JVC FS-S57 Service Manual

3-11
CD servo board
Block No. [0][3][0][0]
 R3110 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
R3111 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
R3112 QRE141J-333Y C RESISTOR 33k Ω 1/4W J
R3113 QRT01DJ-R22X MF RESISTOR 0.22 Ω 1W J
R3114 QRT01DJ-R22X MF RESISTOR 0.22 Ω 1W J
R3115 QRJ146J-101X UNF C RESISTOR 100
Ω 1/4W J
R3116 QRE141J-221Y C RESISTOR 220
Ω 1/4W J
R3117 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R3118 QRE141J-222Y C RESISTOR 2.2k Ω 1/4W J
R3119 QRE141J-221Y C RESISTOR 220 Ω 1/4W J
R3120 QRE141J-222Y C RESISTOR 2.2k Ω 1/4W J
R3121 QRT01DJ-R22X MF RESISTOR 0.22 Ω 1W J
R3122 QRT01DJ-R22X MF RESISTOR 0.22 Ω 1W J
R3123 QRJ146J-101X UNF C RESISTOR 100 Ω 1/4W J
R3124 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R3125 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
 R3126 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
R3127 QRE141J-473Y C RESISTOR 47k Ω 1/4W J
R3128 QRE141J-124Y C RESISTOR 120k Ω 1/4W J
R3129 FQRJ143J-821X UNF C RESISTOR
R3130 QRE141J-103Y C RESISTOR 10k
Ω 1/4W J
R3131 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
 R3132 QRZ9006-4R7X F.RESISTOR 4.7 Ω 1/4W J
R3133 QRE141J-823Y C RESISTOR 82k Ω 1/4W J
R3134 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R3135 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R3136 QRE141J-122Y C RESISTOR 1.2k Ω 1/4W J
R3137 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R3138 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
R3150 QRE141J-472Y C RESISTOR 4.7k Ω 1/4W J
R3200 FQRJ143J-821X UNF C RESISTOR
R3201 FQRJ143J-821X UNF C RESISTOR
R3202 FQRJ143J-821X UNF C RESISTOR
R3203 FQRJ143J-821X UNF C RESISTOR
R3204 QRE141J-221Y C RESISTOR 220 Ω 1/4W J
R3206 QRE141J-473Y C RESISTOR 47k Ω 1/4W J
R3207 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R3208 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R3300 QRT01DJ-R47X MF RESISTOR 0.47 Ω 1W J
R3301 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R3302 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R3303 QRT01DJ-R33X MF RESISTOR 0.33 Ω 1W J
R3304 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R3305 QRE141J-183Y C RESISTOR 18k Ω 1/4W J
R3310 QRE141J-272Y C RESISTOR 2.7k Ω 1/4W J
L3100 QQLZ035-R39 COIL 0.39uH
L3101 QQLZ035-R39 COIL 0.39uH
 T1100 QQT0253-012 POWER TRANSF
 CN100 QGA7901F2-02 CONNECTOR W-B (1-2)
CN101 QGA7901F2-02 CONNECTOR W-B (1-2)
CN102 QGA3901C1-05 CONNECTOR W-B (1-5)
CN103 QGB2510J1-14 CONNECTOR B-B (1-14)
CN104 QGA2501F1-04 CONNECTOR W-B (1-4)
CN350 QGB2510K2-14 CONNECTOR B-B (1-14)
CN351 QGB2510K2-12 CONNECTOR B-B (1-12)
CN352 QGB2510K2-09 CONNECTOR B-B (1-9)
EP300 QNZ0136-001Z EARTH PLATE
 LF110 QQR1321-001 LINE FILTER
PP300 QZW0038-001 WIRE CLAMP
 RY110 QSK0124-001 RELAY
TH332 QAD0015-103Z THERMISTOR 10k
Ω
Z1100 QNG0003-001Z FUSE CLIP
Z1101 QNG0003-001Z FUSE CLIP
Z1400 QNG0003-001Z FUSE CLIP
Z1401 QNG0003-001Z FUSE CLIP
 Symbol No. Part No. Part Name Description Local
IC201 BR24L08FV-W-X IC
 Symbol No. Part No. Part Name Description Local
IC251 MN101C61GMB3 IC
IC601 AN22002A-W IC
IC651 MN6627911AC1 IC
IC671 A42L2604V-45L IC
IC681 SN74AHC1G32DC-X IC
IC682 SN74LV08APW-X IC
IC691 XC6206P182M-X IC
IC801 AN4801SB-W IC
Q291 2SB1424/QR/-W TRANSISTOR
Q631 2SA1037AK/RS/-X TRANSISTOR
C201 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C251 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C252 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C253 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C255 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C258 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C259 NDC31HJ-101X C CAPACITOR 100pF 50V J
C291 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C603 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C604 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C605 NDC31HJ-331X C CAPACITOR 330pF 50V J
C606 NDC31HJ-151X C CAPACITOR 150pF 50V J
C610 NCB31CK-563X C CAPACITOR 0.056uF 16V K
C611 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C612 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C614 NCB31CK-393X C CAPACITOR 0.039uF 16V K
C615 NCB31HK-272X C CAPACITOR 2700pF 50V K
C616 NCB31HK-182X C CAPACITOR 1800pF 50V K
C621 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C622 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C623 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C624 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C631 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C632 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C633 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C641 NDC31HJ-101X C CAPACITOR 100pF 50V J
C651 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C652 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C653 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C654 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C655 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C656 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C657 NDC31HJ-471X C CAPACITOR 470pF 50V J
C658 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C659 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C661 NCB31HK-102X C CAPACITOR 1000pF 50V K
C662 NCB21CK-124X C CAPACITOR 0.12uF 16V K
C663 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C664 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C665 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C666 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C667 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C669 NCB31HK-272X C CAPACITOR 2700pF 50V K
C672 NCB31HK-272X C CAPACITOR 2700pF 50V K
C673 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C674 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C675 NDC31HJ-100X C CAPACITOR 10pF 50V J
C676 NDC31HJ-100X C CAPACITOR 10pF 50V J
C677 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C678 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C679 NCB21CK-105X C CAPACITOR 1uF 16V K
C681 NCB21CK-105X C CAPACITOR 1uF 16V K
C801 QERF1AM-227Z E CAPACITOR 220uF 10V M
C802 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C803 NCB31AK-474X C CAPACITOR 0.47uF 10V K
C804 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C805 NCB31HK-102X C CAPACITOR 1000pF 50V K
C806 NCB31HK-152X C CAPACITOR 1500pF 50V K
R253 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R255 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R256 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R257 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R258 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R259 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R261 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
 Symbol No. Part No. Part Name Description Local
