JVC FS-G6 Service Manual

3-28
UX-G6/FS-G6
Electrical parts list (Main board) Block No. 05
Item Parts number Parts name AreaRemarks
D6712 1SS133-T2 SI DIODE
D6731 MTZJ6.2B-T2 ZENER DIODE
D6732 11E2-T5 DIODE
EP601
Q
NZ0136-001Z EARTH PLATE
EP602 E409182-001SM GRAND TERMINAL
EP603 E409182-001SM GRAND TERMINAL
EP604
Q
NZ0136-001Z EARTH PLATE
IC631 NJM4580L IC
IC632 UPC1228HA IC
IC633 UPC1330HA IC
IC634 BA8221AN IC
IC635 HA12136A IC
IC671 MN171601ADL IC
IC673 LB1641 IC
IC675 MN1381/P
Q
/-T IC
L6101
QQ
L30BJ-562Z INDUCTOR
L6102
QQ
L30BJ-223Z INDUCTOR
L6201
QQ
L30BJ-562Z INDUCTOR
L6202
QQ
L30BJ-223Z INDUCTOR
L6351
QQ
R0588-001 OSC COIL
L6711
QQ
L231K-1R0Y INDUCTOR
L6712
QQ
L01BK-100Z INDUCTOR
Q
6101 KRC114M-T TRANSISTOR
Q
6121 2SK301/P
Q
/-T TRANSISTOR
(
FET
)
Q
6171 2SC3576-JVC-T TRANSISTOR
Q
6172 2SC3576-JVC-T TRANSISTOR
Q
6173 2SC3576-JVC-T TRANSISTOR
Q
6201 KRC114M-T TRANSISTOR
Q
6221 2SK301/P
Q
/-T TRANSISTOR
(
FET
)
Q
6271 2SC3576-JVC-T TRANSISTOR
Q
6272 2SC3576-JVC-T TRANSISTOR
Q
6273 2SC3576-JVC-T TRANSISTOR
Q
6341 2SC2785/FE/-T TRANSISTOR
Q
6342 2SC2785/FE/-T TRANSISTOR
Q
6351 2SC3576-JVC-T TRANSISTOR
Q
6352 2SC3576-JVC-T TRANSISTOR
Q
6353 2SC1740S/RS/-T TRANSISTOR
Q
6354 2SC1740S/RS/-T TRANSISTOR
Q
6371 KRA107M-T D.TRANSISTOR
Q
6731 2SC2001/LK/-T TRANSISTOR
Q
6732 2SC2785/FE/-T TRANSISTOR
Q
6733 2SD400MP/EF/-T TRANSISTOR
Q
6734 KRA104M-T D.TRANSISTOR PHOTO DTC
Q
6735 2SC2785/FE/-T TRANSISTOR PHOTO DTC
R6101
Q
RE141J-153Y C RESISTOR 15K 5% 1/4W
R6102
Q
RE141J-473Y C RESISTOR 47K 5% 1/4W
R6103
Q
RE141J-333Y C RESISTOR 33K 5% 1/4W
R6104
Q
RE141J-153Y C RESISTOR 15K 5% 1/4W
R6105
Q
RE141J-182Y C RESISTOR 1.8K 5% 1/4W
R6106
Q
RE141J-221Y C RESISTOR 220 5% 1/4W
R6107
Q
RE141J-562Y C RESISTOR 5.6K 5% 1/4W
R6108
Q
RE141J-562Y C RESISTOR 5.6K 5% 1/4W
R6109
Q
RE141J-683Y C RESISTOR 68K 5% 1/4W
R6110
Q
RE141J-153Y C RESISTOR 15K 5% 1/4W
R6121
Q
RE141J-622Y C RESISTOR 6.2K 5% 1/4W
R6122
Q
RE141J-912Y C RESISTOR 9.1K 5% 1/4W
R6123
Q
RE141J-334Y C RESISTOR 330K 5% 1/4W
R6124
Q
RE141J-271Y C RESISTOR 270 5% 1/4W
R6125
Q
RE141J-105Y C RESISTOR 1.0M 5% 1/4W
R6126
Q
RE141J-223Y C RESISTOR 22K 5% 1/4W
R6127
Q
RE141J-102Y C RESISTOR 1.0K 5% 1/4W
R6131
Q
RE141J-100Y C RESISTOR 10 5% 1/4W
R6171
Q
RE141J-273Y C RESISTOR 27K 5% 1/4W
R6172
Q
RE141J-222Y C RESISTOR 2.2K 5% 1/4W
R6173
Q
RE141J-153Y C RESISTOR 15K 5% 1/4W
R6174
Q
RE141J-103Y C RESISTOR 10K 5% 1/4W
R6175
Q
RE141J-221Y C RESISTOR 220 5% 1/4W
R6176
Q
RE141J-223Y C RESISTOR 22K 5% 1/4W
R6177
Q
RE141J-102Y C RESISTOR 1.0K 5% 1/4W
R6178
Q
RE141J-123Y C RESISTOR 12K 5% 1/4W
R6179
Q
RE141J-332Y C RESISTOR 3.3K 5% 1/4W
R6201
Q
RE141J-153Y C RESISTOR 15K 5% 1/4W
R6202
Q
RE141J-473Y C RESISTOR 47K 5% 1/4W
R6203
Q
RE141J-333Y C RESISTOR 33K 5% 1/4W
R6204
Q
RE141J-153Y C RESISTOR 15K 5% 1/4W
R6205
Q
RE141J-182Y C RESISTOR 1.8K 5% 1/4W
R6206
Q
RE141J-221Y C RESISTOR 220 5% 1/4W
R6207
Q
RE141J-562Y C RESISTOR 5.6K 5% 1/4W
R6208
Q
RE141J-562Y C RESISTOR 5.6K 5% 1/4W
R6209
Q
RE141J-683Y C RESISTOR 68K 5% 1/4W
R6210
Q
RE141J-153Y C RESISTOR 15K 5% 1/4W
R6221
Q
RE141J-622Y C RESISTOR 6.2K 5% 1/4W
R6222
Q
RE141J-912Y C RESISTOR 9.1K 5% 1/4W
R6223
Q
RE141J-334Y C RESISTOR 330K 5% 1/4W
R6224
Q
RE141J-271Y C RESISTOR 270 5% 1/4W
R6225
Q
RE141J-105Y C RESISTOR 1.0M 5% 1/4W
R6226
Q
RE141J-223Y C RESISTOR 22K 5% 1/4W
R6227
Q
RE141J-102Y C RESISTOR 1.0K 5% 1/4W
R6231
Q
RE141J-100Y C RESISTOR 10 5% 1/4W
R6271
Q
RE141J-273Y C RESISTOR 27K 5% 1/4W
R6272
Q
RE141J-222Y C RESISTOR 2.2K 5% 1/4W
R6273
Q
RE141J-153Y C RESISTOR 15K 5% 1/4W
R6274
Q
RE141J-103Y C RESISTOR 10K 5% 1/4W
R6275
Q
RE141J-221Y C RESISTOR 220 5% 1/4W
R6276
Q
RE141J-223Y C RESISTOR PB OUT 300MV
R6277
Q
RE141J-102Y C RESISTOR 1.0K 5% 1/4W
R6278
Q
RE141J-123Y C RESISTOR 12K 5% 1/4W
R6279
Q
RE141J-332Y C RESISTOR 3.3K 5% 1/4W
R6301
Q
RE141J-181Y C RESISTOR 180 5% 1/4W
R6302
Q
RE141J-181Y C RESISTOR 180 5% 1/4W
R6321
Q
RE141J-471Y C RESISTOR 470 5% 1/4W
R6322
Q
RE141J-103Y C RESISTOR 10K 5% 1/4W
R6331
Q
RE141J-101Y C RESISTOR 100 5% 1/4W
R6341
Q
RE141J-472Y C RESISTOR 4.7K 5% 1/4W
R6342
Q
RE141J-223Y C RESISTOR 22K 5% 1/4W
R6343
Q
RE141J-105Y C RESISTOR 1.0M 5% 1/4W
R6344
Q
RE141J-104Y C RESISTOR 100K 5% 1/4W
R6345
Q
RE141J-105Y C RESISTOR 1.0M 5% 1/4W
R6346
Q
RE141J-104Y C RESISTOR 100K 5% 1/4W
R6347
Q
RE141J-332Y C RESISTOR 3.3K 5% 1/4W
R6351
Q
RJ146J-100X UNF.C RESISTOR 10 5% 1/4W
R6352
Q
RE141J-332Y C RESISTOR 3.3K 5% 1/4W
R6353
Q
RE141J-104Y C RESISTOR 100K 5% 1/4W
R6354
Q
RE141J-681Y C RESISTOR 680 5% 1/4W
R6355
Q
RE141J-561Y C RESISTOR 560 5% 1/4W
R6356
Q
RE141J-511Y C RESISTOR 510 5% 1/4W
R6357
Q
RE141J-222Y C RESISTOR 2.2K 5% 1/4W
R6358
Q
RE141J-104Y C RESISTOR 100K 5% 1/4W
R6359
Q
RJ146J-6R8X UNF C.RESISTOR 6.8 5% 1/4W
R6360
Q
RE141J-563Y C RESISTOR 56K 5% 1/4W
R6361
Q
RE141J-563Y C RESISTOR 56K 5% 1/4W
R6363
Q
RJ146J-100X UNF.C RESISTOR 10 5% 1/4W
R6367
Q
RE141J-474Y C RESISTOR 470K 5% 1/4W
R6371
Q
RE141J-224Y C RESISTOR 220K 5% 1/4W
R6372
Q
RE141J-103Y C RESISTOR 10K 5% 1/4W
R6373
Q
RE141J-183Y C RESISTOR 18K 5% 1/4W
