JVC FS-G6 Service Manual

3-15
UX-G6/FS-G6
Electrical parts list (System control & Analog IN / digital OUT board) Block No. 02
Item Parts number Parts name AreaRemarks
CN451
Q
GA2001F1-06 6P PLUG ASSY FROM KEY PWB
CN452
Q
GB1214K1-16S CONNECTOR TO MICON PWB
CN453
Q
GB1214K1-18S CONNECTOR TO MICON PWB
CN454
Q
GB2510K2-06 CONNECTOR TO MICON PWB
CN455
Q
GB1214K1-18S CONNECTOR TO CD CTL PWB
CN456
Q
GB1214K1-18S CONNECTOR TO CD CTL PWB
CN457
Q
GB2510K2-13 CONNECTOR TO CD CTL PWB
CN501
Q
GA2001F1-05 5P PLUG ASSY
CN502
Q
GB1214J1-16S CONNECTOR
CN503
Q
GB1214J1-18S CONNECTOR
CN504
Q
GB2510J1-06 CONNECTOR
CN506
Q
GF1205F1-10 CONNECTOR
CN507
Q
GB2510J1-07 CONNECTOR
CN508
Q
GA2501C3-05Z CONNECTOR
C4161
Q
ETC1HM-475Z E CAPACITOR 4.7MF 20% 50V
C4162
Q
FZ0202-183Z M CAPACITOR .018MF
C4163
Q
FZ0202-223Z M CAPACITOR .022MF
C4164
Q
FN31HJ-224Z M CAPACITOR .22MF 5% 50V
C4165
Q
FN31HJ-224Z M CAPACITOR .22MF 5% 50V
C4166
Q
FZ0202-562Z M CAPACITOR 5600PF
C4167
Q
ETC1EM-106Z E CAPACITOR 10MF 20% 25V
C4171
Q
EKC1EM-226Z E CAPACITOR 22MF 20% 25V
C4172
Q
EKC1EM-106Z E CAPACITOR 10MF 20% 25V
C4173
Q
CBB1HK-101Y C CAPACITOR 100PF 10% 50V
C4181
Q
CBB1HK-471Y C CAPACITOR 470PF 10% 50V
C4261
Q
ETC1HM-475Z E CAPACITOR 4.7MF 20% 50V
C4262
Q
FZ0202-223Z M CAPACITOR .022MF
C4263
Q
FZ0202-223Z M CAPACITOR .022MF
C4264
Q
FN31HJ-224Z M CAPACITOR .22MF 5% 50V
C4265
Q
FN31HJ-224Z M CAPACITOR .22MF 5% 50V
C4266
Q
FZ0202-562Z M CAPACITOR 5600PF
C4267
Q
ETC1EM-106Z E CAPACITOR 10MF 20% 25V
C4271
Q
EKC1EM-226Z E CAPACITOR 22MF 20% 25V
C4272
Q
EKC1EM-106Z E CAPACITOR 10MF 20% 25V
C4273
Q
CBB1HK-101Y C CAPACITOR 100PF 10% 50V
C4281
Q
CBB1HK-471Y C CAPACITOR 470PF 10% 50V
C4361
Q
ETC1HM-475Z E CAPACITOR 4.7MF 20% 50V
C4362
Q
ETC1CM-476Z E CAPACITOR 47MF 20% 16V
C4372
Q
DGB1HK-102Y C CAPACITOR
C4381
Q
CBB1HK-223Y C CAPACITOR .022MF 10% 50V
C4382
Q
DGB1HK-102Y C CAPACITOR
C4391
Q
EKC1AM-107Z E CAPACITOR 100MF 20% 10V
C4392
Q
CBB1HK-103Y C CAPACITOR .010MF 10% 50V
C5001
Q
CS11HJ-200 C CAPACITOR 20PF 5% 50V
C5002
Q
DCB1HJ-150Y C CAPACITOR
C5003
Q
CBB1HK-103Y C CAPACITOR .010MF 10% 50V
C5004
Q
CZ0202-155Z ML C CAPACITOR 1.5MF
C5005
Q
ETC1AM-107Z-JB E CAPACITOR 100MF 20% 10V
C5006
Q
ETC0JM-108Z E CAPACITOR 1000MF 20% 6.3V
C5007
Q
ETC1AM-107Z-JB E CAPACITOR 100MF 20% 10V
C5008
Q
CZ0202-155Z ML C CAPACITOR 1.5MF
C5009
Q
DGB1HK-102Y C CAPACITOR
C5010
Q
DGB1HK-102Y C CAPACITOR
C5011
Q
DGB1HK-102Y C CAPACITOR
C5012
Q
DGB1HK-102Y C CAPACITOR
C5013
Q
DXB1CM-122Y C CAPACITOR
C5014
Q
DGB1HK-102Y C CAPACITOR
C5016
Q
CZ0205-155Z ML C CAPACITOR 1.5MF
D4361 MTZJ9.1C-T2 Z DIODE
D4371 1SS133-T2 SI DIODE
D4372 1SS133-T2 SI DIODE
D4391 1SS133-T2 SI DIODE
D5001 1SS133-T2 SI DIODE
D5003 1SS133-T2 SI DIODE
D5005 1SS133-T2 SI DIODE
D5006 1SS133-T2 SI DIODE
D5007 1SS133-T2 SI DIODE
EP452
Q
NZ0136-001Z EARTH PLATE FOR H.P GND
IC435 TDA7439 IC
IC436 NJM4580D IC
IC501 UPD784214AGF503 IC
(
MCU
)
IH501 VYH7237-002SC IC HOLDER FOR IC501
J4301
Q
NN0215-001 PIN JACK
J4302 GP1F32T OPTICAL JACK
L5001
QQ
L01BK-100Z INDUCTOR
Q
4171 2SC3576-JVC-T TRANSISTOR
Q
4172 2SC3576-JVC-T TRANSISTOR
Q
4271 2SC3576-JVC-T TRANSISTOR
Q
4272 2SC3576-JVC-T TRANSISTOR
Q
4371 KRA104M-T D.TRANSISTOR
R4161
Q
RE141J-272Y C RESISTOR 2.7K 5% 1/4W
R4162
Q
RE141J-472Y C RESISTOR 4.7K 5% 1/4W
R4164
Q
RE141J-104Y C RESISTOR 100K 5% 1/4W
R4171
Q
RE141J-222Y C RESISTOR 2.2K 5% 1/4W
R4172
Q
RJ146J-221X UNF C.RESISTOR 220 5% 1/4W
R4173
Q
RE141J-223Y C RESISTOR 22K 5% 1/4W
R4174
Q
RE141J-102Y C RESISTOR 1.0K 5% 1/4W
R4175
Q
RE141J-104Y C RESISTOR 100K 5% 1/4W
R4176
Q
RE141J-473Y C RESISTOR 47K 5% 1/4W
R4177
Q
RJ146J-221X UNF C.RESISTOR 220 5% 1/4W
R4178
Q
RE141J-222Y C RESISTOR 2.2K 5% 1/4W
R4181
Q
RE141J-223Y C RESISTOR 22K 5% 1/4W
R4261
Q
RE141J-272Y C RESISTOR 2.7K 5% 1/4W
R4262
Q
RE141J-472Y C RESISTOR 4.7K 5% 1/4W
R4264
Q
RE141J-104Y C RESISTOR 100K 5% 1/4W
R4271
Q
RE141J-222Y C RESISTOR 2.2K 5% 1/4W
R4272
Q
RJ146J-221X UNF C.RESISTOR 220 5% 1/4W
R4273
Q
RE141J-223Y C RESISTOR 22K 5% 1/4W
R4274
Q
RE141J-102Y C RESISTOR 1.0K 5% 1/4W
R4275
Q
RE141J-104Y C RESISTOR 100K 5% 1/4W
R4276
Q
RE141J-473Y C RESISTOR 47K 5% 1/4W
R4277
Q
RJ146J-221X UNF C.RESISTOR 220 5% 1/4W
R4278
Q
RE141J-222Y C RESISTOR 2.2K 5% 1/4W
R4281
Q
RE141J-223Y C RESISTOR 22K 5% 1/4W
R4361
Q
RJ146J-221X UNF C.RESISTOR 220 5% 1/4W
R4371
Q
RE141J-331Y C RESISTOR 330 5% 1/4W
R4391
Q
RE141J-102Y C RESISTOR 1.0K 5% 1/4W
R4392
Q
RE141J-182Y C RESISTOR 1.8K 5% 1/4W
R5001
Q
RE141J-105Y C RESISTOR 1.0M 5% 1/4W
R5002
Q
RE141J-102Y C RESISTOR 1.0K 5% 1/4W
R5003
Q
RE141J-102Y C RESISTOR 1.0K 5% 1/4W
R5005
Q
RE141J-102Y C RESISTOR 1.0K 5% 1/4W
R5007
Q
RE141J-102Y C RESISTOR 1.0K 5% 1/4W
R5008
Q
RE141J-102Y C RESISTOR 1.0K 5% 1/4W
R5009
Q
RE141J-102Y C RESISTOR 1.0K 5% 1/4W
R5011
Q
RE141J-102Y C RESISTOR 1.0K 5% 1/4W
R5012
Q
RE141J-103Y C RESISTOR 10K 5% 1/4W
R5013
Q
RE141J-102Y C RESISTOR 1.0K 5% 1/4W
R5014
Q
RE141J-102Y C RESISTOR 1.0K 5% 1/4W
R5015
Q
RE141J-102Y C RESISTOR 1.0K 5% 1/4W
R5016
Q
RE141J-102Y C RESISTOR 1.0K 5% 1/4W
R5017
Q
RE141J-102Y C RESISTOR 1.0K 5% 1/4W
R5019
Q
RE141J-103Y C RESISTOR 10K 5% 1/4W
R5022
Q
RE141J-102Y C RESISTOR 1.0K 5% 1/4W
R5023
Q
RE141J-102Y C RESISTOR 1.0K 5% 1/4W
R5024
Q
RE141J-102Y C RESISTOR 1.0K 5% 1/4W
Item Parts number Parts name AreaRemarks
