JVC FS-SD5 Schematic Diagrams

FS-SD5/FS-SD7/FS-SD9
3-7
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 01
C1925 QFZ0160-223Z PP CAPA IM FS-SD9
C1925 QFN31HJ-103Z M.M.CAPACITOR FS-SD5/SD7
C1926 QCBB1HK-103Y C CAPACITOR LV
C1927 QCBB1HK-103Y C CAPACITOR HV
C1928 QCBB1HK-103Y C CAPACITOR .010MF 10% 50V
C1929 NCB21HK-103X C CAPACITOR
C3101 QTE1V06-106Z E CAPACITOR IN
C3102 QDGB1HK-102Y C CAPACITOR IN
C3103 QCBB1HK-104Y TF CAPACITOR OUT
C3104 QCBB1HK-104Y TF CAPACITOR OUT
C3201 QTE1V06-106Z E CAPACITOR IN
C3202 QDGB1HK-102Y C CAPACITOR IN
C3203 QCBB1HK-104Y TF CAPACITOR OUT
C3204 QCBB1HK-104Y TF CAPACITOR OUT
C3301 QETN1CM-106Z E CAPACITOR BEEP
C3302 NCS21HJ-152X C CAPACITOR
C3303 QCBB1HK-104Y TF CAPACITOR FS-SD9
C3303 QCBB1HK-103Y CER.CAPACITOR-S FS-SD5/SD7
C3304 QETN1HM-105Z E CAPACITOR 1.0MF 20% 50V
C3306 QTE1E06-476Z E CAPACITOR FS-SD9
C3306 QTE1V28-107Z AL E.CAPACITOR FS-SD5/SD7
C3308 QETN1CM-336Z E CAPACITOR ON.TIME
C3309 QETN1HM-105Z E CAPACITOR AHB NF
C3310 QETN1HM-105Z E CAPACITOR AHB NF
C3311 QCBB1HK-473Y C CAPACITOR AHB NF
C3312 QCBB1HK-473Y C CAPACITOR AHB NF
C8001 NCB21HK-103X C CAPACITOR
C8002 QER41AM-107 E CAPACITOR 100MF 20% 10V
C8003 NCB21HK-223X C CAPACITOR
C8004 NCS21HJ-101X C CAPACITOR
C8101 QER41AM-227 E.CAPA. I.M 220MF 20% 10V
C8102 NCB21HK-103X C CAPACITOR
C8201 QER41AM-227 E.CAPA. I.M 220MF 20% 10V
C8202 NCB21HK-103X C CAPACITOR
D 1 1SS133-T2 SI DIODE
D 2 1SS133-T2 SI DIODE
D 3 1SS133-T2 SI DIODE
D 4 1SS133-T2 SI DIODE
DI801 QLD0120-001 LCD
D1301 1SS133-T2 SI DIODE AHB
D1302 MTZJ5.1A-T2 ZENER DIODE AHB
D1303 1SS133-T2 SI DIODE AHB
D1304 1SS133-T2 SI DIODE HP.MUTE
D1305 1SS133-T2 SI DIODE S.MUTE
D1801 DSK10C-T1 DIODE M.DRIV
D1901 D5SBA20-S1 SI DIODE HV
D1902 D3SBA20-S1 DIODE LV
D1903 1SS133-T2 SI DIODE SW10
D1904 MTZJ5.6C-T2 ZENER DIODE SW10
D1905 MTZJ10A-T2 ZENER DIODE SW10
D1906 MTZJ11A-T2 Z.DIODE I.M L.FIL
D1907 1SS133-T2 SI DIODE L.FIL
D1908 1SS133-T2 SI DIODE CD6.5
D1909 MTZJ6.8B-T2 NER DIODE CD6.5
D1910 6A10E2 SI DIODE LV
D1911 MTZJ6.8A-T2 ZENER DIODE BL7
D1912 MTZJ10A-T2 ZENER DIODE BL7
D1913 MTZJ6.8B-T2 NER DIODE US5V
D1914 MTZJ3.9B-T2 Z DIODE IM TU5
D1915 1SS133-T2 SI DIODE TU5
D1916 1SS133-T2 SI DIODE TU5
D1917 1SS133-T2 SI DIODE
D3302 1SS133-T2 SI DIODE AHB NF
D3303 1SS133-T2 SI DIODE AHB NF
D8001 SPR-39MVWF LED POWER/STANDBY
D8002 1SS133-T2 SI DIODE
D8021 TLYH156P/ST/ LED FS-SD9
D8021 SELU1E50CM LED FS-SD5/SD7
D8022 SELU1E50CM LED FS-SD5/SD7
D8022 TLYH156P/ST/ LED FS-SD9
D8025 MTZJ10C-T2 Z DIODE FS-SD5/SD7
D8031 TLYH156P/ST/ LED FS-SD9
D8031 SELU1E56BM LED FS-SD5/SD7
D8032 SELU1E56BM L.E.D FS-SD5/SD7
D8032 TLYH156P/ST/ LED FS-SD9
D8035 MA3100/M/-X ZENER DIODE FS-SD5/SD7
EP131 QNZ0136-001Z EARTH PLATE
IC 1 TA2057N IC
IC 2 LC72136N IC
IC101 NJM4580DD IC AHB
IC102 BA15218F-XE IC HP
IC108 TA8409F-W IC M.DRIVE
IC191 UPC78L05J-T I C US5
IC301 LA4905 IC
IC801 GP1U271X RM RECIVER
J 1 QNB0014-001 ANT TERMINAL AM/FM ANT COAX
J1901 QNC0030-001 AC INLET
J3001 QNB0092-001 SPK TERMINAL
J8301 QNS0162-001 JACK HP.JACK
K1801 QQR0779-001Z INDUCTOR
K8301 QQR0601-001Z FERRITE BEADS
L 1 QQR0796-001 COIL BLOCK MW RF/OSC
L 4 QQL231K-221Y INDUCTOR
LF111 QQR0590-001 FILTER MPX.FILTER
LF121 QQR0590-001 FILTER MPX.FILTER
LF191 QQR1145-001 LINE FILTER EXCEPT J
L1801 QQL25CK-221Z INDUCTOR M.DRIVER
L8101 QQL231K-470Y INDUCTOR
L8201 QQL231K-470Y INDUCTOR
PP101 QZW0038-001 WIRE CLAMP
PP102 QZW0038-001 WIRE CLAMP
PP103 QZW0038-001 WIRE CLAMP
PP104 QZW0038-001 WIRE CLAMP
Q
1 2SC2668/O/-T TRANSISTOR
Q
6 DTA114YKA-X TRANSISTOR
Q
7 2SA1037AK/R/-X TRANSISTOR
Q
8 2SA1037AK/R/-X TRANSISTOR
Q
1101 2SD2114K/VW/-X CHIP TR.C.M AHB
Q
1102 2SC2412K/R/-X TRANSISTOR HP.MUTE
Q
1201 2SD2114K/VW/-X CHIP TR.C.M AHB
Q
1202 2SC2412K/R/-X TRANSISTOR HP.MUTE
Q
1301 DTA123EKA-X DIGITAL.TR S.MUTE.D
Q
1302 DTA123EKA-X DIGITAL.TR HP.MUTE.D
Q
1801 2SC2412K/R/-X TRANSISTOR M.DRIV
Q
1901 2SA1359/OY/ TRANSISTOR SW10
Q
1902 2SC2412K/R/-X TRANSISTOR SW10
Q
1903 2SC2412K/R/-X TRANSISTOR SW10
Q
1904 2SA1037AK/R/-X TRANSISTOR SW10
Q
1905 DTA144TKA-X TRANSISTOR SW10
Q
1906 DTC144TKA-X TRANSISTOR SW10
Q
1907 2SD2144S/VW/-T TRANSISTOR L.FIL
Q
1908 2SA1359/OY/ TRANSISTOR CD6.5
Q
1909 2SC2412K/R/-X TRANSISTOR CD6.5
Q
1910 2SC2412K/R/-X TRANSISTOR CD6.5
Q
1912 2SA1175/FE/-T TRANSISTOR BL7
Q
1913 2SC2412K/R/-X TRANSISTOR BL7
Item
Parts number Parts name Area
Remarks
(Main board)
