JVC FS-SD5 Schematic Diagrams

FS-SD5/FS-SD7/FS-SD9
3-9
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 01
R1919 NRSA02J-512X MG RESISTOR SW10
R1920 NRSA02J-102X MG RESISTOR R.FIL
R1921 QRZ9006-4R7X F RESISTOR BL7
R1922 QRZ9006-4R7X F RESISTOR US5V
R1923 QRZ9006-4R7X F RESISTOR TO.MICOM+B
R1924 NRSA02J-103X MG RESISTOR CD6.5
R1925 NRSA02J-561X MG RESISTOR BL7
R1926 NRSA02J-123X MG RESISTOR BL7
R1927 NRSA02J-103X MG RESISTOR BL7
R1928 NRSA02J-122X MG RESISTOR TU5
R1929 NRSA02J-273X MG RESISTOR TU5
R1930 NRSA02J-102X MG RESISTOR TU5
R1931 NRSA02J-390X MG RESISTOR TU5
R1932 NRSA02J-331X MG RESISTOR CD6.5
R1933 NRSA02J-681X MG RESISTOR CD6.5
R1934 NRSA02J-152X MG RESISTOR CD6.5
R1935 NRSA02J-272X MG RESISTOR CD6.5
R1936 NRSA02J-151X MG RESISTOR CD6.5
R1937 NRSA02J-562X MG RESISTOR
R1938 NRSA02J-102X MG RESISTOR
R3101 QRE141J-562Y C RESISTOR FS-SD5
R3101 QRE141J-432Y C RESISTOR FS-SD7/SD9
R3102 QRE141J-682Y C RESISTOR FS-SD5
R3102 QRE141J-103Y C RESISTOR FS-SD7/SD9
R3103 QRE141J-2R2Y C RESISTOR OUT
R3104 QRE141J-2R2Y C RESISTOR OUT
R3105 NRSA02J-223X MG RESISTOR AHB NF
R3106 NRSA02J-223X MG RESISTOR AHB NF
R3107 QRE141J-222Y C RESISTOR S.MUTE
R3201 QRE141J-562Y C RESISTOR FS-SD5
R3201 QRE141J-432Y C RESISTOR FS-SD7/SD9
R3202 QRE141J-682Y C RESISTOR FS-SD5
R3202 QRE141J-103Y C RESISTOR FS-SD7/SD9
R3203 QRE141J-2R2Y C RESISTOR OUT
R3204 QRE141J-2R2Y C RESISTOR OUT
R3205 NRSA02J-223X MG RESISTOR AHB NF
R3206 NRSA02J-223X MG RESISTOR AHB NF
R3207 QRE141J-222Y C RESISTOR S.MUTE
R3303 QRE141J-103Y C RESISTOR ST.BY
R3304 NRSA02J-682X MG RESISTOR AHB NF
R3305 NRSA02J-682X MG RESISTOR AHB NF
R8001 NRSA02J-102X MG RESISTOR
R8002 NRSA02J-123X MG RESISTOR
R8003 NRSA02J-331X MG RESISTOR
R8004 NRSA02J-331X MG RESISTOR
R8005 NRSA02J-561X MG RESISTOR
R8007 NRSA02J-432X MG RESISTOR
R8010 NRSA02J-104X MG RESISTOR
R8021 NRSA02J-101X MG RESISTOR FS-SD5/SD7
R8021 NRSA02J-391X MG RESISTOR FS-SD9
R8022 NRSA02J-101X MG RESISTOR FS-SD5/SD7
R8022 NRSA02J-391X MG RESISTOR FS-SD9
R8031 NRSA02J-431X MG RESISTOR FS-SD5/SD7
R8031 NRSA02J-561X MG RESISTOR FS-SD9
R8032 NRSA02J-561X MG RESISTOR FS-SD9
R8032 NRSA02J-431X MG RESISTOR FS-SD5/SD7
R8051 NRSA02J-101X MG RESISTOR
R8052 NRSA02J-272X MG RESISTOR
R8053 NRSA02J-332X MG RESISTOR
R8054 NRSA02J-562X MG RESISTOR
R8055 NRSA02J-123X MG RESISTOR
R8056 NRSA02J-393X MG RESISTOR
R8057 NRSA02J-101X MG RESISTOR
R8058 NRSA02J-272X MG RESISTOR
R8059 NRSA02J-332X MG RESISTOR
R8060 NRSA02J-562X MG RESISTOR
R8061 NRSA02J-123X MG RESISTOR
R8062 NRSA02J-393X MG RESISTOR
R8101 NRSA02J-220X MG RESISTOR
R8102 NRSA02J-222X MG RESISTOR
R8103 NRSA02J-272X MG RESISTOR
R8201 NRSA02J-220X MG RESISTOR
R8202 NRSA02J-222X MG RESISTOR
R8203 NRSA02J-272X MG RESISTOR
R8301 NRSA02J-222X MG RESISTOR
R8302 NRSA02J-222X MG RESISTOR
S1901 VMZ0126-003 VOLTAGE SELCTOR U.ONLY
S8001 QSW0683-001Z PUSH SW I.M OP/CL
S8002 QSW0683-001Z PUSH SW I.M POWER
S8003 QSW0683-001Z PUSH SW I.M VOL+
S8004 QSW0683-001Z PUSH SW I.M VOL-
S8005 QSW0683-001Z PUSH SW I.M TIMER
S8006 QSW0683-001Z PUSH SW I.M CLOCK
S8007 QSW0683-001Z PUSH SW I.M UP
S8008 QSW0683-001Z PUSH SW I.M CD
S8009 QSW0683-001Z PUSH SW I.M STOP
S8010 QSW0683-001Z PUSH SW I.M DOWN
S8011 QSW0683-001Z PUSH SW I.M AHB
S8012 QSW0683-001Z PUSH SW I.M PRESET TU
S8013 QSW0683-001Z PUSH SW I.M TUNER
S8014 QSW0683-001Z PUSH SW I.M AUX
T 1 QQR0793-001 IFT
TU 1 QAU0037-001 FRONT END FM TU
X 1 QAX0402-001 CRYSTAL
Z1901 QNG0003-001Z FUSE CLIP FOR F1901
Z1902 QNG0003-001Z FUSE CLIP FOR F1901
Z1903 QNG0003-001Z FUSE CLIP FOR F1902
Z1904 QNG0003-001Z FUSE CLIP FOR F1902
Z1905 QNG0003-001Z FUSE CLIP FOR F1903
Z1906 QNG0003-001Z FUSE CLIP FOR F1903
(Main board)
