JVC FS-SD5 - Page 43

FS-SD5/FS-SD7/FS-SD9
3-12
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 02
R6122 NRSA02J-151X MG RESISTOR
R6123 NRSA02J-151X MG RESISTOR
R7001 NRSA02J-822X MG RESISTOR
R7002 NRSA02J-822X MG RESISTOR
R7003 NRSA02J-103X MG RESISTOR
R7004 NRSA02J-103X MG RESISTOR
R7005 NRSA02J-331X MG RESISTOR
R7006 NRSA02J-222X MG RESISTOR
R7007 NRSA02J-222X MG RESISTOR
R7008 NRSA02J-222X MG RESISTOR
R7009 NRSA02J-222X MG RESISTOR
R7010 NRSA02J-222X MG RESISTOR
R7011 NRSA02J-222X MG RESISTOR
R7012 NRSA02J-222X MG RESISTOR
R7013 NRSA02J-102X MG RESISTOR
R7014 NRSA02J-103X MG RESISTOR
R7016 NRSA02J-222X MG RESISTOR
R7017 NRSA02J-222X MG RESISTOR
R7018 NRSA02J-0R0X MG RESISTOR
R7019 NRSA02J-102X MG RESISTOR
R7020 NRSA02J-222X MG RESISTOR
R7021 NRSA02J-102X MG RESISTOR
R7022 NRSA02J-102X MG RESISTOR
R7023 NRSA02J-102X MG RESISTOR
R7024 NRSA02J-102X MG RESISTOR
R7025 NRSA02J-102X MG RESISTOR
R7026 NRSA02J-102X MG RESISTOR
R7027 NRSA02J-102X MG RESISTOR
R7028 NRSA02J-222X MG RESISTOR
R7029 NRSA02J-103X MG RESISTOR
R7030 NRSA02J-222X MG RESISTOR
R7031 NRSA02J-103X MG RESISTOR
R7032 NRSA02J-222X MG RESISTOR
R7033 NRSA02J-103X MG RESISTOR
R7034 NRSA02J-222X MG RESISTOR
R7035 NRSA02J-103X MG RESISTOR
R7036 NRSA02J-222X MG RESISTOR
R7037 NRSA02J-222X MG RESISTOR
R7038 NRSA02J-273X MG RESISTOR VERSION
R7039 NRSA02J-562X MG RESISTOR VERSION
R7040 NRSA02J-102X MG RESISTOR
R7041 NRSA02J-103X MG RESISTOR
R7042 NRSA02J-103X MG RESISTOR
R7043 NRSA02J-103X MG RESISTOR
R7044 NRSA02J-103X MG RESISTOR
R7045 NRSA02J-222X MG RESISTOR
R7046 NRSA02J-222X MG RESISTOR
R7048 NRSA02J-102X MG RESISTOR
R7049 NRSA02J-102X MG RESISTOR
R7050 NRSA02J-104X MG RESISTOR
R7051 NRSA02J-473X MG RESISTOR
R7052 NRSA02J-333X MG RESISTOR
R7053 NRSA02J-222X MG RESISTOR
R7054 NRSA02J-222X MG RESISTOR
R7055 NRSA02J-222X MG RESISTOR
R7056 NRSA02J-103X MG RESISTOR
R7057 NRSA02J-103X MG RESISTOR
R7058 NRSA02J-103X MG RESISTOR
R7059 NRSA02J-103X MG RESISTOR
R7060 NRSA02J-103X MG RESISTOR
R7061 NRSA02J-103X MG RESISTOR
R7062 NRSA02J-222X MG RESISTOR
R7063 NRSA02J-222X MG RESISTOR
R7064 NRSA02J-471X MG RESISTOR
R7065 NRSA02J-222X MG RESISTOR
R7066 NRSA02J-222X MG RESISTOR
R7067 NRSA02J-222X MG RESISTOR
R7068 NRSA02J-222X MG RESISTOR
R7069 NRSA02J-222X MG RESISTOR
R7070 NRSA02J-102X MG RESISTOR
R7071 NRSA02J-102X MG RESISTOR
R7072 NRSA02J-222X MG RESISTOR
R7073 NRSA02J-102X MG RESISTOR
R7074 NRSA02J-103X MG RESISTOR
R7075 NRSA02J-103X MG RESISTOR
R7076 NRSA02J-103X MG RESISTOR
R7077 NRSA02J-103X MG RESISTOR
R7078 NRSA02J-103X MG RESISTOR
R7079 NRSA02J-512X MG RESISTOR
SP603 VYH7653-001 IC HOLDER IC603 IC-HOLDER
SP701 VYH7653-002 IC HOLDER
S8021 QSW0851-001 DETECT SWITCH
S8022 QSW0851-001 DETECT SWITCH
TH701 QAD0015-103Z THERMISTOR
W1801 QJK021-021502 SIN CR C-B WIRE
W3001 QJK002-061201 SIN CR C-B WIRE
W3002 QJK019-040704 SIN CR C-B WIRE
W3901 QJK019-072002 SIN CR C-B WIRE
W5001 QJK018-110501 SIN CR C-B WIRE
W8001 QJK018-020502 SIN CR C-B WIRE
W8002 QJK018-040504 SIN CR C-B WIRE
W8003 QJK018-021202 SIN CR C-B WIRE
W8004 QJK018-030503 SIN CR C-B WIRE
W8005 QJK018-020502 SIN CR C-B WIRE
X6051 QAX0413-001Z CRYSTAL
X7001 QAX0401-001 CRYSTAL
X7002 QAX0410-001 CERA LOCK
(CD board)
Item
Parts number Parts name Area
Remarks
