JVC FS-G6 Service Manual

3-27
UX-G6/FS-G6
Electrical parts list (Main board) Block No. 05
Item Parts number Parts name AreaRemarks
CN632
Q
GB2510J1-10 CONNECTOR TO DOLBY PWB
CN633 EMV7141-013M SOCKET ASSY TO TX
CN634
Q
GB2510J1-15 CONNECTOR TO CAPS MOTOR
CN635
Q
GA2001C1-07 7P PLUG ASSY FOR HEAD WIRE
CN636
Q
GB2510J1-06 CONNECTOR TO DOLBY
CN637
Q
GF1205C1-13 CONNECTOR TO DOLBY
CN641
Q
GA2501F1-03 CONNECTOR DOLBY TEST POIN
CN642
Q
GB2510K2-10 CONNECTOR TO MAIN PWB
CN644
Q
GB2510K2-15 CONNECTOR TO UCOM PWB
CN646
Q
GB2510K2-06 CONNECTOR TO MAIN PWB
CN647
Q
GF1205C1-15 CONNECTOR TO MECHA MOTOR
CN667
Q
GF1205F1-13 CONNECTOR TO UCOM PWB
C6101
Q
ETC1HM-225Z E CAPACITOR 2.2MF 20% 50V
C6102
Q
CB31HK-122Z C CAPACITOR 1200PF 10% 50V
C6103
Q
CF11HZ-473 C CAPACITOR .047MF +80:-20%
C6104
Q
CS11HJ-470 C CAPACITOR 47PF 5% 50V
C6105
Q
FLC1HJ-153Z M CAPACITOR .015MF 5% 50V
C6106
Q
FLC1HJ-223Z M CAPACITOR .022MF 5% 50V
C6107
Q
ETC1EM-106Z E CAPACITOR 10MF 20% 25V
C6108
Q
ETC1HM-225Z E CAPACITOR 2.2MF 20% 50V
C6109
Q
CBB1HK-271Y C CAPACITOR 270PF 10% 50V
C6110
Q
CBB1HK-101Y C CAPACITOR 100PF 10% 50V
C6111
Q
CBB1HK-561Y C CAPACITOR 560PF 10% 50V
C6112
Q
CBB1HK-101Y C CAPACITOR 100PF 10% 50V
C6113
Q
ETC1EM-106Z E CAPACITOR 10MF 20% 25V
C6121
Q
TE1H28-225Z E CAPACITOR
C6122
Q
CBB1HK-820Y C CAPACITOR 82PF 10% 50V
C6123
Q
FLC1HJ-822Z M CAPACITOR 8200PF 5% 50V
C6124
Q
ETC1CM-476Z E CAPACITOR 47MF 20% 16V
C6131
Q
FLC1HJ-821Z M.CAPACITOR 820PF 5% 50V
C6132
Q
CBB1HK-331Y C CAPACITOR 330PF 10% 50V
C6171
Q
ETC1HM-475Z E CAPACITOR 4.7MF 20% 50V
C6172
Q
CBB1HK-561Y C CAPACITOR 560PF 10% 50V
C6173
Q
ETC1HM-474Z E CAPACITOR .47MF 20% 50V
C6174
Q
FLC1HJ-154Z M.CAPACITOR .15MF 5% 50V
C6175
Q
ETC1EM-106Z E CAPACITOR 10MF 20% 25V
C6176
Q
ETC1HM-105Z E CAPACITOR 1.0MF 20% 50V
C6182
Q
CBB1HK-561Y C CAPACITOR 560PF 10% 50V
C6201
Q
ETC1HM-225Z E CAPACITOR 2.2MF 20% 50V
C6202
Q
CB31HK-122Z C CAPACITOR 1200PF 10% 50V
C6203
Q
CF11HZ-473 C CAPACITOR .047MF +80:-20%
C6204
Q
CS11HJ-470 C CAPACITOR 47PF 5% 50V
C6205
Q
FLC1HJ-153Z M CAPACITOR .015MF 5% 50V
C6206
Q
FLC1HJ-223Z M CAPACITOR .022MF 5% 50V
C6207
Q
ETC1EM-106Z E CAPACITOR 10MF 20% 25V
C6208
Q
ETC1HM-225Z E CAPACITOR 2.2MF 20% 50V
C6209
Q
CBB1HK-271Y C CAPACITOR 270PF 10% 50V
C6210
Q
CBB1HK-101Y C CAPACITOR 100PF 10% 50V
C6211
Q
CBB1HK-561Y C CAPACITOR 560PF 10% 50V
C6212
Q
CBB1HK-101Y C CAPACITOR 100PF 10% 50V
C6213
Q
ETC1EM-106Z E CAPACITOR 10MF 20% 25V
C6221
Q
TE1H28-225Z E CAPACITOR
C6222
Q
CBB1HK-820Y C CAPACITOR 82PF 10% 50V
C6223
Q
FLC1HJ-822Z M CAPACITOR 8200PF 5% 50V
C6224
Q
ETC1CM-476Z E CAPACITOR 47MF 20% 16V
C6231
Q
FLC1HJ-821Z M.CAPACITOR 820PF 5% 50V
C6232
Q
CBB1HK-331Y C CAPACITOR 330PF 10% 50V
C6271
Q
ETC1HM-475Z E CAPACITOR 4.7MF 20% 50V
C6272
Q
CBB1HK-561Y C CAPACITOR 560PF 10% 50V
C6273
Q
ETC1HM-474Z E CAPACITOR .47MF 20% 50V
C6274
Q
FLC1HJ-154Z M.CAPACITOR .15MF 5% 50V
C6275
Q
ETC1EM-106Z E CAPACITOR 10MF 20% 25V
C6276
Q
ETC1HM-105Z E CAPACITOR 1.0MF 20% 50V
C6282
Q
CBB1HK-561Y C CAPACITOR 560PF 10% 50V
C6301
Q
ETC1CM-476Z E CAPACITOR 47MF 20% 16V
C6302
Q
ETC1CM-476Z E CAPACITOR 47MF 20% 16V
C6303
Q
DGB1HK-102Y C CAPACITOR
C6304
Q
FN31HJ-473Z M CAPACITOR .047MF 5% 50V
C6321
Q
ETC1EM-107Z-JB E CAPACITOR 100MF 20% 25V
C6322
Q
ETC1HM-105Z E CAPACITOR 1.0MF 20% 50V
C6331
Q
ETC1CM-107Z E CAPACITOR 100MF 20% 16V
C6341
Q
DVB1EZ-223Y C CAPACITOR
C6342
Q
DVB1EZ-223Y C CAPACITOR
C6343
Q
ETC1HM-104Z E CAPACITOR .10MF 20% 50V
C6344
Q
ETC1EM-106Z E CAPACITOR 10MF 20% 25V
C6351
Q
FP32AJ-682Z PP CAPACITOR 6800PF 5% 100V
C6353
Q
FLC1HJ-103Z M CAPACITOR .010MF 5% 50V
C6354
Q
ETC1EM-106Z E CAPACITOR 10MF 20% 25V
C6355
Q
FLC1HJ-222Z M CAPACITOR 2200PF 5% 50V
C6356
Q
FLC1HJ-682Z M CAPACITOR 6800PF 5% 50V
C6357
Q
FLC1HJ-222Z M CAPACITOR 2200PF 5% 50V
C6358
Q
ETC1HM-105Z E CAPACITOR 1.0MF 20% 50V
C6359
Q
ETC1EM-106Z E CAPACITOR 10MF 20% 25V
C6360
Q
ETC1HM-105Z E CAPACITOR 1.0MF 20% 50V
C6371
Q
CF31HZ-223Z C CAPACITOR .022MF +80:-20%
C6372
Q
ETC1CM-476Z E CAPACITOR 47MF 20% 16V
C6373
Q
DGB1HK-102Y C CAPACITOR
C6374
Q
ETC1CM-226Z E CAPACITOR 22MF 20% 16V
C6375
Q
ETC1CM-106Z E CAPACITOR 10MF 20% 16V
C6377
Q
ETC1CM-106Z E CAPACITOR 10MF 20% 16V
C6378
Q
FN31HJ-224Z M.CAPACITOR .22MF 5% 50V
C6379
Q
FN31HJ-224Z M.CAPACITOR .22MF 5% 50V
C6380
Q
ETC1CM-227Z E CAPACITOR 220MF 20% 16V
C6601
Q
DGB1HK-102Y C CAPACITOR
C6602
Q
DGB1HK-102Y C CAPACITOR
C6703
Q
CZ0202-155Z ML C CAPACITOR 1.5MF
C6704
Q
ETC1AM-107Z-JB E CAPACITOR 100MF 20% 10V
C6705
Q
ETC1AM-107Z E CAPACITOR 100MF 20% 10V
C6706
Q
DVB1EZ-223Y C CAPACITOR
C6707
Q
DGB1HK-102Y C CAPACITOR
C6708
Q
DGB1HK-102Y C CAPACITOR
C6709
Q
DGB1HK-102Y C CAPACITOR
C6710
Q
DGB1HK-102Y C CAPACITOR
C6711
Q
DGB1HK-102Y C CAPACITOR
C6712
Q
DGB1HK-102Y C CAPACITOR
C6733
Q
ETC1AM-477Z E CAPACITOR 470MF 20% 10V
C6734
Q
FLC1HJ-103Z M CAPACITOR .010MF 5% 50V
C6735
Q
DVB1EZ-223Y C CAPACITOR
C6736
Q
ETC1CM-107Z-JB E CAPACITOR 100MF 20% 16V
D6351 1SS133-T2 SI DIODE
D6371 1SS133-T2 SI DIODE
D6601 SLR-342DC-T LED DOLBY ORENG
D6602 SLR-342DC-T LED REVERSE ORENG
D6603 SLR-342DC-T LED FWD ORENG
D6604 SLR-342DC-T LED REV ORENG
D6605 SLR-342VC-T LED REC RED
D6606 SELU1E10CXM LED BLUE
D6607 MTZJ10C-T2 Z.DIODE
D6608 1SS133-T2 SI DIODE
D6609 1SS133-T2 SI DIODE
D6610 1SS133-T2 SI DIODE
D6702 1SS133-T2 SI DIODE
D6703 1SS133-T2 SI DIODE
D6704 1SS133-T2 SI DIODE
D6705 1SS133-T2 SI DIODE
D6711 1SS133-T2 SI DIODE
Item Parts number Parts name AreaRemarks
