JVC FS-SD5

Item
Parts number Parts name Area
Parts list
Q'ty
Description
Block No. M1MM
1 LV10325-003A
FRONT PANEL
1
FS-SD9
LV10325-001A
FRONT PANEL
1
FS-SD5/SD7
2 LV31677-201A
PUSH BUTTON 1
2
ABS/PLATING
3 LV41520-001A
INDICATOR 1
STANDBY LED
4 QYSDSF2608Z
SCREW
7
FRONT+SW PWB+BT
5 LV31678-004A
LENS
1
FS-SD9
LV31678-002A
LENS
1
FS-SD5/SD7
6 LV31679-001A
LCD CASE
1
ABS
7 LV41519-001A
SHEET
1
LCD FILTER
8 LV31680-001A
REFLECTOR
1
PMMA/MILKY
9 KSM-770ABA
CD MECHA
1
CD MECHA
10 LV40770-002A
INSULATOR
3
11 LV10326-002A
CD CHASSIS
1
MIPS
12 LV31687-001A
MOTOR BASE
1
ABS
13 LV41522-001A
WORM GEAR
1
POM
14 LV41523-001A
WORM WHEEL
1
POM
15 LV41536-001A
PULLEY
1
POM
16 LV41598-001A
BELT
1
17 QAR0100-001
DC MOTOR
1
18 QYSPSP3004Z
SCREW
2
DC MOTOR+M.BASE
19 LV31688-001A
WHEEL STOPPER
1
ABS
20 LV31691-001A
G.WHEEL(L)
1
POM
21 LV31690-002A
ARM
2
ABS
22 LV31693-001A
G.GEAR(L)
1
PBT
23 LV31695-002A
ARM GEAR(L)
1
FS-SD9
LV31695-001A
ARM GEAR(L)
1
FS-SD5/SD7
24 LV31697-002A
GEAR BASE(L)
1
PBT
25 LV31692-001A
G.WHEEL(R)
1
POM
26 LV31694-001A
G.GEAR(R)
1
PBT
27 LV31696-002A
ARM GEAR(R)
1
FS-SD9
LV31696-001A
ARM GEAR(R)
1
FS-SD5/SD7
28 LV31698-002A
GEAR BASE(R)
1
PBT
29 LV32127-001A
GEAR BKT(L)
1
EGC T1
30 LV32128-001A
GEAR BKT(R)
1
EGC T1
31 LV41929-001A
SHAFT 4
4
FS-SD5/SD7
LV41929-002A
SHAFT 4
4
FS-SD9
32 LV41930-002A
SHAFT 5
1
FS-SD9
LV41930-001A
SHAFT 5
2
FS-SD5/SD7
33 LV31701-002A
DOOR BASE
2
FS-SD9
LV31701-001A
DOOR BASE
1
FS-SD5/SD7
34 QYSPSFG2605N
SCREW
6
DOOR BASE+ARM
35 QYSDSF2606Z
SCREW
4
SW.PWB+G.BASE
36 QYSDSF2606Z
SCREW
6
G.BKT+G.BASE
37 LV10328-003A
CD DOOR
1
FS-SD5/SD7
LV10328-004A
CD DOOR
1
FS-SD9
38 LV31702-002A
DOOR COVER
1
FS-SD5
LV31702-004A
DOOR COVER
1
FS-SD7
LV31702-006A
DOOR COVER
1
FS-SD9
(General asembly)
Item
Parts number Parts name Area
Parts list
Q'ty
Description
Block No. M1MM
39 LV41758-001A
CUSTOM SCREW
4
D.C.BKT+D.COVER
40 LV41587-001A
SPECIAL SCREW
4
CD DOOR+D.BASE
41 LV10329-001A
BOTTOM CHASSIS
1
EGC T1.0
42 LV30064-068A
SPACER
1
43 QYSBST4006Z
T.SCREW
4
BOTTOM.C+TRANS
44 QYSBST3006Z
T.SCREW
5
BOTTOM+MAIN PWB
45 VKZ4001-110
WIRE HOLDER
1
46 LV31901-002A
BURRER
1
BETW.AC&BTM
47 QAR0148-001
FAN MOTOR
1
48 QYSPST3012Z
T.SCREW
2
49 QYSBST3006Z
T.SCREW
2
50 LV41799-001A
FAN BRACKET
1
51 LV10327-001A
TOP PANEL
1
FS-SD5/SD7
LV10327-003A
TOP PANEL
1
FS-SD9
52 LV41821-002A
FELT
4
FS-SD9
LV41821-001A
FELT
4
FS-SD5/SD7
53 LV31681-201A
PUSH BUTTON 3
1
ABS/PLATING
54 QYSDSF2608Z
SCREW
2
P.BTN3+PWB+TOP
55 LV41828-001A
PROTECTOR
1
56 LV31682-201A
PUSH BUTTON 2
1
ABS/PLATINGR
57 QYSDSF2608Z
SCREW
2
P.BTN2+PWB+TOP
59 QUQ910-1607BJ
FFC WIRE
1
60 LV31686-001A
LED.BOX
1
FS-SD5/SD7
LV31686-002A
LED BOX
1
FS-SD9
61 LV41521-001A
LED COVER
1
ABS
62 LV31704-001A
IC HOLDER
1
AL T2
63 QYSBSF3010Z
SCREW
2
IC+IC HOLDER
64 LV31849-001A
HEAT SINK2
1
AL T2
65 QYSBSF3010Z
SCREW
2
66 LV31705-002A
HEAT SINK
1
AL
67 LV31850-001A
HEAT SINK3
1
AL T2
68 QYSBSF3010Z
SCREW
2
69 QYSBSF3008Z
SCREW
2
IC HOLDER+H.SIN
70 LV10330-002A
SIDE PANEL(L)
1
FS-SD9
LV10330-001A
SIDE PANEL(L)
1
FS-SD5/SD7
71 QYSSST3006Z
SCREW
4
72 LV10331-002A
SIDE PANEL(R)
1
FS-SD9
LV10331-001A
SIDE PANEL(R)
1
FS-SD5/SD7
73 LV41832-001A
FOOT
4
SIDE PANEL
74 LV10332-003A
REAR PANEL
1
FS-SD5/SD7
LV10332-006A
REAR PANEL
1
FS-SD9
75 QYSDSF2608N
SCREW
5
REAR+TOP
76 QYSDSG3008N
T.SCREW
7
REAR+JACK
77 QYSDSG3008N
T.SCREW
3
REAR+BOTTOM
78 LV32005-006A
NAME PLATE
1
FS-SD9
LV31706-006A
NAME PLATE
1
FS-SD5
LV32004-006A
NAME PLATE
1
FS-SD7
80 QYSDSF2608Z
SCREW
7
CD CHASSIS+TOP
(General assembly)
FS-SD5/FS-SD7/FS-SD9FS-SD5/FS-SD7/FS-SD9
3-4
