JVC FS-S57 Service Manual

3-10
Power board
Block No. [0][2][0][0]
J2000 QNB0118-002 SPK.TERMINAL
J2100 QNN0420-001 SURROUND JACK
J5100 QSW0993-001 ROTARY ENCODER
J5600 QNS0170-001 HEADPHONE JACK
K5600 QQR0621-001Z COIL
K7023 QQR0621-001Z COIL
K7025 QQR0621-001Z COIL
K7049 QQR0621-001Z COIL
K7300 QQR0621-001Z COIL
PP700 QZW0038-001 WIRE CLAMP
RY200 QSK0109-001 RELAY
S5100 QSW0651-001Z TACT SWITCH
S5101 QSW0651-001Z TACT SWITCH
S5102 QSW0651-001Z TACT SWITCH
S5103 QSW0651-001Z TACT SWITCH
S5104 QSW0651-001Z TACT SWITCH
S5105 QSW0651-001Z TACT SWITCH
S5106 QSW0651-001Z TACT SWITCH
S5107 QSW0651-001Z TACT SWITCH
S5108 QSW0651-001Z TACT SWITCH
S5109 QSW0651-001Z TACT SWITCH
S5110 QSW0651-001Z TACT SWITCH
S5111 QSW0651-001Z TACT SWITCH
S5112 QSW0651-001Z TACT SWITCH
S5113 QSW0651-001Z TACT SWITCH
S5114 QSW0651-001Z TACT SWITCH
S5115 QSW0651-001Z TACT SWITCH
S5116 QSW0651-001Z TACT SWITCH
S5200 QSW0651-001Z TACT SWITCH
X7000 QAX0718-001Z CRYSTAL 8.000000MHz
 Symbol No. Part No. Part Name Description Local
 IC340 STK432-070 IC
 IC341 KIA7810API IC
 IC342 KIA7808API IC
 IC343 PQ033RD01SZ IC
Q1100 KTC3199/GL/-T TRANSISTOR
Q1200 KTA1023/OY/-T TRANSISTOR
Q1201 KTC3199/GL/-T TRANSISTOR
Q1202 KTC3199/GL/-T TRANSISTOR
Q1500 KTC3199/GL/-T TRANSISTOR
Q3100 KRA102M-T DIGI TRANSISTOR
Q3101 2SC3576-JVC-T TRANSISTOR
Q3102 2SC3576-JVC-T TRANSISTOR
Q3103 KTA1268/GL/-T TRANSISTOR
Q3104 KTA1268/GL/-T TRANSISTOR
Q3105 KTC3199/GL/-T TRANSISTOR
Q3106 KTC3199/GL/-T TRANSISTOR
Q3107 KTA1267/YG/-T TRANSISTOR
Q3200 KRA102M-T DIGI TRANSISTOR
Q3201 2SC3576-JVC-T TRANSISTOR
Q3202 2SC3576-JVC-T TRANSISTOR
D1100 1N4003S-T5 SI DIODE
D1101 1SS133-T2 DIODE
D1200 1SS133-T2 DIODE
D1201 MTZJ5.6B-T2 Z DIODE
 D1300 1N5402M-20 DIODE
 D1301 1N5402M-20 DIODE
 D1302 1N5402M-20 DIODE
 D1303 1N5402M-20 DIODE
 D1400 1N4003S-T5 SI DIODE
 D1401 1N4003S-T5 SI DIODE
 D1402 1N4003S-T5 SI DIODE
 D1403 1N4003S-T5 SI DIODE
D1500 1SS133-T2 DIODE
D1501 MTZJ5.1B-T2 Z DIODE
 D3100 MTZJ9.1B-T2 Z DIODE
D3101 1SS133-T2 DIODE
 Symbol No. Part No. Part Name Description Local
D3102 1SS133-T2 DIODE
D3103 1SS133-T2 DIODE
 D3104 MTZJ9.1B-T2 Z DIODE
 D3300 MTZJ11C-T2 Z DIODE
D3301 1SS133-T2 DIODE
 D3302 MTZJ11C-T2 Z DIODE
D3303 1SS133-T2 DIODE
 D3304 MTZJ3.6B-T2 Z DIODE
C1100 QETM1EM-108 E CAPACITOR 1000uF 25V M
 C1101 QCZ9105-472 C CAPACITOR 4700pF 250V M
C1200 QEKC1CM-107Z E CAPACITOR 100uF 16V M
C1300 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C1301 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C1302 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C1303 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C1400 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C1401 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C1402 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C1403 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C1500 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1600 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
C3000 QEZ0570-228 E CAPACITOR 2200uF
C3001 QEZ0570-228 E CAPACITOR 2200uF
C3002 QETM1EM-228 E CAPACITOR 2200uF 25V M
C3100 QCBB1HK-101Y C CAPACITOR 100pF 50V K
C3101 QCBB1HK-101Y C CAPACITOR 100pF 50V K
C3102 QTE1V06-106Z E CAPACITOR 10uF 35V
C3103 QTE1V06-106Z E CAPACITOR 10uF 35V
C3104 QEKC1HM-475Z E CAPACITOR 4.7uF 50V M
C3105 QCBB1HK-101Y C CAPACITOR 100pF 50V K
C3106 QENC1HM-106Z BP E CAPACITOR 10uF 50V M
C3107 QCSB1HJ-100Y C CAPACITOR 10pF 50V J
C3109 QETN1HM-476Z E CAPACITOR 47uF 50V M
C3110 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C3111 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C3112 QFLC1HJ-223Z M CAPACITOR 0.022uF 50V J
C3113 FQCF31HZ-223Z D.CAPACITOR
C3114 QETN1HM-106Z E CAPACITOR 10uF 50V M
C3115 QETN1HM-106Z E CAPACITOR 10uF 50V M
C3116 FQCF31HZ-223Z D.CAPACITOR
C3117 QENC1HM-106Z BP E CAPACITOR 10uF 50V M
C3118 QCBB1HK-101Y C CAPACITOR 100pF 50V K
C3119 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C3120 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C3121 QCSB1HJ-100Y C CAPACITOR 10pF 50V J
C3122 QETN1HM-476Z E CAPACITOR 47uF 50V M
C3123 QETN1HM-226Z E CAPACITOR 22uF 50V M
C3124 FQCF31HZ-223Z D.CAPACITOR
C3125 QETN1HM-226Z E CAPACITOR 22uF 50V M
C3126 QETN1VM-476Z E CAPACITOR 47uF 35V M
C3200 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C3300 QETN1HM-106Z E CAPACITOR 10uF 50V M
C3301 QETN1HM-106Z E CAPACITOR 10uF 50V M
C3302 QETN1HM-106Z E CAPACITOR 10uF 50V M
C3303 QETN1HM-106Z E CAPACITOR 10uF 50V M
C3304 QETN1HM-106Z E CAPACITOR 10uF 50V M
C3306 QETN1HM-106Z E CAPACITOR 10uF 50V M
R1101 QRE141J-332Y C RESISTOR 3.3k
Ω 1/4W J
 R1102 QRZ9037-335 COMP RESISTOR 3.3M Ω 1/2W K
R1200 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R1201 QRE141J-102Y C RESISTOR 1k
Ω 1/4W J
R1202 QRE141J-102Y C RESISTOR 1k
Ω 1/4W J
R1203 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R1500 QRE141J-103Y C RESISTOR 10k
Ω 1/4W J
R1501 QRE141J-102Y C RESISTOR 1k
Ω 1/4W J
R1502 QRE141J-473Y C RESISTOR 47k
Ω 1/4W J
R3100 QRE141J-472Y C RESISTOR 4.7k
Ω 1/4W J
R3101 QRE141J-472Y C RESISTOR 4.7k Ω 1/4W J
R3102 QRE141J-203Y C RESISTOR 20k
Ω 1/4W J
R3103 QRE141J-221Y C RESISTOR 220
Ω 1/4W J
R3104 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R3105 QRE141J-103Y C RESISTOR 10k
Ω 1/4W J
R3106 QRE141J-473Y C RESISTOR 47k
Ω 1/4W J
R3107 QRE141J-473Y C RESISTOR 47k Ω 1/4W J
R3108 QRE141J-473Y C RESISTOR 47k
Ω 1/4W J
R3109 FQRJ143J-821X UNF C RESISTOR
 Symbol No. Part No. Part Name Description Local
