITCH >>
S7007
Q
SW0674-001Z TACT SWITCH PLAY MODE
S7008
Q
SW0674-001Z TACT SWITCH REC MODE
S7009
Q
SW0674-001Z TACT SWITCH CLOCK
S7010
Q
SW0674-001Z TACT SWITCH SET
S7011
Q
SW0674-001Z TACT SWITCH CANCEL
S7012
Q
SW0674-001Z TACT SWITCH EDIT/TITLE
S7013
Q
SW0674-001Z TACT SWITCH DISPLAY/CHARA
S7014
Q
SW0674-001Z TACT SWITCH ENTER
TB901
Q
NZ0079-001Z TAB
TB902
Q
NZ0079-001Z TAB
T9002
QQ
T0274-004 POWER TRANS
X7001
Q
AX0246-001Z RESONATOR
