JVC FS-S57 Service Manual

(No.MB205)1-21
3.3.5 Removing the CD tramecha assembly
(See Fig.12)
• Prior to performing the following procedure, remove the servo
control board.
(1) Turn over the body and remove the three screws F attach-
ing the tramecha.
Fig.12
F
CD Tramecha assembly
F
F

JVC FS-S57 Specifications

General

Brand	JVC
Model	FS-S57
Category	Stereo System
Language	English
