JVC FS-G6 Service Manual

3-29
UX-G6/FS-G6
Electrical parts list (Main board) Block No. 05
Item Parts number Parts name AreaRemarks
R6374
Q
RZ9005-220X F.RESISTOR 22 1/0W
R6376
Q
RE141J-103Y C RESISTOR 10K 5% 1/4W
R6601
Q
RE141J-221Y C RESISTOR 220 5% 1/4W
R6602
Q
RE141J-221Y C RESISTOR 220 5% 1/4W
R6603
Q
RE141J-331Y C RESISTOR 330 5% 1/4W
R6604
Q
RE141J-331Y C RESISTOR 330 5% 1/4W
R6605
Q
RE141J-161Y C RESISTOR 160 5% 1/4W
R6606
Q
RE141J-151Y C RESISTOR 150 5% 1/4W
R6607
Q
RE141J-104Y C RESISTOR 100K 5% 1/4W
R6608
Q
RE141J-104Y C RESISTOR 100K 5% 1/4W
R6609
Q
RE141J-104Y C RESISTOR 100K 5% 1/4W
R6610
Q
RE141J-111Y C RESISTOR 110 5% 1/4W
R6611
Q
RE141J-111Y C RESISTOR 110 5% 1/4W
R6701
Q
RE141J-104Y C RESISTOR 100K 5% 1/4W
R6702
Q
RE141J-104Y C RESISTOR 100K 5% 1/4W
R6703
Q
RE141J-104Y C RESISTOR 100K 5% 1/4W
R6704
Q
RE141J-104Y C RESISTOR 100K 5% 1/4W
R6705
Q
RE141J-104Y C RESISTOR 100K 5% 1/4W
R6706
Q
RE141J-104Y C RESISTOR 100K 5% 1/4W
R6707
Q
RE141J-104Y C RESISTOR 100K 5% 1/4W
R6708
Q
RE141J-102Y C RESISTOR 1.0K 5% 1/4W
R6709
Q
RE141J-102Y C RESISTOR 1.0K 5% 1/4W
R6710
Q
RE141J-102Y C RESISTOR 1.0K 5% 1/4W
R6711
Q
RE141J-104Y C RESISTOR 100K 5% 1/4W
R6712
Q
RE141J-101Y C RESISTOR 100 5% 1/4W
R6714
Q
RE141J-821Y C RESISTOR 820 5% 1/4W
R6715
Q
RE141J-102Y C RESISTOR 1.0K 5% 1/4W
R6716
Q
RE141J-102Y C RESISTOR 1.0K 5% 1/4W
R6730
Q
RE141J-105Y C RESISTOR 1.0M 5% 1/4W
R6731
Q
RE141J-104Y C RESISTOR 100K 5% 1/4W
R6732
Q
RE141J-473Y C RESISTOR 47K 5% 1/4W
R6733
Q
RE141J-122Y C RESISTOR 1.2K 5% 1/4W
R6734
Q
RE141J-334Y C RESISTOR 330K 5% 1/4W
R6735
Q
RE141J-104Y C RESISTOR 100K 5% 1/4W
R6736
Q
RE141J-152Y C RESISTOR 1.5K 5% 1/4W
R6737
Q
RE141J-821Y C RESISTOR 820 5% 1/4W
R6738
Q
RE141J-473Y C RESISTOR 47K 5% 1/4W
R6739
Q
RE141J-103Y C RESISTOR 10K 5% 1/4W
R6740
Q
RE141J-101Y C RESISTOR 100 5% 1/4W
R6741
Q
RJ146J-1R0X UNF C.RESISTOR 1.0 5% 1/4W
R6742
Q
RL01DJ-220X OMF RESISTOR 22 5% 1/1W
R6743
Q
RE141J-561Y C RESISTOR 560 5% 1/4W
R6744
Q
RL01DJ-220X OMF RESISTOR 22 5% 1/1W
R6745
Q
RE141J-471Y C RESISTOR 470 5% 1/4W
SS601 LV41684-001A SPRING
SS602 LV41684-001A SPRING
S6601
Q
SW0674-001Z TACT SWITCH
S6602
Q
SW0674-001Z TACT SWITCH
S6603
Q
SW0674-001Z TACT SWITCH
S6604
Q
SW0674-001Z TACT SWITCH
S6605
Q
SW0674-001Z TACT SWITCH
S6606
Q
SW0674-001Z TACT SWITCH
TP631
Q
NZ0104-001 POST PIN
TP632
Q
NZ0104-001 POST PIN
VR611
Q
VP0004-501Z SEMI.V.RESISTOR H TYPE
VR612
Q
VP0004-104Z SEMI.V.RESISTOR H TYPE
VR613
Q
VP0004-104Z SEMI.V.RESISTOR H TYPE
VR614
Q
VP0008-503Z SEMI.V.RESISTOR V TYPE
VR621
Q
VP0004-501Z SEMI.V.RESISTOR H TYPE
VR622
Q
VP0004-104Z SEMI.V.RESISTOR H TYPE
VR623
Q
VP0004-104Z SEMI.V.RESISTOR H TYPE
VR624
Q
VP0008-503Z SEMI.V.RESISTOR V TYPE
VR671
Q
VP0008-102Z SEMI.V.RESISTOR V TYPE
W 648
Q
JK016-051600 SIN CR C-B WIRE
X6701
Q
AX0247-001Z RESONATOR
