FS-SD1000
1-31
Input Output Mode
IN1
0
1
0
1
IN2
0
0
1
1
OUT1
H
L
L
OUT2
L
H
L
MOTOR
STOP
CW/CCW
CCW/CW
BRAKE
2
10
1
Standby
circuit
Heat
interception
IN1
IN2
GND
5
M
OUT1
OUT2
8
3
9
7
Vref
Vs
Vcc
TA8409F-W (IC108) : Motor driver
1.Block diagram
2.Pin function
