JVC FS-S57 Service Manual

3-8
Electrical parts list
Micon board
Block No. [0][1][0][0]
 Symbol No. Part No. Part Name Description Local
IC520 GP1UM281XK IR DETECT UNIT 38kHz
IC900 MN101C57DEB MASK MICON
IC901 LC75345M-X IC
Q2209 2SD601A/QR/-X TRANSISTOR
Q2210 2SD601A/QR/-X TRANSISTOR
Q2211 2SC2001/K/-T TRANSISTOR
Q2600 KTC3200/GL/-T TRANSISTOR
Q2601 KTA1268/GL/-T TRANSISTOR
Q2602 KTD863/Y/-T TRANSISTOR
Q7300 2SD601A/QR/-X TRANSISTOR
Q7301 UN2215-X TRANSISTOR
Q7400 KTC3199/GL/-T TRANSISTOR
Q7401 KTC3199/GL/-T TRANSISTOR
Q7402 KTC3199/GL/-T TRANSISTOR
Q7500 2SB709A/R/-X TRANSISTOR
Q7501 UN2213-X DIGI TRANSISTOR
Q7550 UN2215-X TRANSISTOR
Q7600 2SB709A/R/-X TRANSISTOR
Q7601 UN2211-X TRANSISTOR
Q7602 2SC2001/K/-T TRANSISTOR
Q7700 KRC104M-T TRANSISTOR
Q7701 KRC102M-T DIGI TRANSISTOR
Q7801 KTC3199/GL/-T TRANSISTOR
Q7802 UN2213-X DIGI TRANSISTOR
D2000 MTZJ24C-T2 Z DIODE
D2100 1SS133-T2 DIODE
D2101 1SS133-T2 DIODE
D2205 1SS133-T2 DIODE
D2206 1SS133-T2 DIODE
D2230 1SS133-T2 DIODE
D2600 MTZJ5.1C-T2 Z DIODE
 D2601 1N4003S-T5 SI DIODE
 D2602 1N4003S-T5 SI DIODE
 D2603 1N4003S-T5 SI DIODE
D2604 MTZJ18C-T2 Z DIODE
D2605 MTZJ22C-T2 Z.DIODE
D5200 SPR-39MVWF LED RED-GREEN
D5400 SELU1E10WXM-P LED
D5401 SELU1E10WXM-P LED
D5402 SELU1E10WXM-P LED
D7300 1SS133-T2 DIODE
D7301 1SS133-T2 DIODE
D7302 MTZJ5.1C-T2 Z DIODE
D7303 1SS133-T2 DIODE
D7304 1SS133-T2 DIODE
D7305 1SS133-T2 DIODE
D7306 MA700A-T2 SB DIODE
D7500 1SS133-T2 DIODE
D7501 1SS133-T2 DIODE
D7550 1SS133-T2 DIODE
D7551 1SS355-X SI DIODE
C2005 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2007 QTE1V06-106Z E CAPACITOR 10uF 35V
C2008 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2009 QTE1V06-106Z E CAPACITOR 10uF 35V
C2010 QTE1V06-106Z E CAPACITOR 10uF 35V
C2011 QFLC1HJ-272Z M CAPACITOR 2700pF 50V J
C2012 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C2013 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C2014 QFVF1HJ-184Z MF CAPACITOR 0.18uF 50V J
C2015 QFVF1HJ-184Z MF CAPACITOR 0.18uF 50V J
C2016 QFVF1HJ-154Z MF CAPACITOR 0.15uF 50V J
C2017 QTE1C06-226Z E CAPACITOR 22uF 16V
C2018 QFVF1HJ-124Z MF CAPACITOR 0.12uF 50V J
C2019 QFVF1HJ-274Z MF CAPACITOR 0.27uF 50V J
C2026 QFLC1HJ-183Z M CAPACITOR 0.018uF 50V J
C2100 NCB31HK-221X C CAPACITOR 220pF 50V K
C2101 NCB31HK-221X C CAPACITOR 220pF 50V K
C2102 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
C2105 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2107 QTE1V06-106Z E CAPACITOR 10uF 35V
C2108 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2109 QTE1V06-106Z E CAPACITOR 10uF 35V
C2110 QTE1V06-106Z E CAPACITOR 10uF 35V
C2111 QFLC1HJ-272Z M CAPACITOR 2700pF 50V J
C2112 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C2113 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C2114 QFVF1HJ-184Z MF CAPACITOR 0.18uF 50V J
C2115 QFVF1HJ-184Z MF CAPACITOR 0.18uF 50V J
C2116 QFVF1HJ-154Z MF CAPACITOR 0.15uF 50V J
C2117 QTE1C06-226Z E CAPACITOR 22uF 16V
C2118 QFVF1HJ-124Z MF CAPACITOR 0.12uF 50V J
C2119 QFVF1HJ-274Z MF CAPACITOR 0.27uF 50V J
C2126 QFLC1HJ-183Z M CAPACITOR 0.018uF 50V J
C2213 QETN1HM-106Z E CAPACITOR 10uF 50V M
C2215 QETN1CM-107Z E CAPACITOR 100uF 16V M
C2220 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C2221 QETN1CM-107Z E CAPACITOR 100uF 16V M
C2222 QETN1CM-107Z E CAPACITOR 100uF 16V M
C2223 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C2230 QETN1HM-105Z E CAPACITOR 1uF 50V M
C2231 NCB31AK-154X C CAPACITOR 0.15uF 10V K
C2239 QETN1HM-105Z E CAPACITOR 1uF 50V M
C2507 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
C2508 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
C2600 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2601 QETN1JM-476Z E CAPACITOR 47uF 63V M
C2602 QETN1HM-107Z E CAPACITOR 100uF 50V M
C2604 QETN1HM-474Z E CAPACITOR 0.47uF 50V M
C2605 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C2607 QETN1JM-476Z E CAPACITOR 47uF 63V M
C2702 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
C5100 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C5101 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C5104 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C5105 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C5200 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C5201 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C5202 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C5600 QCBB1HK-103Y C CAPACITOR 0.01uF 50V K
C5601 QCBB1HK-103Y C CAPACITOR 0.01uF 50V K
C5700 QCBB1HK-103Y C CAPACITOR 0.01uF 50V K
C5701 QCBB1HK-101Y C CAPACITOR 100pF 50V K
C5702 QCBB1HK-101Y C CAPACITOR 100pF 50V K
C5703 QCBB1HK-101Y C CAPACITOR 100pF 50V K
C5704 QCBB1HK-101Y C CAPACITOR 100pF 50V K
C7012 NDC31HJ-330X C CAPACITOR 33pF 50V J
C7013 NDC31HJ-330X C CAPACITOR 33pF 50V J
C7018 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C7237 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C7240 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C7300 QETN1CM-107Z E CAPACITOR 100uF 16V M
C7301 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C7302 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C7303 QETN0JM-108Z E CAPACITOR 1000uF 6.3V M
C7304 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C7305 QETN1CM-107Z E CAPACITOR 100uF 16V M
C7400 QETN1VM-476Z E CAPACITOR 47uF 35V M
C7401 QETN1VM-476Z E CAPACITOR 47uF 35V M
C7402 QETN1VM-476Z E CAPACITOR 47uF 35V M
C7500 QETN1HM-106Z E CAPACITOR 10uF 50V M
C7550 QEKC1HM-106Z E CAPACITOR 10uF 50V M
C7551 QEKC1CM-107Z E CAPACITOR 100uF 16V M
C7600 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C7608 QETN1AM-227Z E CAPACITOR 220uF 10V M
C7800 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
R2010 NRSA63J-752X MG RESISTOR 7.5k Ω 1/16W J
R2011 NRSA63J-752X MG RESISTOR 7.5k Ω 1/16W J
R2012 NRSA63J-152X MG RESISTOR 1.5k
Ω 1/16W J
R2013 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R2014 NRSA63J-303X MG RESISTOR 30k Ω 1/16W J
R2015 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
 Symbol No. Part No. Part Name Description Local
