JVC FS-S57 Service Manual

3-12
Loading switch board
Block No. [0][4][0][0]
R262 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R263 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R264 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R265 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R267 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R271 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R274 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R278 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R281 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R282 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R283 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R284 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R285 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R286 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R287 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R288 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R289 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R290 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R291 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R292 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R293 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R294 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R295 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R296 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R297 NRSA63J-122X MG RESISTOR 1.2k Ω 1/16W J
R298 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R601 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R602 NRSA63J-392X MG RESISTOR 3.9k Ω 1/16W J
R603 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R604 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R605 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R606 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R607 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R608 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R611 NRSA63J-392X MG RESISTOR 3.9k Ω 1/16W J
R613 NRSA63J-392X MG RESISTOR 3.9k Ω 1/16W J
R617 NRSA63J-122X MG RESISTOR 1.2k Ω 1/16W J
R621 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R622 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R624 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R625 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R631 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R632 NRSA63J-3R9X MG RESISTOR 3.9 Ω 1/16W J
R634 NRSA63J-3R9X MG RESISTOR 3.9 Ω 1/16W J
R635 NRSA63J-100X MG RESISTOR 10 Ω 1/16W J
R651 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R652 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R653 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R654 NRSA63J-823X MG RESISTOR 82k Ω 1/16W J
R655 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R656 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R657 NRSA63J-561X MG RESISTOR 560
Ω 1/16W J
R658 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R659 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R661 NRSA63J-153X MG RESISTOR 15k
Ω 1/16W J
R662 NRSA02J-101X MG RESISTOR 100
Ω 1/10W J
R663 NRSA63J-273X MG RESISTOR 27k Ω 1/16W J
R664 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R665 NRSA63J-681X MG RESISTOR 680 Ω 1/16W J
R666 NRSA63J-561X MG RESISTOR 560
Ω 1/16W J
R667 NRSA63J-681X MG RESISTOR 680
Ω 1/16W J
R668 NRSA63J-561X MG RESISTOR 560 Ω 1/16W J
R669 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R671 NRSA63J-333X MG RESISTOR 33k
Ω 1/16W J
R672 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R673 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R674 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R675 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R676 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R677 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R678 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R679 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R681 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R682 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R801 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R802 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R803 NRSA63J-562X MG RESISTOR 5.6k
Ω 1/16W J
R805 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
 Symbol No. Part No. Part Name Description Local
R806 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R807 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R809 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R811 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R812 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R814 NRSA63J-183X MG RESISTOR 18k
Ω 1/16W J
R815 NRSA63J-153X MG RESISTOR 15k
Ω 1/16W J
R816 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R818 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
CN251 QGF1036F1-15 CONNECTOR FFC/FPC (1-15)
CN252 QGA2001F1-02 CONNECTOR W-B (1-2)
CN253 QGA2001F1-03 CONNECTOR W-B (1-3)
CN601 QGF1006F2-16W CONNECTOR FFC/FPC (1-16)
CN602 QGA2001F1-06 CONNECTOR W-B (1-6)
CN651 QGF1036F1-17 CONNECTOR FFC/FPC (1-17)
K654 NQR0007-002X FERRITE BEADS
X251 QAX0684-001Z C RESONATOR 8.38MHz
X651 NAX0476-001X CRYSTAL 33.8688MHz
 Symbol No. Part No. Part Name Description Local
IC1 LB1641 IC
IC2 LB1641 IC
D1 MTZJ6.2A-T2 Z DIODE
C1 QEKC1AM-107Z E CAPACITOR 100uF 10V M
C2 QCFB1HZ-104Y C CAPACITOR 0.1uF 50V Z
C3 QFLC1HJ-103Z M CAPACITOR 0.01uF 50V J
C5 QFLC1HJ-103Z M CAPACITOR 0.01uF 50V J
C6 QCFB1HZ-104Y C CAPACITOR 0.1uF 50V Z
C7 QCFB1HZ-104Y C CAPACITOR 0.1uF 50V Z
CN1 QGF1036F1-15 CONNECTOR FFC/FPC (1-15)
CN2 QGB1214J1-08S CONNECTOR B-B (1-8)
CN3 QGB1214K1-08S CONNECTOR B-B (1-8)
SW1 QSW0844-001 PUSH SWITCH
SW2 QSW0844-001 PUSH SWITCH
SW3 QSW0844-001 PUSH SWITCH
SW4 QSW0844-001 PUSH SWITCH
SW5 QSW0844-001 PUSH SWITCH
SW6 QSW0854-002 PUSH SW
SW7 QSW0886-002 DETECT SWITCH
SW8 QSW0886-002 DETECT SWITCH
 Symbol No. Part No. Part Name Description Local
