JVC FS-G6 Service Manual

3-11
UX-G6/FS-G6
Parts list (XT-UXG6 General assembly)
Item
Parts number Parts name
Area
Q'ty
Description
Block No
.
M2MM
1 LV10278-001A FRONT PANEL 1
2 LV31438-002A BUTTON 1 PLATING
3 LV41295-001A REMOTE LENS 1
4 LV31458-001A FRONT PLATE 1
5 E406971-222 JVC MARK 1
6 LV41317-002A LENS
(
A
)
1
7 LV41318-001A LENS
(
B
)
1
8 LV41750-001A LABEL 1
9
Q
YSBSF2608Z T.SCREW 7 FOR SW PWB
10 E75896-002 FELT SPACER 2 FOR FOOT
11
Q
YSBST3006Z T.SCREW 3 FOR F.PANE+B.CHASSIS
12 LV10275-001A BOTTOM CHASSIS 1
13 E47227-029 FOOT 2
14
Q
YSBST3006Z T.SCREW 2
15 --------------- CD MECHA 1
16 --------------- CD LOADING BASE 1
17 E26756-004 CD CLAMPER BASE 1
18
Q
YSBSF3008Z SCREW 2 CLAMP B.+LOADING BASE
19 E406293-001 SPECIAL SCREW 1
20 E306835-221SS CD CLAMPER 1
21 VYH7313-003 MAGNET 1
22 E306836-003 C.D.YOKE 1
23 E102358-222K CD TRAY 1
24
Q
YSBSF3008Z SCREW 1 FOR TRAY
25 LV20520-001A CD FITTING 1
26 LV31459-001A FITTING PLATE 1
27
Q
YSBST3006Z T.SCREW 3 FOR CD LOADING
28
Q
YSBSF2608Z T.SCREW 2 PWB+CLAMPER BASE
29
Q
YSBST3006Z T.SCREW 1 TUNER+CHASSIS
30
Q
YSBST3006Z T.SCREW 1 PWB
(
L
)
+CHASSIS
31
Q
YSBSF2608Z T.SCREW 3 LOADING+PWB
32 E75896-001 FELT SPACER 1 FS401
34
Q
YSBST3006Z T.SCREW 1 CHASSIS+PWB
35 VYSA1R3-049 SPACER 1
36 LV10273-002A/S/ METAL COVER 1
38
Q
YSDSG3008N T.SCREW 2 M.COVER+B.CHASSIS
39
Q
YSDSG3008N T.SCREW 4 M.COVER+R.PANEL
40 LV20521-007A REAR PANEL 1 U,UB
LV20521-008A REAR PANEL 1 UP
41
Q
YSDSG3008N T.SCREW 1
42 E409257-001 GND TERMINAL 1 FOR EARTH
43
QQ
R1086-001 NOISE FILTER 1
44
Q
YSDSG3008N T.SCREW 2 FOR ANT.
45
Q
YSDSG3008N T.SCREW 2 FOR SYS.CONNECT
46
Q
YSDSG3008N T.SCREW 1 FOR AUX IN
47
Q
YSDSG3008N T.SCREW 1 FOR OPTICAL OUT
48
Q
JJ010-051000 SIN CR C-C WIRE 1
49
Q
JJ010-061501 SIN CR C-C WIRE 1
50
Q
U
Q
B12-1010BJ FFC WIRE 1 TUNER-MICOM
51
Q
U
Q
910-1508AJ CARD WIRE 1 CD PICK
52 WJS0015-002A E-FL/RB WIRE 1 19 PIN SYSTEM WIRE
54 LV41773-001A SHEET 1
